Overview & Vision
Human movement is inherently transient. Whether an athlete sprinting, a dancer executing a spin, a gymnast mid-air, or a child jumping, fleeting physical motion unfolds and vanishes within fractions of a second.
MotionShot bridges high-speed mobile computer vision with human kinetic expression. Inspired by Sony's legacy Motion Shot technology, MotionShot captures dynamic action bursts and synthesizes a single, multi-pose stroboscopic composite image directly on-device in real time.
Operating entirely offline with zero cloud latency and zero reliance on heavy AI neural networks, MotionShot renders motion as an aligned visual trajectory: sharp, stabilized, and captured in full sensor resolution.
Visual Showcase
| Camera Viewfinder | Hardware Sliders | Step 1 Raw Gallery | Composite Result |
|---|---|---|---|
 |
 |
 |
Technical Specifications
| Parameter | Specification & Range | Engineering Function |
|---|---|---|
| Timer Window |
1s, 2s, 5s, Custom (1–60s)
|
Dynamic sequence capture deadline |
| Frame Count |
5, 15, 25, Custom (2–50)
|
Trajectory density sampling points |
| Shutter Speed |
Auto, 1/30s to 1/8000s
|
Logarithmic hardware motion-freeze slider |
| ISO Sensitivity |
Auto, ISO 50 to ISO 102,400
|
Continuous sensor gain boost |
| Stabilization | $\pm 16\text{px}$ 2D translation search | Sub-5ms background micro-jitter alignment |
| Blending Engine | PorterDuff.Mode.SRC_OVER |
Sequential alpha layer compositing |
| Persistence | SharedPreferences |
Automatic parameter restoration across sessions |
Key Features
-
Pixel-to-Pixel Handheld Image Stabilization: The 2D translation alignment engine (
ImageStabilizer) correlates background grid pixels across frames, locking static elements in place to eliminate camera shake. - Normalized Chromaticity Motion Differencing: Evaluates $r, g$ color space ratios alongside BT.601 luminance separation, making motion detection 100% immune to camera exposure shifts and shadows.
-
High Shutter Speed Freeze-Frame Control: Manual shutter speed control down to
1/8000s($125,\mu\text{s}$ exposure) freezes ultra-fast movement without motion blur. - Extended ISO Gain Boost: Manual ISO control scaling up to ISO 102,400 maintains crisp image brightness even under high shutter speeds in low light.
-
Fast Motion Slide & Auto-Play Flipbook Preview: Interactive touch-drag preview and a
▶ Playbutton (15 FPS flipbook) allow instant sequence verification before finalizing. -
Pluggable Engine Architecture: Decoupled
MotionEngineinterface andMotionEngineFactoryallow instant engine swapping without modifying UI state logic.
Architecture Overview
MotionShot follows a strict Contract-Based Clean Architecture, decoupling UI presentation, state orchestration, image processing algorithms, and Camera2 hardware controls.
graph TD
subgraph Presentation["Presentation Layer (Jetpack Compose)"]
MA[MainActivity] --> CS[CameraScreen]
CS --> CP[CameraPreview Viewfinder]
CS --> CC[CaptureControls Sheet & Sliders]
CS --> RV[Step1ResultView Flipbook Gallery]
end
subgraph Domain["Domain Contracts & Storage"]
VM[MotionShotViewModel] --> |Preferences| PR[PreferencesRepository]
VM --> |Pluggable Contract| ME[MotionEngine Interface]
end
subgraph Engine["Image Processing Realizations"]
ME --> FDEM[FastDifferenceMotionEngine]
FDEM --> STAB[ImageStabilizer Engine]
FDEM --> DIFF[FrameDifferencer Engine]
FDEM --> MORPH[MorphologyOps Engine]
FDEM --> CCMP[CanvasCompositor Engine]
end
subgraph Hardware["Hardware Capture Layer (CameraX / Camera2)"]
VM --> FA[FrameAnalyzer]
FA --> YR[Native C++ YuvToRgb]
VM --> C2[Camera2Interop Control]
C2 --> CP
end
Technical Processing Pipeline
Each captured frame sequence moves through a zero-allocation processing pipeline:
flowchart TD
A["Raw Frame Burst (N Frames)"] --> B["1. 2D Translation Alignment (ImageStabilizer)"]
B --> C["2. Normalized Chromaticity Differencing (FrameDifferencer)"]
C --> D["3. 3x3 Morphological Opening (MorphologyOps)"]
D --> E["4. Soft Contour Edge Feathering"]
E --> F["5. Sequence Alpha Decay (CanvasCompositor)"]
F --> G["Final Stroboscopic Composite Image"]
Request Lifecycle & Frame Acquisition
sequenceDiagram
autonumber
actor User
participant UI as CameraScreen / Controls
participant VM as MotionShotViewModel
participant Analyzer as FrameAnalyzer
participant Engine as MotionEngine
User->>UI: Tap Capture Button
UI->>VM: onCaptureToggle()
VM->>VM: Lock Start Time & Set Hard Deadline (T seconds)
loop Dynamic Time Window (T / N-1)
VM->>Analyzer: shouldCapture.set(true)
Analyzer-->>VM: frameChannel.receive() [Time-Bounded Timeout Guard]
end
VM->>Engine: process(capturedFrames)
Engine->>Engine: 2D Translation Alignment
Engine->>Engine: Normalized Chromaticity Masking
Engine->>Engine: 3x3 Morphological Noise Removal
Engine->>Engine: Native Canvas PorterDuff Stamping
Engine-->>VM: Return Composite Bitmap
VM->>UI: Phase = Done (Show Result & Interactive Flipbook)
Technical Deep-Dives
1. Handheld 2D Translation Alignment Mathematics
Camera micro-jitter causes static background edges to shift between frames. MotionShot computes an optimal $(\Delta x, \Delta y)$ alignment vector over a $\pm 16\text{px}$ search window using a 4x grid subsampling strategy:
$$\Delta x, \Delta y = \arg\min_{dx, dy} \sum_{y, x} \left| \text{Base}(x, y) - \text{Curr}(x + dx, y + dy) \right|$$
Target frame pixels are shifted by $(\Delta x, \Delta y)$ prior to motion differencing, locking static background elements 100% in place.
2. Normalized Chromaticity Color Space (r, g)
Camera auto-exposure shifts brightness across frames. Simple RGB subtraction fails under exposure drift. MotionShot converts pixels to Normalized Chromaticity:
$$r = \frac{R}{R + G + B + 1}, \quad g = \frac{G}{R + G + B + 1}$$
Combining chromaticity distance $\Delta_{\text{chroma}} = |r_1 - r_0| + |g_1 - g_0|$ with BT.601 luminance separation ($\Delta_Y = |Y_1 - Y_0|$) ensures lighting fluctuations and shadows are 100% ignored.
3. Camera2 Hardware Exposure & ISO Interop
High shutter speeds (1/500s to 1/8000s) eliminate subject motion blur. CameraX parameters are applied directly to the Camera2 HAL via Camera2CameraControl:
CaptureRequest.CONTROL_AE_MODE: Set toOFFfor manual exposure control.CaptureRequest.SENSOR_EXPOSURE_TIME: Configured in nanoseconds via logarithmic slider.CaptureRequest.SENSOR_SENSITIVITY: Configured up to ISO 102,400 for low-light gain compensation.
Repository Structure
bted.app.motionshot/
├── capture/
│ ├── FrameAnalyzer.kt # CameraX ImageAnalysis analyzer
│ └── YuvToRgb.kt # Native C++ accelerated ImageProxy to Bitmap
├── data/
│ └── PreferencesRepository.kt # SharedPreferences persistence (Timer, Count, Shutter, ISO)
├── engine/
│ ├── MotionEngine.kt # Pluggable engine interface contract
│ ├── FastDifferenceMotionEngine.kt # Math & Differencing engine
│ ├── MotionEngineFactory.kt # Engine registry & factory
│ └── DebugPipelineConfig.kt # Step-by-step pipeline config
├── processing/
│ ├── FrameDifferencer.kt # Normalized chromaticity & luminance differencer
│ ├── ImageStabilizer.kt # Pixel-to-pixel 2D handheld stabilizer
│ ├── MorphologyOps.kt # 3x3 Erode, Dilate, and Morphological Opening
│ └── CanvasCompositor.kt # Native Canvas PorterDuff compositing
├── ui/
│ ├── components/
│ │ ├── CaptureControls.kt # Sliders, custom input, tap-to-record button
│ │ └── LoadingOverlay.kt # Pulsing progress overlay
│ ├── state/
│ │ ├── MotionShotUiState.kt # UI state holder & CameraParameterUtils
│ │ └── CapturePhase.kt # Capture phase lifecycle
│ ├── theme/ # Dark aesthetic color, typography, theme
│ ├── CameraPreview.kt # CameraX preview + Camera2Interop hardware controls
│ └── CameraScreen.kt # Root camera & result flipbook gallery screen
└── viewmodel/
└── MotionShotViewModel.kt # StateFlow, preferences, capture loop, engine dispatcher
Building & Requirements
System Requirements
- Android Studio: Ladybug / Jellyfish or newer
- Android SDK: Compile SDK 37 (Min SDK 24)
- Kotlin: 2.2.10
- Gradle: 8.13+
Local Build Commands
# Clone the repository git clone https://github.com/AhmadHassan-BTed/MotionShot.git cd MotionShot # Execute unit tests ./gradlew test # Build Debug APK ./gradlew assembleDebug
