DiPlay
CarPlay for compatible BYD Android head units. Wired and wireless, with the familiar DiAuto interface. Independent app: com.shihab.diplay.
BYD support scope: These projects focus on BYD cars. They may work on other brands, but other brands are unsupported and there are no plans to add support or fix brand-specific incompatibilities.
Download & website · Release · Report a problem
0.2.19 — public preview
Install on the car, not the iPhone. No jailbreak, dongle, Mac, account or authentication server is required for use. Core CarPlay does not require ADB; optional dashboard, battery, wheel-speed and parked-video features do. Your head unit must permit APK installation. The APK supports Android 7.1+ (API 25); Android 7.1–8.1 support is not yet confirmed on a vehicle. Wireless supports Wi-Fi Direct, the car’s existing hotspot or Existing Wi-Fi / Same LAN. Android 7.1–9 Wi-Fi Direct uses a firmware-dependent legacy path with generated group credentials and unverified requested frequency; see Android 9 Wi-Fi Direct. Android 10+ verifies its negotiated group frequency.
- Wired USB and wireless CarPlay with local authentication.
- BYD HUD navigation with arrows, distance and street names on verified firmware.
- Car hotspot support, improved audio buffering and saved receive diagnostics.
- Automatic address discovery, fixed-channel Wi-Fi fallbacks and successful-configuration memory.
- Icon/text size, resolution and frame rate; applying a display change reconnects CarPlay.
- Local diagnostic export. Reports are sent only if you choose to share them.
- Separate installation alongside DiAuto. Run one projection app at a time.
This is not an Apple-certified product. The APK bundles an experimental accessory identity recovered from public Carlinkit firmware, not a newly provisioned MFi identity for DiPlay. A bundled private key is extractable. Acceptance after future iOS updates, reliability across head units and suitability of that identity for general distribution are unresolved. This release invites community testing; it is not a guarantee of universal compatibility.
Earlier releases were tested on the development DiLink5.1 car: live windshield guidance and street names work, Car hotspot now starts CarPlay, and Wi-Fi Direct performance is substantially improved. Audio underrun recovery is improved in 0.2.15; remaining cutouts need current diagnostic reports. The 0.2.16 software Opus microphone fallback was accepted on a BOS Mini A1 head unit (Android 9) with an iPhone 12 on iOS 27. The floating-map test build was installed on the development DiLink 5.1 car; feedback led to the pinch corrections in 0.2.9. Earlier wheel-speed and video contributions were tested on a BYD Tang with DiLink 5.0 and an iPhone 15 Pro on iOS 27; wheel-speed dead reckoning in tunnels remains unverified. Broader head-unit and iOS compatibility is not guaranteed. The HUD firmware scope and cleanup limits are documented in BYD navigation.
What’s new in 0.2.19
- Wired CarPlay starts several seconds sooner on many head units, starts on iOS 26 when the iPhone first offers a USB mode without CarPlay, and works on Android 7.1–9 head units whose firmware removed the USB permission page (with approved network ADB).
- Calls, Siri and navigation prompts keep the right timing with the iPhone, and music no longer underruns while CarPlay is in the background.
- With the DiLink 4 dashboard map on, CarPlay no longer restarts at the first touch; with the status bar kept, it no longer stays scaled down after the reversing camera.
- DiPlay is available in Japanese, Traditional Chinese is complete, and more Arabic strings are translated.
- Settings → Diagnostics → Get the report on a phone downloads the diagnostic report on a phone, by QR code or a typed address and code; the connection screen shows a tip for each failure.
- A redesigned settings menu inside CarPlay, and an optional album-artwork card on the dashboard map.
See 0.2.19 release notes and validation for contribution links and remaining physical tests. General stutter, calls/Siri, decoder and model-specific reports still need current-device evidence. 0.2.18 notes remain available as historical guidance.
If a problem remains, reproduce it on 0.2.19, then use Settings → Diagnostics → Save diagnostic report. Android 10+ normally saves to Downloads/DiPlay; Android 7.1–9 asks for storage access and saves there too. If unavailable, use View report or Share from the confirmation, which identifies external/private fallback storage. Review the .txt and add it to a matching existing issue, or create one. Include vehicle/head-unit model, exact firmware and Android/DiLink, phone/iOS, connection backend, relevant settings, steps and failure time. Reports are shared only when you choose; never post your hotspot password.
Documentation
Existing Wi-Fi / Same LAN keeps the iPhone and head unit on an external router. See the guide for setup, build requirements and the BYD DiLink 4.0 / Android 10 clean-install validation result.
- Install and connect
- Compatibility and troubleshooting
- Smooth wireless CarPlay
- Privacy and diagnostic reports
- Build from source — select
mobilefor the main DiPlay app;maphostis a map sample. - Validation
- Release notes
- Credits and licenses
The app and the website source include English, Arabic, Russian, Ukrainian, Spanish, Simplified Chinese, Traditional Chinese (Taiwan), and Japanese. Traditional Chinese uses Taiwan wording; the app also recognizes Hong Kong/Macao and explicit Hant selections without claiming separate regional translations. Choose the app language in Settings; on Android 13+, it stays synchronized with Android’s per-app language setting. See the Traditional Chinese guide for installation, settings, troubleshooting, privacy and build instructions.
Source and credits
Based on xcertplay, GPL-3.0. The home/settings UI and website adapt DiAuto, AGPL-3.0; that license is included in docs/licenses. Preserve those notices when distributing modifications. CarPlay and its icon belong to Apple Inc.; no Apple or BYD affiliation or endorsement is implied.
This repository starts with a clean public source snapshot. Local research, tester reports and release-signing secrets are excluded. The complete source corresponding to the APK is provided with every release; experimental runtime identity assets are described separately in the build instructions and notices.
Local release packaging
The release APK intentionally contains the experimental accessory identity. The Git repository and source archive exclude all accessory and Android signing keys; tests generate synthetic identities at runtime. Source/CI builds omit runtime identity assets by default. Local release builds explicitly select an external asset directory. Publishing the APK makes its bundled identity extractable; building locally does not preserve that identity's confidentiality.
