programmerguohuajing/DiPlay-Legacy-Android

English · 简体中文

This project is modified from shihabal3amri/DiPlay with deep compatibility refactoring.

Scope difference with upstream:

• Upstream DiPlay supports Android 7.0+ (API 24) in latest releases, primarily targeting modern 64-bit platforms.
• This project focuses on Android 4.4 KitKat (API 19) through Android 6.0, as well as legacy 32-bit automotive hardware architectures (armeabi-v7a, x86, Allwinner T3, MediaTek, AC8227L), low-level Linux usbfs driver hardening, and proprietary Bluetooth stacks (e.g., Hangsheng HSAE for Dongfeng Nissan).

Upstream project: https://github.com/shihabal3amri/DiPlay

CarPlay for compatible BYD and legacy Android head units. Wired and wireless, with the familiar DiAuto interface. Independent app: com.shihab.diplay.

BYD support scope: These projects focus on BYD cars. They may work on other brands, but other brands are unsupported and there are no plans to add support or fix brand-specific incompatibilities.

Download & website · Release · Report a problem

Install on the car, not the iPhone. No jailbreak, dongle, Mac, account or authentication server is required for use. Core CarPlay does not require ADB; optional dashboard, battery, wheel-speed and parked-video features do. Your head unit must permit APK installation. The APK supports Android 9+ (API 28); wireless supports Wi-Fi Direct, the car’s existing hotspot or Existing Wi-Fi / Same LAN. Android 9 Wi-Fi Direct uses a firmware-dependent legacy path with generated group credentials and unverified requested frequency; see Android 9 Wi-Fi Direct. Android 10+ verifies its negotiated group frequency.

• Wired USB and wireless CarPlay with local authentication.
• BYD HUD navigation with arrows, distance and street names on verified firmware.
• Car hotspot support, improved audio buffering and saved receive diagnostics.
• Automatic address discovery, fixed-channel Wi-Fi fallbacks and successful-configuration memory.
• Icon/text size, resolution and frame rate; applying a display change reconnects CarPlay.
• Local diagnostic export. Reports are sent only if you choose to share them.
• Separate installation alongside DiAuto. Run one projection app at a time.
• Legacy Android fallbacks for media keys, notification/services, USB configuration and requests, audio/video codecs, multidex and Java library APIs.

This is not an Apple-certified product. The APK bundles an experimental accessory identity recovered from public Carlinkit firmware, not a newly provisioned MFi identity for DiPlay. A bundled private key is extractable. Acceptance after future iOS updates, reliability across head units and suitability of that identity for general distribution are unresolved. This release invites community testing; it is not a guarantee of universal compatibility.

Earlier releases were tested on the development DiLink5.1 car: live windshield guidance and street names work, Car hotspot now starts CarPlay, and Wi-Fi Direct performance is substantially improved. Occasional audio cutouts remain and are deferred to a later update. The floating-map test build was installed on the development DiLink 5.1 car; feedback led to the pinch corrections in 0.2.9. Earlier wheel-speed and video contributions were tested on a BYD Tang with DiLink 5.0 and an iPhone 15 Pro on iOS 27; wheel-speed dead reckoning in tunnels remains unverified. Broader head-unit and iOS compatibility is not guaranteed. The HUD firmware scope and cleanup limits are documented in BYD navigation.

• Searchable Settings, clear categories, quick controls and reconnect notices, with layouts for short screens and Arabic RTL.
• Interface size from Automatic to 200% for DiPlay's own controls, separate from CarPlay picture sizing.
• Default automatic connection choice: Last used, Wireless or USB; scheduled day/night appearance; more reliable car-button image selection.
• Targeted USB/Bluetooth recovery, hotspot address discovery, video output on windows without hardware acceleration, and safer wireless handoff.
• Smooth video (experimental), off by default, with a latency tradeoff and no picture adjustments on its SurfaceView path.
• Configurable wheel-key Siri, microphone-source fallback, optional audio-focus handling and BYD call-watcher repairs.
• Call echo cancellation and Clearer call voices, experimental and off by default; opt-in changes apply at the next connection.
• Album artwork proportions, system-bar-aware rotation/split-screen areas and recognition of an observed DiLink 3 cluster surface.

See 0.2.14 release notes and validation for contribution links and remaining physical tests. General stutter, calls/Siri, decoder and model-specific reports still need current-device evidence. 0.2.13 notes remain available as historical guidance.

If a problem remains, reproduce it on 0.2.14, then use Settings → Diagnostics → Save diagnostic report. Android 10+ normally saves to Downloads/DiPlay; Android 9 uses the document picker. If unavailable, use View report or Share from the confirmation, which identifies external/private fallback storage. Review the .txt and add it to a matching existing issue, or create one. Include vehicle/head-unit model, exact firmware and Android/DiLink, phone/iOS, connection backend, relevant settings, steps and failure time. Reports are shared only when you choose; never post your hotspot password.

Existing Wi-Fi / Same LAN keeps the iPhone and head unit on an external router. See the guide for setup, build requirements and the BYD DiLink 4.0 / Android 10 clean-install validation result.

• Install and connect
• Compatibility and troubleshooting
• Smooth wireless CarPlay
• Privacy and diagnostic reports
• Build from source — select mobile for the main DiPlay app; maphost is a map sample.
• Validation
• Release notes
• Credits and licenses

The app and release website are available in English, Arabic, Russian, Ukrainian, Spanish, Simplified Chinese and Traditional Chinese (Taiwan). Traditional Chinese uses Taiwan wording; the app also recognizes Hong Kong/Macao and explicit Hant selections without claiming separate regional translations. Choose the app language in Settings; on Android 13+, it stays synchronized with Android’s per-app language setting.

Based on xcertplay, GPL-3.0. The home/settings UI and website adapt DiAuto, AGPL-3.0; that license is included in docs/licenses. Preserve those notices when distributing modifications. CarPlay and its icon belong to Apple Inc.; no Apple or BYD affiliation or endorsement is implied.

This repository starts with a clean public source snapshot. Local research, tester reports and release-signing secrets are excluded. The complete source corresponding to the APK is provided with every release; experimental runtime identity assets are described separately in the build instructions and notices.

• Issues & Discussions: Feel free to discuss questions and issues in GitHub Issues. We will reply whenever time permits.
• Check Real Android OS Version: If installation fails (e.g. "There was a problem parsing the package"), your aftermarket head unit may have a spoofed system version (such as fake Android 10/11/12 on top of real Android 4.4/5.1). You can use this head unit inspection tool provided by @493330227-wq to check your genuine Android version and API level:
  👉 headunit-version-inspector
• Attach Diagnostic Logs: When reporting a specific problem, attaching detailed diagnostic logs (via Settings → Diagnostics → Save diagnostic report, automatically exported to USB/SD cards since v0.2.27) and environment details (head-unit model, Android version, iPhone/iOS version) is strongly recommended.
• Contributions Welcome: Pull Requests (PRs) from experienced developers are warmly welcomed to help improve compatibility across various legacy automotive hardware!
• ⭐ Support: If this project is helpful to you, please give it a Star!
