ZOVserver is the world's first fully open-source private server emulator for Brawl Stars V24, built on the .NET 10 platform and the Microsoft Orleans actor model.

Unlike traditional monolithic emulator architectures, ZOVserver offers an uncompromising approach: a total separation of business logic into microservices, strict typing, zero-allocation paradigms in critical execution paths, sophisticated routing, and support for cutting-edge databases. When properly configured in a cluster, it stands as the most fault-tolerant server in the world, featuring best-in-class defense against automated bot request floods, with seamless support for hot horizontal and vertical scaling.

• Absolutely all of Brawl Stars V24's lobby functionality.
• The core of the battle system (battle loading, battle spectating, basic movement logic)

• Key Architectural Paradigms and Technology Stack
  • Database and Caching Foundation
  • Telemetry, Monitoring and Discovery
• Detailed Breakdown of the Microservices Domain (src/)
  • 1. Network Gateway (Gateway Layer)
  • 2. Scalable Game Services (Game Silos)
  • 3. Extreme Battle Silos (Battle Silos)
  • 4. Global Services (Single-Instance)
  • 5. Infrastructure Bridges (Shared Services)
• Libraries, Code Generation and Legacy (Shared)
• Control Panel and Orchestration (Admin Panel & Bots)
  • Admin Panel (ZOVserver.AdminPanel)
  • Telegram Orchestrators (ZOVserver.Orchestra)
• 🚀 Deployment and Launch
• Client Configuration and Patching (APK)
• License and Disclaimer

The infrastructure is designed to handle hundreds of thousands of simultaneous connections. Every data and network-routing layer is strictly optimized for its specific task.

• MongoDB: Serves as the persistent State store (via Orleans.Providers.MongoDB) for players, clubs, teams, content creators, and so on.
• Microsoft Garnet: An ultra-fast in-memory store. Used exclusively for microsecond-scale operations: storing raw leaderboard indexes (ID:Trophies) and powering the in-lobby team-finding system.
• Redis: Storage for "enriched" data. Receives fully assembled top-player profiles from the worker processes across 266 geographic regions for instant delivery to the client.
• etcd: A smart storage layer. Used to synchronize global promotions (Offers) across all running HomeService instances in the cluster via the WatchRangeAsync and GetRangeAsync mechanisms.
• NATS: A high-performance message bus. Responsible for the instant synchronization of events (game modes) across all nodes.
• OpenSearch: A search cluster with custom DSL queries. Provides fuzzy club search using sophisticated ranking algorithms and prefixes.

• Orleans cluster topology maintenance is available via either Consul (default) or ZooKeeper.
• Internal .NET and Orleans metrics (via Prometheus-net) are collected by the Mimir server and visualized in Grafana.
• SeaweedFS is integrated as a modern distributed file system for metrics.

ZOVserver.Bridge.TcpProtocolBridge An asynchronous TCP bridge built on the high-performance DotNetty framework.

• Anti-DDoS: The bridge doesn't just forward connections - it also acts as an L7 filter. When a suspicious traffic spike is detected (N connections to a port within 60 seconds), a custom self-protection trigger fires, temporarily halting new incoming connections on the targeted port and protecting the internal Orleans cluster from thread starvation.
• Rasputin-Protect: Protection against bot requests and attempts by attackers to analyze the network architecture.
• Communication: Packets of the Laser protocol are parsed on the fly. Incoming requests are routed to Grains via the Orleans Client, while the asynchronous return delivery of packets from grains to the bridge is handled through the Orleans Observer mechanism. Direct routing from the Bridge is permitted only to three entry-point services: PlayerSessionService, HomeService, and FriendshipService.

A group of services designed to run in parallel across multiple instances.

• ZOVserver.Services.Game.PlayerSessionService: The session lifecycle control service. Handles account generation and verification, as well as cryptographic validation of the hashed passToken. Responsible for the Lock/Ban system: a Locked account enters a special waiting state - if the user knows the unique code issued by an administrator and enters it, the account is unlocked; a Banned account is unlocked automatically once the ban period expires.
• ZOVserver.Services.Game.HomeService: The core of the business logic and the largest node in the project. Handles the generation of personalized promotions, calculates the reward-drop entropy for Brawl Boxes, and manages gifts and offers. If a request falls outside its scope, it proxies it to AllianceService or TeamService.
• ZOVserver.Services.Game.FriendshipService: The friendship-graph node. Handles incoming friend requests, generates friends lists, and tracks online/offline presence status.
• ZOVserver.Services.Game.TeamService: Isolated logic for in-game Teams. Autonomously manages everything within a game room.
• ZOVserver.Services.Game.AllianceService: Business logic for Alliances (clubs). Transactionally manages roles, club trophies, and club state, while writing its data in parallel to the search indexes and Garnet leaderboard tables.
• ZOVserver.Services.Game.ContentCreatorRewardService: A monetization and creator-support service. Receives triggers not from the TCP bridge but from the Telegram orchestrator. Handles crediting a share (gems) to content creators' accounts whenever their code is activated by players during in-game purchases.
• ZOVserver.Services.Game.MatchmakingService: The matchmaking balancer. Applies complex algorithms to solve binary-optimization problems in order to group players into sessions. It accounts for trophy spread, the presence of pre-formed teams, and strictly prevents under- or over-filled matches, assembling ideal matches before sending them to BattleService. A timer can optionally kick in during low online periods, after which the battle will start even if the required number of players hasn't been reached.

ZOVserver.Services.Game.BattleService The most technically complex and high-load node in the cluster. It's an Orleans silo, but internally hosts UDP battle servers. Battle state is kept exclusively InMemory.

• Zero-GC & Marshalling: To eliminate "stutters" caused by the .NET Garbage Collector, all battle code is written to GC-friendly standards. It makes heavy use of unsafe blocks, raw memory pointers, struct types, ArrayPool, and Span<T>.
• LogicLooper: All battle context, movement physics, collision, and damage calculations run in a strict game loop at 20 ticks per second, built on top of the powerful Cysharp.LogicLooper library.
• Scale: A single battle is represented by a single Orleans grain, but just one UDP server instance is capable of asynchronously routing traffic for tens of thousands of such grains.
• Cryptography: An ultra-fast implementation of the encryption protocol applied to every packet sent over the Datagram (UDP) channel.

Services that are strictly permitted to run as only a single instance in order to avoid race conditions:

• ZOVserver.Services.Global.GameGlobalEventsService: The server's "director." Responsible for global state flags: switching gamemodes, box-opening availability, shop states, trophy seasons, and maintenance breaks. Synchronizes its changes across all Game Silos and Bridge via NATS.
• ZOVserver.Services.Global.LeaderboardEnrichmentService: The leaderboard-enrichment daemon. Runs a complex assembly pipeline: on a schedule, it queries Garnet to pull the leading ID:Trophies pairs, then queries HomeService to load full player profiles or AllianceService to load club headers, and writes the finished data to Redis. The process repeats for 266 regions across three independent categories: Players, Clubs, and Brawlers.

(Requires publishing to NuGet to keep versions in sync)

An abstraction layer used by a handful (2-3) of Game nodes. They're "shared" because they allow database-access logic to be reused while keeping the calling services fully encapsulated:

• ZOVserver.Services.Shared.AllianceSearchService: The club search engine. Issues complex queries to the OpenSearch cluster. The search algorithm uses boost factors for optimal relevance:
  • An exact match (the raw suffix) receives the maximum Boost = 20.
  • A prefix match (MatchPhrasePrefix) receives Boost = 10.
  • Fuzzy search (tolerating typos) via Damerau–Levenshtein distance (Fuzziness.EditDistance(2)) receives Boost = 5.
  • Used in: HomeService (for reading search results) and AllianceService (for writing and updating indexes).
• ZOVserver.Services.Shared.GarnetLeaderboardsService: The interface for interacting with Microsoft Garnet. Responsible for atomic reads and writes of trophy scores.
  • Used in: LeaderboardEnrichmentService (read), HomeService (write), AllianceService (write).
• ZOVserver.Services.Shared.TeamPlayersSearchService: Implements the team-finding mechanic. Also built on Garnet, thanks to its microsecond read/write latency and mature atomicity guarantees.
  • Used in: HomeService (fetching available teams) and TeamService (writing teams that are ready to accept players).

(Requires publishing to NuGet to keep versions in sync)

The src/shared/ directory (not to be confused with Services.Shared) contains the foundational projects that the entire server is built on:

• ZOVserver.Shared.Contracts: Defines all RPC contracts for Orleans and the Laser protocol structures.
• ZOVserver.Shared.Contracts.Generator: A powerful .NET Source Generator. Runs at compile time, scanning C# message and command classes (marked with the [LaserSerializable] attribute) and automatically generating high-performance Encode/Decode methods - completely eliminating slow runtime Reflection and manual serialization code from the server.
• ZOVserver.Shared.Contracts.Proto: Defines the .proto files used for inter-service gRPC communication.
• ZOVserver.Shared.Localization: A centralized project for managing server localization across every language supported by the Brawl Stars client.
• ZOVserver.Shared.TitanRemnants: The highlight of the codebase. The remnants of the original Titan game engine, fully reverse-engineered and rewritten in modern C#. Includes:
  • Ultra-fast ByteStream and BitStream implementations for working with binary streams. A benchmark confirming the superiority of this implementation is available in the ZOVserver.Basic.Titan.Streams repository.
  • The innovative PAssets approach for lightning-fast parsing of in-game CSV assets, with highly optimized usage.
  • Math utilities and helpers.

To ensure maximum security, the server has no built-in administrative commands in the in-game chat. All management is handled through external RPC interfaces:

• Frontend: Written in Python using the Flet v0.23.0 framework.
• Backend: Written in C# and communicates over gRPC.
• Communication: The frontend calls the backend's methods over gRPC, which in turn issues Orleans Client requests.
• Capabilities: Real-time cluster metrics viewing, issuing Locks/Bans, crediting gifts to accounts, sending in-game messages (Inbox), and dynamically creating promotions (Offers) on the server without restarting the cluster.

Interactive management of business entities directly from the messenger:

1. ContentCreatorsBotOrchestrator: A Telegram bot for managing content creators. Lets administrators register new creator codes, assign payout tiers, and track transparent statistics on player donations (linked to ContentCreatorRewardService).
2. GameGlobalEventsBotOrchestrator: A bot that performs remote gRPC calls to the GameGlobalEventsService singleton. Lets administrators add new game events, stop map rotation, close the shop, or block box openings, and trigger scheduled maintenance - all with a single command.

The entire external stack is deployed with a single command:

1. Make sure ports 27017, 8500, 8600, 4222, 8222, 2379, 2380, 9333, 8333, 9009, 12345, 3000, 6380, 2181, 2182, 2183, 9005, 9200, 9300, 9201, 9301, 6191, 6194 are free.
2. The docker/ folder contains a single docker-compose.yml that spins up the entire ecosystem: MongoDB, Redis, Garnet, OpenSearch, NATS, etcd, Consul, Mimir, SeaweedFS, and Grafana.
3. Start the infrastructure:

    docker-compose up -d

Recommended order for the cluster's first launch:

dist-files
services/game
services/global
bridge
admin-panel
orchestra

APK: https://github.com/ZOVserver/ZOVserver/releases/download/V24/ZOVclient_s2417_.apk

The libsettings.so file is generated using settings_creator.py in the client/ directory.

• Adding Servers and Ports:
  • Specific ports (.add): Attach individual ports to an IP address (e.g., servers.add("192.168.0.10", "9339,9449")).
  • Port ranges (.addRange): Assign a range of sequential ports to an IP address (e.g., servers.addRange("172.17.64.1", 9006, 9099)).
  • Method chaining: You can chain multiple .add() or .addRange() calls together on the same Servers() instance.
• Loading Screen Text (watermark):
  • Display a custom loading screen message instead of the default "Connecting to server..." (e.g., watermark = "Welcome to ZOVserver client!").
  • To keep the default game text, set watermark to an empty string (""), "none", or "null".

• The package name MUST start with the prefix org.zovserver. (otherwise the application will fail to launch).
• After the dot, any unique words or identifiers of your choosing are allowed.
  • Correct: org.zovserver.mybrawl, org.zovserver.medved, org.zovserver.pvp
  • Incorrect: com.brawlstars.zov, org.zov.server

This project is distributed under the MIT license.

Disclaimer: ZOVserver is an open-source emulator created for educational and research purposes. It is not affiliated with, endorsed by, or sponsored by Supercell Oy or its subsidiaries. All trademarks, characters, and assets from Brawl Stars belong to Supercell. The project does not contain any proprietary game files; a legitimate copy of the client is required to use it.
