MaxLiu22/Motion2MixamoRig

简体中文 · 繁體中文 · English · 한국어 · 日本語 · Deutsch · Русский · العربية · Tiếng Việt · Filipino · ไทย · Français · Español · Türkçe · नेपाली · Bahasa Indonesia · Polski · Nederlands

Transfer the motion of a person in a video — or the pose in a still photo — onto an Adobe Mixamo-rigged 3D character.

For game developers: give it a single-person action video (or a still) and a Mixamo character; it writes preview videos plus a skinned character file (.glb) you can drop into Blender or Unity.

Motion2MixamoRig is currently experimental. Version 0.1.7 is the command-line pipeline. This repository also includes a Blender 4.2+ Extension that runs that same pipeline in an external Python environment. Building the add-on from source: blender_extension/README.md.

1. Download the zip for your platform, e.g. motion2mixamorig-<version>-macos-arm64.zip, from the latest release.
2. In Blender: Edit → Preferences → Get Extensions → ∨ → Install from Disk…, pick the zip.
3. 3D Viewport → press N → Motion2MixamoRig tab → Install Runtime (one click).
4. Choose SMPL-X Model… (a free download) and pick a Mixamo character FBX.
5. Choose a video of one person → Generate Motion.

Step-by-step instructions, tips, and updating: User Guide. Tested on macOS (Apple Silicon).

Clone the repository and run the pipeline yourself: start at Prerequisites.

Agents should start with AGENTS.md.

_{Open demo.mp4 in this repository.}

Another demo:

Python 3.11+. After cloning, create a virtualenv and install dependencies; the m2mr command is then available:

git clone https://github.com/MaxLiu22/Motion2MixamoRig.git
cd Motion2MixamoRig
python -m venv .venv && source .venv/bin/activate

# Install dependencies and this project. chumpy (a legacy package on the
# dependency chain) imports pip in its setup script, which fails with
# "No module named 'pip'" under pip's default isolated build. Install it
# first with isolation turned off, then install this project.
pip install --upgrade pip setuptools wheel \
  && pip install "numpy>=1.26" \
  && pip install --no-build-isolation "chumpy==0.70" \
  && pip install -e .

Inference weights (GVHMR and so on) are not downloaded here. The first m2mr run pulls them into weights/ (~5 GB, once only).

ffmpeg is recommended (macOS: brew install ffmpeg, Ubuntu: apt install ffmpeg). The pipeline runs without it, but the output videos will be silent and will not play in a browser.

This repository does not ship these files; you have to fetch them. The SMPL-X filename must match the table exactly; FBX, video, and image names can be anything. A run needs SMPL-X, a Mixamo character, and either a video or a still. Mixamo characters re-exported from Cinema 4D also work; see docs/c4d-fbx-support.md.

Note: Mixamo's download is named Y Bot.fbx (space), one character off from Y_Bot.fbx (underscore) in the table. Rename it to the underscore form and it becomes the default rig (m2mr run without --rig). Leaving the space is fine too — if Y_Bot.fbx is missing, the first .fbx in assets/mixamo/ is used.

assets/video/ can hold several videos. Without --video or --image, the run uses the file most recently added to assets/video/; if that folder is empty it falls back to the latest still in assets/image/. Each clip or photo must show only one person, head to toe in frame — nothing cropped at the edges. m2mr doctor / m2mr run stop before extraction if two people are in view.

Results land in outputs/<run-time>_<source>/. Video runs write videos/; still runs write images/.

Anything missing is printed with where to download it and where to put it.

m2mr doctor

With no flags, this uses the latest file in assets/video/ and assets/mixamo/Y_Bot.fbx.

m2mr run

This is the slow step. The first run downloads ~5 GB of inference weights (once only), then extracts human motion from the video. On CPU, a ~30 second clip takes about 8–15 minutes to extract; later runs of similar length, with weights already there, take about 3–5 minutes. Retargeting and rendering are usually a minute or two. Reusing a skeleton with --skeleton in the next section skips extraction entirely and finishes in tens of seconds.

Download another character from Mixamo into assets/mixamo/. Do not rerun with only --rig — that repeats the slow extraction. Pass --skeleton to reuse the skeleton from a previous run; minutes become tens of seconds:

m2mr run --skeleton outputs/<previous-run-dir>/skeleton_motion.npz --rig assets/mixamo/Vampire.fbx

--video picks the clip. It combines freely with --rig.

m2mr run --video assets/video/dance.mp4 --rig assets/mixamo/Vampire.fbx

--image recovers a static 3D pose from a photo of one person, then retargets it onto the Mixamo character the same way a video run does. Previews are four stills in images/ (same views as the video run), plus a left/right orbit clip before_after_360_compare.mp4. Do not pass --video at the same time.

m2mr run --image assets/image/pose.jpg
m2mr run --image assets/image/pose.jpg --rig assets/mixamo/Vampire.fbx

--image with no path uses the file most recently added to assets/image/.

Each m2mr run creates a directory named by the time the command started. The four files at the root are the same for video and still; only the preview folder changes.

outputs/20260829_193205_dance/          # or …_pose/ for a still
├── run.json                            # start time, inputs, full command
├── skeleton_motion.npz                 # 3D human skeleton (reuse with --skeleton)
├── mixamo_rotations.npz                # per-bone Mixamo rotations
├── mixamo_character.glb                # skinned character, import into Blender / Unity
└── videos/   or   images/              # previews — which one depends on the input

Video input writes videos/ (same aspect ratio as the clip):

videos/
├── human_skeleton.mp4                  # recovered 3D human skeleton
├── mixamo_skeleton.mp4                 # Mixamo rig skeleton
├── mixamo_character.mp4                # skinned Mixamo character
└── compare.mp4                         # 2×2: original (TL) / Mixamo skeleton (TR)
                                        #      human skeleton (BL) / character (BR)

Still input writes images/ instead (same four views, plus a turntable):

images/
├── human_skeleton.png                  # recovered 3D human skeleton
├── mixamo_skeleton.png                 # Mixamo rig skeleton
├── mixamo_character.png                # skinned Mixamo character
├── compare.png                         # 2×2: original (TL) / Mixamo skeleton (TR)
│                                       #      human skeleton (BL) / character (BR)
└── before_after_360_compare.mp4        # left: original photo
                                        # right: 10° orbit of the rig (one full turn)

Open mixamo_character.glb in Blender: File → Import → glTF 2.0 (.glb/.gltf). If the camera is framed on empty space, select the character mesh and use View → Frame Selected. The cluster of spheres on the head and hands is bone display, not the mesh: in the Outliner, hide Icosphere and the armature; leave the skinned mesh visible. Set scene FPS and the timeline end frame from run.json (fps, n_frames) so playback matches the source. Compare a video run against videos/mixamo_character.mp4, a still run against images/mixamo_character.png or the orbit clip.

This repository's code is Apache-2.0. The assets you download have their own terms and must not be redistributed with this repo:

• SMPL-X: MPI-gated; default non-commercial research / education / art; commercial use needs a separate deal
• Mixamo FBX: fine in a shipped product; do not redistribute the raw FBX as an asset pack
• GVHMR and other inference weights: auto-downloaded into weights/ on the first m2mr run, under each upstream license

If you run into a problem, need help finishing a local setup, or would like to talk about working together, email: maxliu2022sz@gmail.com
