Origami is a Home Assistant theme with a matching phone dashboard. The dashboard is built mainly with Paper Buttons Row and Bubble Card, and everything else uses what Home Assistant already offers, such as themes, template sensors and scripts. The repository also contains modules that give Bubble cards the Origami look.

Part	Description
Theme	The theme uses muted, warm colors in light and dark mode. Strong colors are used mainly for devices that are on. It works with any dashboard.
Dashboard	The dashboard shows the weather, favorites, rooms and a navigation bar. You can install all of it or copy single cards.
Bubble Card modules	The modules give Bubble cards the Origami look. They are still a bit experimental. The module reference explains them.

Note

The dashboard comes from a real home, so all entities are examples. Replace them with your own and remove the parts you do not need. Some cards are built in an unusual way so that nothing moves while the page loads. The Techniques section explains how. The desktop layout is not finished yet.

Setup · Dashboard · Pop-ups · Helpers · Techniques · Theme · Troubleshooting

Setup

Theme only

Add these lines to configuration.yaml and restart Home Assistant. If frontend: is already in the file, add only the themes line under it.
```
frontend:
  themes: !include_dir_merge_named themes
```
Open Origami in HACS. If HACS asks you to add the repository, select Add. Then select Download.
Run frontend.reload_themes and select Origami in your profile.
To use the font, copy www/fonts to /config/www/fonts. Then add /local/fonts/montserrat.css as a Stylesheet under Resources. If you just created the www folder, restart Home Assistant.

Full dashboard

The dashboard has been tested with Home Assistant 2026.10. You need HACS and access to the /config folder, for example through the Samba share or the Studio Code Server app.

1. Copy three folders

To download this repository, select Code, then Download ZIP. Copy these folders into /config.

Folder	Contents
`www/fonts`	The Montserrat font
`bubble_card/modules`	The Bubble Card modules
`packages`	The helpers, with template sensors, toggles, a speaker selection, a timer, scripts and an automation

2. Edit configuration.yaml

Add these lines and restart Home Assistant. If homeassistant: or frontend: is already in the file, add only the indented line under the existing key.

homeassistant:
  packages: !include_dir_named packages

frontend:
  themes: !include_dir_merge_named themes

3. Install the cards from HACS

Open each repository in HACS. If HACS asks you to add the repository, select Add. Then select Download.

Repository	Used for	Link
Origami	The theme	Open in HACS
Paper Buttons Row	The greeting, the server card, the room cards, the climate table and the buttons in the pop-ups	Open in HACS
Bubble Card	The favorites, the section headers and the pop-ups	Open in HACS
Bubble Card Tools	Loading the Bubble Card modules	Open in HACS
Navbar Card	The navigation bar at the bottom	Open in HACS
Origami Notifications	The notifications next to the greeting	Open in HACS
Origami Weather	The weather card	Open in HACS

Restart Home Assistant again. Then add Bubble Card Tools as an integration.

4. Select the theme and add the font

Select Origami as the theme in your profile.
Add /local/fonts/montserrat.css as a Stylesheet under Resources.

5. Install Origami Header (optional)

Origami Header removes the Home Assistant header without any flicker while the page loads. In its place, a menu slides in from the top of the screen when you tap More in the navigation bar. Origami Header is still experimental, and the dashboard also works without it.

Open Origami Header in HACS. If HACS asks you to add the repository, select Add. Then select Download. Origami Header requires Home Assistant 2026.9 or newer.

Add the extra_module_url lines under the existing frontend: key in configuration.yaml. Then restart Home Assistant.

frontend:
  themes: !include_dir_merge_named themes
  extra_module_url:
    - /hacsfiles/origami_header/origami-header.js

To edit the dashboard, use the edit button in the menu or add ?edit=1 to the address.

6. Add the dashboard

Open Dashboards and select Add dashboard, then New dashboard from scratch. Open the new dashboard.
In the three-dot menu, select Edit dashboard, then Raw configuration editor.
Replace everything in the editor with the contents of dashboard.yaml.
If you do not use Origami Header, delete the card under # Menu (Origami Header) and the route under # Opens the Origami Header menu.
Select Save.

7. Replace the example entities

The dashboard uses entities from one home. In the raw configuration editor, press Ctrl+F (⌘F on a Mac) to find an entity such as light.living_room, and replace it with your own. Do the same in the pop-ups at the end of the file. Delete the parts that do not apply to your home, such as a tile, a room or a navigation bar button. Each part described under Dashboard has a list of the entities it uses.

Then replace the same entities in /config/packages/origami.yaml. These are the temperature and humidity sensors, window contacts, front door, lights, speakers, scenes and fan. The dashboard reads the helpers that this file creates, such as sensor.climate_living_room. If you rename a helper, rename it in both files. Restart Home Assistant when you are done.

Single cards

Every part of the dashboard and every pop-up has a YAML section with the cards from its picture. You can add these cards to your own dashboard without the rest of dashboard.yaml.

Set up the theme and the font as described under Theme only.
Install the cards that the YAML section names. The table in step 3 of Full dashboard links to each of them. Bubble cards also need Bubble Card Tools and the modules, which steps 1 and 3 of Full dashboard set up.
If the cards read helpers, such as sensor.greetings, set up the package as in steps 1, 2 and 7 of Full dashboard.
Edit your dashboard, add a card and select Manual. Paste the YAML and replace the example entities with your own.

Dashboard

The dashboard is a single sections view for phones. In dashboard.yaml, each part starts with a comment such as # Favorites. Every part below also has a YAML section with the cards from its picture. To use one of these cards without the whole file, follow Single cards under Setup. Some buttons open a pop-up. The repository contains the pop-ups for the living room, the TV and the fan. Other pop-ups, such as those for music, lights and the remaining rooms, are not included yet, so their buttons do nothing.

Greeting and notifications

The greeting changes with the time of day, and the next calendar event appears above it. The Origami Notifications card is next to the greeting.

How it works

The greeting and the event line above it form a single Paper Buttons Row. The event line shows the current or next event from calendar.household, and its text comes from the calendar's message attribute. To use another entity, change the entity and remove attribute: message. You can also delete the event line and keep only the greeting.
Origami Notifications shows Home Assistant's notifications, repairs and updates without any configuration. Each entity that you add to the card appears only when it is relevant, for example a timer while it runs. In this example, the card watches weather warnings, a calendar, a pizza timer, the oven, the vacuum and the dinner sensor.
hide_when_empty is set to false, so the card also shows the weather and upcoming events after its entries. When there are no entries, the card shows only the weather and the events. With the default value true, the card is hidden when there is nothing to show.
When the card has several entries, it switches to the next one every 3 seconds. Tap the card to open the full list.

Entities

Entity	Purpose
`sensor.greetings`	The greeting, from the helpers
`calendar.household`	The event above the greeting. The notifications card shows events one day in advance.
`weather.home`	Rain, snow, thunderstorms and frost in the forecast, and the current weather
`sensor.dwd_*`, `timer.pizza`, `sensor.oven_ready_in`, `vacuum.robot`, `sensor.dinner`	These are examples. The card accepts almost any entity, as its README explains.

All of these entities are optional.

YAML

The greeting and the notifications card share a grid card with two columns. The grid needs Paper Buttons Row, Origami Notifications and sensor.greetings from the helpers.

type: grid
square: false
columns: 2
cards:
  - type: custom:paper-buttons-row
    extra_styles: ':host { display: block; height: 100% }'
    styles:
      flex-direction: column
      justify-content: center
      height: 100%
      gap: var(--ha-space-1)
    base_config:
      layout: state
      tap_action:
        action: none
      styles:
        button:
          min-height: unset
          padding: 0px
          align-self: flex-start
          justify-content: flex-start
          pointer-events: none
        state:
          padding: 0px
    buttons:
      - entity: calendar.household
        state:
          attribute: message
        styles:
          state:
            font-size: var(--ha-font-size-s)
            font-weight: var(--ha-font-weight-bold)
            color: var(--secondary-text-color)
            white-space: nowrap
            overflow: hidden
            text-overflow: ellipsis
            max-width: 100px
      - entity: sensor.greetings
        state:
          case: first
        styles:
          state:
            font-size: var(--ha-font-size-l)
            font-weight: var(--ha-font-weight-bold)
            white-space: nowrap
            overflow: hidden
            text-overflow: ellipsis
  - type: custom:origami-notifications
    entities:
      - sensor.dwd_current_warning_level
      - sensor.dwd_advance_warning_level
      - entity: calendar.household
        before:
          days: 1
      - timer.pizza
      - entity: sensor.oven_ready_in
        type: countdown
        name: Oven
      - vacuum.robot
      - entity: sensor.dinner
        actions:
          - label: Open recipe
            tap_action:
              action: url
              url_path: https://tandoor.dev
    weather: weather.home
    hide_when_empty: false
    rotate: 3
    css: |
      :host {
        --origami-pad: var(--ha-space-4);
        --origami-gap: var(--ha-space-4);
        --origami-tile: var(--ha-space-9, 36px);
        --origami-icon: var(--icon-size-m);
        --origami-radius: var(--radius-inner);
        --origami-card-bg: var(--fill-subtle);
        --origami-row-bg: var(--fill-subtle);
        --accent-color: var(--fill-active);
        --ha-tile-info-primary-font-size: var(--ha-font-size-m);
        --ha-tile-info-primary-font-weight: var(--ha-font-weight-bold);
        --ha-tile-info-secondary-font-size: var(--ha-font-size-s);
        --ha-tile-info-secondary-font-weight: var(--ha-font-weight-bold);
        --ha-tile-info-secondary-color: var(--secondary-text-color);
      }
      ha-card { box-shadow: none; }
      .texts { min-height: calc(var(--origami-tile) + 2 * var(--origami-pad)); }
      .slide { gap: var(--ha-space-1); }
      .icon {
        border-radius: var(--radius-inner);
        background: color-mix(in srgb, var(--tile-color) var(--tint-strength), var(--ha-card-background, var(--card-background-color)));
        box-shadow: var(--ha-card-box-shadow, none);
      }
      .head .icon.idle { color: var(--primary-text-color); }
      .badge {
        top: -6px;
        inset-inline-end: -6px;
        min-width: 20px;
        height: 20px;
        padding: 0 6px;
        border-radius: 10px;
        font-size: 12px;
        font-weight: var(--ha-font-weight-bold);
        box-shadow: none;
      }
      .list { gap: var(--ha-space-2); }
      .row { padding: var(--ha-space-3); }
      .row .title {
        font-size: var(--ha-font-size-m);
        font-weight: var(--ha-font-weight-bold);
      }
      .row .message { font-size: var(--ha-font-size-s); }

The menu comes from Origami Header, a card that the dashboard does not need at all. It exists to solve one very specific problem. Every other way to hide the Home Assistant header still shows it for a moment while the page loads. The flash is short, but it is more annoying than it should be. Origami Header truly hides the header and adds a few neat extras, such as this menu. Because the card is a bit hacky, treat it as experimental. In this dashboard, More in the navigation bar opens the menu from the top of the screen.

How it works

The menu is an Origami Header card with mode: menu, and you decide what it contains. This example contains a server card and buttons for the File editor app, automations, the sidebar and edit mode. If you do not use the File editor app, change or delete the Files button.
The server card shows a status, the uptime, the processor load and the memory use. Tap the processor or memory value to open its details. Tap anywhere else on the card to open the server pop-up, which is not included yet.

The status consists of an icon and a short message. The icon shows the overall state, and the message gives the reason, for example Backup due.

Icon	Meaning
Green check	Everything is fine.
Arrow in the accent color	Updates are available.
Orange	The disk is more than 80% full, the memory use is above 85%, the processor load is above 80%, the last automatic backup is older than 3 days, or System Monitor sends no data.
Red	The disk is more than 90% full, the memory use or processor load is above 95%, or the last automatic backup is older than 7 days.

Entities

Entity	Purpose
`sensor.system_monitor_*`	The processor load, memory use, disk use and uptime, from System Monitor. Without these sensors, the status shows No data.
`sensor.backup_last_successful_automatic_backup`	The backup check. Without this sensor, the card does not check backups.

YAML

The menu is one Origami Header card with a Paper Buttons Row inside. It needs Origami Header, which step 5 of the setup installs, and Paper Buttons Row.

type: custom:origami-header-card
mode: menu
position: top
layout: grid
all_users: true
buttons:
  - name: Files
    icon: mdi:folder-outline
    tap_action:
      action: navigate
      navigation_path: /app/core_configurator
  - name: Autom.
    icon: mdi:robot-outline
    tap_action:
      action: navigate
      navigation_path: /config/automation/dashboard
  - name: Menu
    icon: mdi:menu
    special: sidebar
  - name: Edit
    icon: mdi:pencil-outline
    special: edit
cards:
  type: custom:paper-buttons-row
  extra_styles: '.flex-box:active { transform: scale(var(--press-scale)) }'
  styles:
    position: relative
    gap: var(--ha-space-3)
    padding: var(--ha-space-4) var(--ha-space-5) var(--ha-space-4) var(--ha-space-4)
    background-color: var(--ha-card-background)
    border-radius: var(--ha-card-border-radius)
    box-shadow: var(--ha-card-box-shadow)
  base_config:
    layout: name|state
    tooltip: false
    styles:
      button:
        flex-direction: column
        padding: 0px
      name:
        padding: 0px
        white-space: nowrap
        font-weight: var(--ha-font-weight-bold)
        line-height: var(--ha-line-height-normal)
      state:
        padding: 0px
        margin-top: var(--ha-space-1)
        white-space: nowrap
        font-size: 12px
        font-weight: var(--ha-font-weight-medium)
        line-height: var(--ha-line-height-condensed)
        color: var(--secondary-text-color)
  buttons:
    # An invisible overlay opens the server pop-up when the card is tapped. CPU and RAM have their own tap actions.
    - layout: name
      name: ' '
      tap_action:
        action: navigate
        navigation_path: '#popup_server'
      styles:
        button:
          position: absolute
          inset: 0px
    # Status icon for ok, info (updates), warn and crit
    - layout: icon
      icon: mdi:check-bold
      state: >-
        {%- set c = states('sensor.system_monitor_processor_use') | float(-1) -%}
        {%- set r = states('sensor.system_monitor_memory_usage') | float(-1) -%}
        {%- set s = states('sensor.system_monitor_disk_usage') | float(-1) -%}
        {%- set b = as_timestamp(states('sensor.backup_last_successful_automatic_backup'), default=none) -%}
        {%- set a = (now().timestamp() - b) if b is not none else 0 -%}
        {%- set u = states.update | selectattr('state', 'eq', 'on') | list | count -%}
        {%- if s > 90 or r > 95 or c > 95 or a > 604800 -%}crit
        {%- elif s > 80 or r > 85 or c > 80 or a > 259200 or (c < 0 and r < 0 and s < 0) -%}warn
        {%- elif u > 0 -%}info
        {%- else -%}ok
        {%- endif -%}
      state_icons:
        info: mdi:arrow-up-thick
        warn: mdi:exclamation-thick
        crit: mdi:close-thick
      state_styles:
        info:
          button:
            color: var(--accent-color)
        warn:
          button:
            color: var(--warning-color)
        crit:
          button:
            color: var(--error-color)
      tap_action:
        action: none
      styles:
        button:
          color: var(--success-color)
          pointer-events: none
        icon:
          display: flex
          align-items: center
          justify-content: center
          width: var(--control-height-icon)
          height: var(--control-height-icon)
          border-radius: var(--radius-inner)
          background-color: currentColor
          box-shadow: 0 0 0 5px color-mix(in srgb, currentColor 12%, transparent)
          --mdc-icon-size: var(--icon-size-xs)
          --icon-primary-color: var(--text-color-active)
    # Status text and uptime
    - name: >-
        {%- set c = states('sensor.system_monitor_processor_use') | float(-1) -%}
        {%- set r = states('sensor.system_monitor_memory_usage') | float(-1) -%}
        {%- set s = states('sensor.system_monitor_disk_usage') | float(-1) -%}
        {%- set b = as_timestamp(states('sensor.backup_last_successful_automatic_backup'), default=none) -%}
        {%- set a = (now().timestamp() - b) if b is not none else 0 -%}
        {%- set u = states.update | selectattr('state', 'eq', 'on') | list | count -%}
        {%- if s > 90 -%}Disk almost full
        {%- elif r > 95 -%}Memory low
        {%- elif c > 95 -%}CPU high
        {%- elif a > 259200 -%}Backup due
        {%- elif s > 80 -%}Disk almost full
        {%- elif r > 85 -%}Memory low
        {%- elif c > 80 -%}CPU high
        {%- elif c < 0 and r < 0 and s < 0 -%}No data
        {%- elif u > 0 -%}{{ u }} {{ 'update' if u == 1 else 'updates' }}
        {%- else -%}All good
        {%- endif -%}
      state: >-
        {%- set n = as_timestamp(states('sensor.system_monitor_last_boot'), default=none) -%}
        {%- set d = [(now().timestamp() - n) | int, 0] | max if n is not none else -1 -%}
        {%- if d < 0 -%}Uptime unknown
        {%- elif d >= 86400 -%}Up {{ d // 86400 }} {{ 'day' if d < 172800 else 'days' }}
        {%- elif d >= 3600 -%}Up {{ d // 3600 }} {{ 'hour' if d < 7200 else 'hours' }}
        {%- else -%}Up {{ [d // 60, 1] | max }} {{ 'minute' if d < 120 else 'minutes' }}
        {%- endif -%}
      tap_action:
        action: none
      styles:
        button:
          flex: 1
          min-width: 0px
          align-items: flex-start
          pointer-events: none
        name:
          max-width: 100%
          overflow: hidden
          text-overflow: ellipsis
          font-size: var(--ha-font-size-l)
        state:
          max-width: 100%
          overflow: hidden
          text-overflow: ellipsis
    # CPU and memory, colored when high
    - name: >-
        {%- set v = states('sensor.system_monitor_processor_use') | float(none) -%}
        {{ ((v | round(0) | int) ~ ' %') if v is not none else '–' }}
      state: CPU
      tap_action:
        action: more-info
        entity: sensor.system_monitor_processor_use
      styles:
        button:
          min-width: 44px
          align-items: flex-end
        name:
          font-size: var(--ha-font-size-m)
          font-variant-numeric: tabular-nums
          color: >-
            {%- set v = states('sensor.system_monitor_processor_use') | float(0) -%}
            {{ 'var(--error-color)' if v > 95 else ('var(--warning-color)' if v > 80 else 'var(--primary-text-color)') }}
    - name: >-
        {%- set v = states('sensor.system_monitor_memory_usage') | float(none) -%}
        {{ ((v | round(0) | int) ~ ' %') if v is not none else '–' }}
      state: RAM
      tap_action:
        action: more-info
        entity: sensor.system_monitor_memory_usage
      styles:
        button:
          min-width: 44px
          align-items: flex-end
        name:
          font-size: var(--ha-font-size-m)
          font-variant-numeric: tabular-nums
          color: >-
            {%- set v = states('sensor.system_monitor_memory_usage') | float(0) -%}
            {{ 'var(--error-color)' if v > 95 else ('var(--warning-color)' if v > 85 else 'var(--primary-text-color)') }}
css: |-
  .scrim {
    backdrop-filter: blur(14px);
    background:
      linear-gradient(var(--card-shadow-color), var(--card-shadow-color)),
      color-mix(in srgb, var(--primary-background-color) 28%, transparent);
  }
  .sheet {
    padding: var(--ha-space-5) var(--ha-space-5) var(--ha-space-6, 24px) var(--ha-space-5);
    gap: var(--ha-space-5);
    box-shadow: var(--ha-card-box-shadow);
  }
  .buttons {
    gap: var(--ha-space-3);
  }
  .button {
    background: none;
    box-shadow: none;
    padding: 0 !important;
    gap: 12px !important;
  }
  .button ha-ripple {
    display: none;
  }
  .sheet .buttons .button ha-icon {
    width: 100%;
    height: 72px;
    border-radius: var(--radius-inner);
    color: var(--color, var(--primary-text-color));
    background: var(--fill-subtle);
  }
  .button:active ha-icon {
    transform: scale(var(--press-scale));
  }
  .name {
    display: block;
    white-space: nowrap;
    font-size: 13px;
  }

Other cards, such as buttons and tiles, can open the menu with this tap action. More in the navigation bar uses the same action.

tap_action:
  action: fire-dom-event
  origami_header: toggle

Weather

The weather card is an Origami Weather card. The card has many options that this example does not use, such as an animated sky, forecasts, gauges and your own images. This example uses a simple setup with one color for each weather condition.

Configuration

background_mode is set to color, and background_thresholds sets a color for each condition in light and dark mode.
The sun, moon, clouds, stars, birds, balloons and planes are turned off. Rain, snow, hail and thunderstorms still appear, because precipitation_effects is on by default.
The house is the card's demo house. The Origami Weather README explains how to create a picture of your own home in the same style.
The top-left corner shows the next sunset, or the next sunrise while the sun is down. The bottom-left corner shows the temperature and condition from the weather entity. To use your own temperature sensor, set it as the entity of the button that shows the temperature, and delete attribute: temperature.

Entities

Entity	Purpose
`weather.home`	The condition, color and temperature
`sun.sun`	The next sunset or sunrise

YAML

The weather is a single Origami Weather card, and it needs no helpers.

type: custom:origami-weather
weather_entity: weather.home
sun_enabled: false
moon_enabled: false
color_mode: theme
card_height: 160px
card_padding: 20px
card_offset: 16px 0px 12px 0px
# One color for each condition instead of the sky. Clouds and the other effects are off.
# Rain, snow, hail and thunderstorms still appear.
background_mode: color
background_threshold_entity: weather.home
background_thresholds:
  - value: sunny
    color: '#e7e2d9'
    color_dark: '#24211d'
  - value: clear-night
    color: '#dbdce1'
    color_dark: '#15181f'
  - value: partlycloudy
    color: '#e0deda'
    color_dark: '#1c2023'
  - value: cloudy
    color: '#d3d4d6'
    color_dark: '#222324'
  - value: fog
    color: '#e6e6e5'
    color_dark: '#272829'
  - value: windy
    color: '#dadfdd'
    color_dark: '#1c201e'
  - value: windy-variant
    color: '#d5dad9'
    color_dark: '#1a1f1e'
  - value: rainy
    color: '#cdd2d6'
    color_dark: '#181e22'
  - value: pouring
    color: '#c8cdd2'
    color_dark: '#14191e'
  - value: lightning
    color: '#cfced3'
    color_dark: '#1c1b21'
  - value: lightning-rainy
    color: '#cacacf'
    color_dark: '#18171e'
  - value: snowy
    color: '#e6eaed'
    color_dark: '#252b2e'
  - value: snowy-rainy
    color: '#d8dddf'
    color_dark: '#1f2527'
  - value: hail
    color: '#d2d9da'
    color_dark: '#1c2324'
  - value: exceptional
    color: '#ded8d2'
    color_dark: '#27221f'
cloud_effects: false
night_sky_effects: false
bird_effects: false
balloon_effects: false
plane_effects: false
grid_options:
  rows: auto
  columns: 12
button_containers:
  # The house is 20px from the top, right and bottom edges. The drawing
  # does not fill its picture, so the offsets are negative.
  - position: custom
    position_anchor: top-right
    position_x: -32px
    position_y: -10px
    custom_width: 168px
    image: demo-home-image
  # Next sunset, or sunrise while the sun is down
  - position: custom
    position_anchor: top-left
    button_gap: 6px
    buttons:
      - entity: sun.sun
        visibility:
          - condition: state
            entity: sun.sun
            state: above_horizon
        elements:
          - type: text
            size: 12px
            weight: '500'
            color: var(--secondary-text-color)
            text: Sunset
          - type: text
            size: 12px
            weight: '500'
            color: var(--primary-text-color)
            entity: sun.sun
            attribute: next_setting
      - entity: sun.sun
        visibility:
          - condition: state
            entity: sun.sun
            state: below_horizon
        elements:
          - type: text
            size: 12px
            weight: '500'
            color: var(--secondary-text-color)
            text: Sunrise
          - type: text
            size: 12px
            weight: '500'
            color: var(--primary-text-color)
            entity: sun.sun
            attribute: next_rising
  # Temperature and condition
  - position: custom
    position_anchor: bottom-left
    gap: 5px
    buttons:
      - entity: weather.home
        width: 100%
        elements:
          - type: text
            size: 48px
            weight: '700'
            color: var(--primary-text-color)
            attribute: temperature
            precision: 0
            format: °
      - entity: weather.home
        elements:
          - type: text
            size: 12px
            weight: '500'
            color: var(--primary-text-color)

Favorites

The favorites are tiles for devices and tasks that are relevant at the moment. Most tiles appear only at certain times or in certain states. The tiles use Bubble Card with the Header and Tiles modules.

How it works

All tiles are sub-buttons of one Bubble card. A tile with visibility conditions appears only while its conditions are met. A hidden tile leaves no gap.
In this example, the oven tile is always first and appears while sensor.oven is not Off. The fan tile appears while the fan runs or when the living room or bedroom is warmer than 24°. Music appears from 22:00 to 4:00, dinner from 14:00 to 21:00 with a photo of the recipe, and the bath from 11:00 to 23:00 and whenever it runs.
The vacuum and printer tiles are always visible. While the vacuum is cleaning, its tile shows the progress and moves to the front. The bath and printer tiles show the remaining minutes while they run.
Tap the fan, bath or printer tile to turn it on or off. The music, oven and vacuum tiles open pop-ups, and the dinner tile opens Tandoor. Hold a tile to open the details for its entity.
To add a tile, copy an existing tile and change its entity and visibility conditions.

Entities

Tile	Entities
Oven	`sensor.oven`
Vacuum	`vacuum.robot`, `number.robot_cleaning_progress`
Fan	`fan.bedroom`, `sensor.living_room_temperature`, `sensor.bedroom_temperature`
Dinner	`sensor.dinner` with a `recipe.image` attribute, for example from Tandoor
Music	`media_player.bedroom`
Bath	`input_boolean.bath_time`, `input_datetime.bath_time_end`
Printer	`switch.printer`, `input_datetime.printer_end`

All of these entities are examples. If your vacuum has no progress entity, delete the name template from the vacuum tile, or the tile shows Error.

YAML

The favorites are two Bubble cards. The first one is the header with the All button.

type: custom:bubble-card
card_type: separator
name: Favorites
modules:
  - origami_header
origami_header:
  icon_size: var(--icon-size-m)
grid_options:
  columns: full
  rows: auto
sub_button:
  main:
    - name: All
      icon: mdi:chevron-right
      show_name: true
      content_layout: icon-right
      tap_action:
        action: navigate
        navigation_path: '#popup_favorites'

The second card contains the tiles.

type: custom:bubble-card
card_type: sub-buttons
modules:
  - origami_tiles
grid_options:
  columns: full
  rows: auto
sub_button:
  bottom:
    # Music, from 22:00 to 4:00
    - name: Bedroom
      entity: media_player.bedroom
      icon: mdi:speaker
      force_icon: true
      origami_tiles:
        state: Music
        color: var(--state-media_player-active-color)
      visibility:
        - condition: time
          after: '22:00'
          before: '03:59:59'
      tap_action:
        action: navigate
        navigation_path: '#popup_music'
      hold_action:
        action: more-info
    # Fan, while it runs or when the living room or the bedroom is above 24°
    - name: Fan
      entity: fan.bedroom
      icon: mdi:fan
      origami_tiles:
        state:
          'on': ${attr.percentage} %
          'off': 'Off'
      visibility:
        - condition: state
          entity: fan.bedroom
          state_not:
            - unavailable
            - unknown
        - condition: or
          conditions:
            - condition: state
              entity: fan.bedroom
              state: 'on'
            - condition: numeric_state
              entity: sensor.living_room_temperature
              above: 24
            - condition: numeric_state
              entity: sensor.bedroom_temperature
              above: 24
      tap_action:
        action: toggle
      hold_action:
        action: more-info
    # Dinner, with the recipe photo as the icon
    - name: Cooking
      entity: sensor.dinner
      icon: mdi:chef-hat
      origami_tiles:
        state: Dinner
        image: ${attr.recipe?.image}
      visibility:
        - condition: state
          entity: sensor.dinner
          state_not:
            - unknown
            - unavailable
        - condition: time
          after: '14:00'
          before: '20:59:59'
      tap_action:
        action: url
        url_path: https://tandoor.dev
      hold_action:
        action: more-info
    # Oven, only while it is on, and always first
    - name: Oven
      entity: sensor.oven
      icon: mdi:toaster-oven
      origami_tiles:
        color: var(--state-climate-heat-color)
        order: -2
      visibility:
        - condition: state
          entity: sensor.oven
          state_not: 'Off'
      tap_action:
        action: navigate
        navigation_path: '#popup_kitchen'
      hold_action:
        action: more-info
    # Vacuum. While it cleans, the progress replaces the name.
    - name: Vacuum
      entity: vacuum.robot
      icon: mdi:robot-vacuum
      force_icon: true
      origami_tiles:
        name: >-
          ${(p => Number.isNaN(p) || p < 0 ? 'Error'
          : ['docked', 'returning'].includes(state) || p >= 99 ? 'Vacuum'
          : p + ' %')(Math.round(states('number.robot_cleaning_progress')))}
        state:
          docked: 'Off'
          idle: 'Off'
          cleaning: Vacuum
        order:
          cleaning: -1
      tap_action:
        action: navigate
        navigation_path: '#popup_vacuum'
      hold_action:
        action: more-info
    # Bath, with the remaining minutes while it runs
    - name: Bath
      entity: input_boolean.bath_time
      icon: mdi:shower
      origami_tiles:
        name:
          'on': ${minutesUntil('input_datetime.bath_time_end')} min
        state:
          'on': Running
          'off': Ready
        color:
          'on': var(--blue-color)
      visibility:
        - condition: or
          conditions:
            - condition: state
              entity: input_boolean.bath_time
              state: 'on'
            - condition: time
              after: '11:00'
              before: '22:59:59'
      tap_action:
        action: toggle
      hold_action:
        action: more-info
    # Printer, with the remaining minutes while it prints
    - name: Printer
      entity: switch.printer
      icon: mdi:printer-outline
      origami_tiles:
        name:
          'on': ${minutesUntil('input_datetime.printer_end')} min
        state:
          'on': Running
          'off': 'Off'
        name_color:
          'on': initial
      tap_action:
        action: toggle
      hold_action:
        action: more-info

Rooms

Each room has a card. The first four rooms are always visible, and All rooms shows the others.

How it works

Each room card is a single Paper Buttons Row. Tap anywhere on the card to open the room's pop-up.
The icon is colored while the room's light is on.
Below the name, a colored dot shows the room's temperature, from blue when it is cold to red when it is hot. A window icon follows if the room has a window contact. The temperature and humidity come last.
The rooms header shows the average temperature and the number of open windows. Tap one of these values or the arrow to open or close the climate table.
To add a room, copy a card and change its entities, name, icon and pop-up. Add a sensor.climate_<room> for the room in packages/origami.yaml, and add the room to the lists in that file. The rooms after the fourth are conditional cards, which appear while input_boolean.all_rooms is on.

Entities

Entity	Purpose
`light.<room>`	The icon color
`sensor.climate_<room>`	The dot color, temperature and humidity, from the helpers
`binary_sensor.<room>_window`	The window icon. In the living room, this is a balcony door.
`sensor.climate_home`	The average temperature and the open windows in the header
`input_boolean.all_rooms`	The All rooms button

YAML

The rooms header and All rooms are Bubble cards, and each room card is a Paper Buttons Row. All of them read helpers. The rooms header is the first card.

type: custom:bubble-card
card_type: separator
name: Rooms
modules:
  - origami_header
origami_header:
  value_style: chip
  icon_size: var(--icon-size-l)
grid_options:
  columns: full
  rows: auto
sub_button:
  main:
    - name: Temperature
      entity: sensor.climate_home
      icon: mdi:thermometer
      origami_header:
        name: ${attr.temperature_average}°
      tap_action:
        action: perform-action
        perform_action: input_boolean.toggle
        target:
          entity_id: input_boolean.room_climate_card
      hold_action:
        action: more-info
    - name: Windows
      entity: sensor.climate_home
      icon: mdi:window-closed-variant
      state_content: windows_open
      origami_header:
        icon: "${attr.windows_open > 0 ? 'mdi:window-open-variant' : ''}"
        color: "${attr.windows_open > 0 ? 'var(--state-binary_sensor-window-on-color)' : 'var(--secondary-text-color)'}"
        background: "${attr.windows_open > 0 ? 'var(--tint)' : ''}"
      tap_action:
        action: perform-action
        perform_action: input_boolean.toggle
        target:
          entity_id: input_boolean.room_climate_card
      hold_action:
        action: more-info
    - name: Table
      entity: input_boolean.room_climate_card
      icon: mdi:chevron-down
      show_background: false
      origami_header:
        icon:
          'on': mdi:chevron-up
      tap_action:
        action: toggle
      hold_action:
        action: more-info

The living room's card follows. The dashboard puts the room cards in a grid card with two columns.

type: custom:paper-buttons-row
styles:
  position: relative
  display: flex
  flex-wrap: wrap
  justify-content: flex-start
  align-items: center
  padding: var(--ha-space-4)
  background-color: var(--fill-subtle)
  border-radius: var(--ha-card-border-radius)
base_config:
  layout: icon
  active: []
  tap_action:
    action: navigate
    navigation_path: '#popup_living_room'
  styles:
    button:
      padding: 0px
      margin-bottom: var(--ha-space-3)
      justify-content: flex-start
      pointer-events: none
    name:
      padding: 0px
      font-size: var(--ha-font-size-m)
      font-weight: var(--ha-font-weight-bold)
      white-space: nowrap
    state:
      padding: 0px
      font-size: var(--ha-font-size-s)
      font-weight: var(--ha-font-weight-medium)
      color: var(--secondary-text-color)
buttons:
  # Invisible overlay that catches the tap for the whole card
  - entity: light.living_room
    layout: name
    name: false
    styles:
      button:
        z-index: 3
        pointer-events: all
        position: absolute
        top: 0px
        left: 0px
        width: 100%
        height: 100%
        border-radius: var(--ha-card-border-radius)
  # Icon, colored while the room's lights are on
  - entity: light.living_room
    icon: mdi:sofa
    state_styles:
      'on':
        icon:
          background-color: var(--tint)
          color: var(--state-light-active-color)
    styles:
      button:
        width: calc(100% - var(--control-height-icon))
      icon:
        --mdc-icon-size: var(--icon-size-m)
        width: var(--tile-size)
        height: var(--tile-size)
        display: flex
        justify-content: center
        align-items: center
        border-radius: var(--radius-inner)
        background-color: var(--ha-card-background)
        box-shadow: var(--ha-card-box-shadow)
        transition: var(--transition-interactive)
  - icon: mdi:chevron-right
    styles:
      button:
        width: var(--control-height-icon)
        justify-content: center
      icon:
        --mdc-icon-size: var(--icon-size-l)
        opacity: var(--opacity-quiet)
  - name: Living
    layout: name
    styles:
      button:
        width: 100%
        margin: var(--ha-space-2) 0px 0px 0px
  # Comfort dot, window, temperature and humidity
  - layout: icon
    icon: mdi:circle
    styles:
      button:
        margin: var(--ha-space-2) var(--ha-space-2) 0px 0px
      icon:
        --mdc-icon-size: var(--dot-size)
        margin: -3px 0px 0px 0px
        color: '{{ state_attr("sensor.climate_living_room", "color_code") }}'
  - entity: binary_sensor.living_room_balcony_door
    layout: icon
    icon: mdi:window-closed-variant
    state_icons:
      'on': mdi:window-open-variant
      'off': mdi:window-closed-variant
    styles:
      button:
        margin: var(--ha-space-2) var(--ha-space-2) 0px 0px
      icon:
        --mdc-icon-size: var(--dot-size)
        margin: -3px 0px 0px 0px
  - entity: sensor.climate_living_room
    layout: state
    state:
      attribute: temperature
      postfix: ° |
    styles:
      button:
        margin: var(--ha-space-2) var(--ha-space-1) 0px 0px
  - entity: sensor.climate_living_room
    layout: state
    state:
      attribute: humidity
      postfix: '%'
    styles:
      button:
        margin: var(--ha-space-2) 0px 0px 0px

All rooms is the last card. It turns input_boolean.all_rooms on and off, and the rooms after the fourth are conditional cards that appear while this toggle is on.

type: custom:bubble-card
card_type: separator
modules:
  - origami_header
origami_header:
  icon_size: var(--icon-size-l)
  icon_color: color-mix(in srgb, var(--primary-text-color) 50%, transparent)
grid_options:
  columns: full
  rows: auto
sub_button:
  main:
    - name: All rooms
      entity: input_boolean.all_rooms
      icon: mdi:chevron-down
      show_name: true
      content_layout: icon-right
      origami_header:
        name:
          'on': Fewer rooms
        icon:
          'on': mdi:chevron-up
      tap_action:
        action: toggle
      hold_action:
        action: more-info
styles: |-
  ha-card .bubble-sub-button-container {
    justify-content: center !important;
    margin: 0 !important;
  }
  ha-card .bubble-sub-button-container .bubble-sub-button.content-icon-right .bubble-sub-button-icon:not(.hidden) {
    margin-left: var(--ha-space-1) !important;
  }

Climate table

The climate table shows all rooms at once. It opens under the rooms header.

How it works

Tap the arrow or one of the values in the rooms header to open or close the table.
Each row shows one room with its colored dot, name, window, thermostat, temperature and humidity. The living room row also shows the front door.
An open window or door turns cyan, and a thermostat that is heating turns deep orange. Arrows mark the warmest and coldest rooms and the most and least humid rooms.
Tap a room to open its thermostat. Tap a window or the door to open its contact sensor.
The table is a single Paper Buttons Row with a grid layout. Keep the room names short so that the table fits on a phone. To add a room, copy a row and increase the 6 in repeat(6, …).

Entities

Entity	Purpose
`sensor.climate_<room>`	The temperature, humidity, arrows and dot color
`binary_sensor.<room>_window`, `binary_sensor.front_door`	The windows and the door
`climate.<room>`	The target temperature and whether the thermostat is heating
`input_boolean.room_climate_card`	Whether the table is open

If a room has no thermostat or window contact, delete that button. The cell stays empty, as in the office row.

YAML

The table is a Paper Buttons Row inside a grid card, and it reads the room helpers. The grid's visibility condition shows the table while input_boolean.room_climate_card is on. The header above the table is the rooms header from the Rooms section.

type: grid
square: false
columns: 1
visibility:
  - condition: state
    entity: input_boolean.room_climate_card
    state: 'on'
cards:
  - type: custom:paper-buttons-row
    extra_styles: |
      @keyframes fadeInUp { to { opacity: 1; transform: translateY(0) } }
    styles:
      display: grid
      grid-template-columns: auto auto auto 1fr auto auto
      grid-template-rows: repeat(6, var(--control-height-icon))
      column-gap: var(--ha-space-1)
      padding: 0px var(--ha-space-2)
      margin-bottom: var(--ha-space-5)
      border-radius: var(--ha-card-border-radius)
      opacity: 0
      transform: translateY(10px)
      animation: fadeInUp var(--duration-slow) ease-in forwards
      background-image: >-
        repeating-linear-gradient(to bottom, transparent, transparent var(--control-height-icon),
        var(--fill-subtle) var(--control-height-icon), var(--fill-subtle) calc(var(--control-height-icon) * 2))
    base_config:
      layout: icon|name
      tap_action:
        action: more-info
      state_icons:
        warmest: mdi:arrow-up
        coldest: mdi:arrow-down
        most_humid: mdi:arrow-up
        driest: mdi:arrow-down
      state_styles:
        'on':
          button:
            background-color: var(--tint)
            color: var(--state-binary_sensor-window-on-color)
          icon:
            color: var(--state-binary_sensor-window-on-color)
        heating:
          button:
            background-color: var(--tint)
            color: var(--state-climate-heat-color)
          icon:
            color: var(--state-climate-heat-color)
          name:
            color: var(--primary-text-color)
        warmest:
          button:
            background-color: var(--fill-subtle)
            color: var(--primary-text-color)
          icon:
            opacity: 1
        most_humid:
          button:
            background-color: var(--fill-subtle)
            color: var(--primary-text-color)
          icon:
            opacity: 1
        coldest:
          icon:
            opacity: 1
        driest:
          icon:
            opacity: 1
      styles:
        button:
          padding: 0px 6px
          min-height: var(--icon-size-m)
          justify-content: center
          border-radius: var(--radius-inner)
        icon:
          --mdc-icon-size: var(--icon-size-2xs)
          margin-right: var(--ha-space-1)
          display: flex
          align-items: center
          justify-content: center
        name:
          padding: 0px
          font-size: var(--ha-font-size-s)
          font-weight: var(--ha-font-weight-bold)
          font-variant-numeric: tabular-nums
          white-space: nowrap
        state:
          padding: 0px
    buttons:
      # Living
      - entity: sensor.climate_living_room
        icon: mdi:circle
        name: Living
        tap_action:
          entity: climate.living_room
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_living_room", "color_code") }}'
      - entity: binary_sensor.living_room_balcony_door
        layout: icon
        state_icons:
          'on': mdi:window-open-variant
          'off': mdi:window-closed-variant
        styles:
          button:
            grid-column: 2
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: climate.living_room
        icon: mdi:thermostat
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: hvac_action
        styles:
          button:
            grid-column: 3
            color: var(--secondary-text-color)
      - entity: binary_sensor.front_door
        layout: icon
        state_icons:
          'on': mdi:door-open
          'off': mdi:door-closed
        styles:
          button:
            grid-column: 4
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: sensor.climate_living_room
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        tap_action:
          entity: climate.living_room
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_living_room
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        tap_action:
          entity: climate.living_room
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      # Bedroom
      - entity: sensor.climate_bedroom
        icon: mdi:circle
        name: Bed
        tap_action:
          entity: climate.bedroom
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_bedroom", "color_code") }}'
      - entity: binary_sensor.bedroom_window
        layout: icon
        state_icons:
          'on': mdi:window-open-variant
          'off': mdi:window-closed-variant
        styles:
          button:
            grid-column: 2
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: climate.bedroom
        icon: mdi:thermostat
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: hvac_action
        styles:
          button:
            grid-column: 3
            color: var(--secondary-text-color)
      - entity: sensor.climate_bedroom
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        tap_action:
          entity: climate.bedroom
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_bedroom
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        tap_action:
          entity: climate.bedroom
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      # Office
      - entity: sensor.climate_office
        icon: mdi:circle
        name: Office
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_office", "color_code") }}'
      - entity: sensor.climate_office
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_office
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      # Bath
      - entity: sensor.climate_bathroom
        icon: mdi:circle
        name: Bath
        tap_action:
          entity: climate.bathroom
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_bathroom", "color_code") }}'
      - entity: binary_sensor.bathroom_window
        layout: icon
        state_icons:
          'on': mdi:window-open-variant
          'off': mdi:window-closed-variant
        styles:
          button:
            grid-column: 2
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: climate.bathroom
        icon: mdi:thermostat
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: hvac_action
        styles:
          button:
            grid-column: 3
            color: var(--secondary-text-color)
      - entity: sensor.climate_bathroom
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        tap_action:
          entity: climate.bathroom
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_bathroom
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        tap_action:
          entity: climate.bathroom
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      # Kitchen
      - entity: sensor.climate_kitchen
        icon: mdi:circle
        name: Kitchen
        tap_action:
          entity: climate.kitchen
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_kitchen", "color_code") }}'
      - entity: binary_sensor.kitchen_window
        layout: icon
        state_icons:
          'on': mdi:window-open-variant
          'off': mdi:window-closed-variant
        styles:
          button:
            grid-column: 2
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: climate.kitchen
        icon: mdi:thermostat
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: hvac_action
        styles:
          button:
            grid-column: 3
            color: var(--secondary-text-color)
      - entity: sensor.climate_kitchen
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        tap_action:
          entity: climate.kitchen
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_kitchen
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        tap_action:
          entity: climate.kitchen
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      # WC
      - entity: sensor.climate_small_bathroom
        icon: mdi:circle
        name: WC
        tap_action:
          entity: climate.small_bathroom
        styles:
          button:
            grid-column: 1
            justify-content: flex-start
          icon:
            color: '{{ state_attr("sensor.climate_small_bathroom", "color_code") }}'
      - entity: binary_sensor.small_bathroom_window
        layout: icon
        state_icons:
          'on': mdi:window-open-variant
          'off': mdi:window-closed-variant
        styles:
          button:
            grid-column: 2
            padding: 0px
            width: var(--icon-size-m)
          icon:
            margin-right: 0px
      - entity: climate.small_bathroom
        icon: mdi:thermostat
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: hvac_action
        styles:
          button:
            grid-column: 3
            color: var(--secondary-text-color)
      - entity: sensor.climate_small_bathroom
        icon: mdi:thermometer
        name:
          attribute: temperature
          postfix: °
        state:
          attribute: temp_rank
        tap_action:
          entity: climate.small_bathroom
        styles:
          button:
            grid-column: 5
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)
      - entity: sensor.climate_small_bathroom
        icon: mdi:water-percent
        name:
          attribute: humidity
          postfix: ' %'
        state:
          attribute: humidity_rank
        tap_action:
          entity: climate.small_bathroom
        styles:
          button:
            grid-column: 6
            color: var(--secondary-text-color)
          icon:
            opacity: var(--opacity-muted)

Navigation bar

The navigation bar is a Navbar Card with buttons for music, the TV, the lights, the favorites and the menu. A card above the bar shows what is playing.

How it works

The music button turns light blue while a speaker is playing, and the TV button turns light blue while the TV is on. The lights button turns amber while a light is on. Badges on the music and lights buttons show how many speakers are playing and how many lights are on.
Hold Music to play or pause the active speaker, unless the speaker is playing TV audio. Tap TV to open the TV pop-up, or hold it to open the TV entity's controls.
Hold Lights to open a menu. The menu contains the living room scenes and a button that turns all lights on or off. The active scene is amber.
More opens the Origami Header menu. Administrators see a dot on this button while updates are available.
The card above the bar shows either the TV or the most relevant speaker, which comes from sensor.active_speaker.
In Navbar Card's [[[ ]]] templates, read a state with states['sensor.x'].state. The states('sensor.x') function only works in Jinja and in the ${ } templates of the Bubble Card modules.

The light scenes, which open when you hold Lights

Entities

Entity	Purpose
`sensor.active_speaker_count`, `sensor.lights_on_count`	The numbers on the badges, from the helpers
`sensor.active_speaker`	The card above the bar, from the helpers
`media_player.living_room_tv`, `media_player.tv_ump`	The TV button and the TV in the card above the bar
`light.all_lights`, `script.lights_toggle`	Turning all lights on or off
`scene.living_room_*`, `sensor.living_room_scene`	The scenes and the active scene

Except for the helpers, all of these entities are examples. Delete the buttons and scenes that you do not need.

YAML

The navigation bar and the card above it are one Navbar Card. It reads several helpers, such as sensor.active_speaker and sensor.lights_on_count. If you do not use Origami Header, delete the route under # Opens the Origami Header menu.

type: custom:navbar-card
routes:
  - label: Music
    icon: mdi:speaker
    icon_selected: mdi:speaker-play
    selected_color: var(--state-media_player-active-color)
    selected: "[[[ return Number(states['sensor.active_speaker_count']?.state) > 0; ]]]"
    tap_action:
      action: navigate
      navigation_path: '#popup_music'
    hold_action:
      action: custom-js-action
      code: |-
        [[[
          // Holding the button plays or pauses the active speaker. Music Assistant
          // owns the queue when it delivers the cover, so it gets the command.
          // This only works for music, so the TV sound is never paused by accident.
          const active = states['sensor.active_speaker'];
          const target = active?.state;
          const chip = active?.attributes?.chip ?? '';
          if (!states[target] || !/^(playing|paused)_/.test(chip)) return;
          const ma = `${target}_mass`;
          const entity_id = chip.endsWith('_art') && states[ma] ? ma : target;
          hass.callService('media_player', 'media_play_pause', { entity_id });
        ]]]
    badge:
      show: "[[[ return Number(states['sensor.active_speaker_count']?.state) > 0; ]]]"
      count: "[[[ return states['sensor.active_speaker_count']?.state ?? ''; ]]]"
  - label: TV
    icon: mdi:remote-tv
    selected_color: var(--state-media_player-active-color)
    selected: "[[[ return states['media_player.living_room_tv']?.state === 'on'; ]]]"
    tap_action:
      action: navigate
      navigation_path: '#popup_tv'
    hold_action:
      action: more-info
      entity: media_player.living_room_tv
  - label: Lights
    icon: mdi:lightbulb
    icon_selected: mdi:lightbulb-on
    selected_color: var(--state-light-active-color)
    selected: "[[[ return Number(states['sensor.lights_on_count']?.state) > 0; ]]]"
    tap_action:
      action: navigate
      navigation_path: '#popup_lights'
    hold_action:
      action: open-popup
    badge:
      show: "[[[ return Number(states['sensor.lights_on_count']?.state) > 0; ]]]"
      count: "[[[ return states['sensor.lights_on_count']?.state ?? ''; ]]]"
    popup:
      - label: "[[[ return states['light.all_lights']?.state === 'on' ? 'Turn off' : 'Turn on'; ]]]"
        icon: "[[[ return states['light.all_lights']?.state === 'on' ? 'mdi:lightbulb-group-off-outline' : 'mdi:lightbulb-group-outline'; ]]]"
        tap_action:
          action: perform-action
          perform_action: script.lights_toggle
      - label: Evening
        icon: mdi:weather-sunset-down
        selected: "[[[ return states['sensor.living_room_scene']?.state === 'evening'; ]]]"
        tap_action:
          action: perform-action
          perform_action: scene.turn_on
          target:
            entity_id: scene.living_room_evening
      - label: Dinner
        icon: mdi:food-fork-drink
        selected: "[[[ return states['sensor.living_room_scene']?.state === 'dinner'; ]]]"
        tap_action:
          action: perform-action
          perform_action: scene.turn_on
          target:
            entity_id: scene.living_room_dinner
      - label: Movie
        icon: mdi:theater
        selected: "[[[ return states['sensor.living_room_scene']?.state === 'movie'; ]]]"
        tap_action:
          action: perform-action
          perform_action: scene.turn_on
          target:
            entity_id: scene.living_room_movie
      - label: Late
        icon: mdi:moon-waning-crescent
        selected: "[[[ return states['sensor.living_room_scene']?.state === 'late'; ]]]"
        tap_action:
          action: perform-action
          perform_action: scene.turn_on
          target:
            entity_id: scene.living_room_late
      - label: Night
        icon: mdi:weather-night
        selected: "[[[ return states['sensor.living_room_scene']?.state === 'night'; ]]]"
        tap_action:
          action: perform-action
          perform_action: scene.turn_on
          target:
            entity_id: scene.living_room_night
  - label: Favorites
    icon: mdi:star
    tap_action:
      action: navigate
      navigation_path: '#popup_favorites'
  # Opens the Origami Header menu
  - label: More
    icon: mdi:dots-horizontal
    tap_action:
      action: fire-dom-event
      origami_header: toggle
    badge:
      show: "[[[ return !!user?.is_admin && Object.keys(states).some(id => id.startsWith('update.') && states[id].state === 'on'); ]]]"
media_player:
  album_cover_background: true
  desktop_position: bottom-right
  show: '[[[ return !navbar.isDesktop; ]]]'
  players:
    - entity: |-
        [[[
          // The Music Assistant twin when it delivers the cover (right artwork,
          // progress and skip), otherwise the speaker itself
          const active = states['sensor.active_speaker'];
          const target = states[active?.state] ? active.state : 'media_player.living_room';
          const ma = `${target}_mass`;
          return (active?.attributes?.chip ?? '').endsWith('_art') && states[ma] ? ma : target;
        ]]]
      show: |-
        [[[
          const active = states['sensor.active_speaker'];
          return !!active && !!states[active.state] && /^(playing|paused)_/.test(active.attributes?.chip ?? '');
        ]]]
      title: "[[[ return (states['sensor.active_speaker']?.attributes?.title ?? '').split(' | ')[0]; ]]]"
      subtitle: |-
        [[[
          const a = states['sensor.active_speaker']?.attributes ?? {};
          // CSS cannot read entity states, so the group state is passed to the stylesheet as a variable
          document.documentElement.style.setProperty('--navbar-player-group', a.group === 'yes' ? '1' : '0');
          return a.speaker ?? '';
        ]]]
      tap_action:
        action: navigate
        navigation_path: '#popup_music'
    - entity: media_player.tv_ump
      title: "[[[ return states['media_player.tv_ump']?.attributes?.media_title || 'TV'; ]]]"
      icon: "[[[ return states['media_player.tv_ump']?.attributes?.entity_picture ? null : 'mdi:television'; ]]]"
      subtitle: "[[[ return states['media_player.tv_ump']?.attributes?.app_name ?? ''; ]]]"
      tap_action:
        action: navigate
        navigation_path: '#popup_tv'
desktop:
  position: right
  mode: floating
  min_width: 700
  show_labels: popup_only
  show_popup_label_backgrounds: true
mobile:
  mode: floating
  show_labels: popup_only
haptic:
  url: false
  tap_action: true
layout:
  reflect_child_state: true
  auto_padding:
    enabled: true
    mobile_px: 100
    media_player_px: 84
styles: |
  /* Bar */
  :host {
    --navbar-background-color: var(--fill-subtle);
    --navbar-box-shadow: var(--navbar-shadow);
    --navbar-box-shadow-mobile-floating: var(--navbar-shadow);
    --navbar-box-shadow-desktop: var(--navbar-shadow-side, var(--navbar-shadow));
  }

  .navbar-card {
    gap: var(--ha-space-2) !important;
    padding: var(--ha-space-5) !important;
    backdrop-filter: var(--blur-strong);
    -webkit-backdrop-filter: var(--blur-strong);
    margin-bottom: 0px !important;
    border-radius: var(--ha-card-border-radius) var(--ha-card-border-radius) 0px 0px !important;
    border-top: 2px solid var(--border-color);
  }

  ha-ripple {
    display: none !important;
  }

  .route {
    overflow: visible;
    border-radius: var(--ha-card-border-radius);
    --icon-primary-color: var(--secondary-text-color);
  }

  /* The buttons have no ripple, so the press effect is the only feedback */
  .route > .button {
    isolation: isolate;
    transition: scale var(--duration-fast) var(--ease-standard);
  }

  .route:active > .button {
    scale: var(--press-scale);
  }

  /* The icon has the color, and the background behind it is the tint.
     The tint is drawn on ::before, so a badge can cut into it
     without clipping itself. */
  .button.active {
    color: var(--navbar-primary-color);
    background: none !important;
    border-radius: var(--radius-inner);
  }

  .button.active::before {
    content: "";
    position: absolute;
    inset: 0;
    z-index: -1;
    border-radius: inherit;
    background: var(--tint);
    -webkit-mask: var(--b-cutout, none);
    mask: var(--b-cutout, none);
    animation: navbar-fade-in var(--duration-normal) var(--ease-standard);
  }

  .navbar.mobile,
  .navbar.mobile.floating {
    overflow: visible !important;
  }

  /* Content slides under the bar and fades into the page,
     like it does under the header at the top. */
  .navbar.mobile.floating::before {
    content: "";
    position: absolute;
    left: 0;
    right: 0;
    bottom: 0;
    height: calc(100% + var(--ha-space-10, 40px));
    z-index: -2;
    pointer-events: none;
    background: linear-gradient(to top, var(--dashboard-background), var(--backdrop-background-color) 45%, transparent);
    backdrop-filter: var(--blur-soft);
    -webkit-backdrop-filter: var(--blur-soft);
    -webkit-mask: linear-gradient(to top, #000 45%, transparent);
    mask: linear-gradient(to top, #000 45%, transparent);
  }

  /* Each badge is a solid circle in the route's color on the button's top-right
     corner. The circle cuts a gap of --b-gap out of the tint.
     On an inactive button without a tint, it cuts into the icon instead. */
  .route > .button {
    --b-size: var(--icon-size-m);
    --b-gap: 3px;
    --b-out: 3px;
    --b-x: calc(100% - var(--b-size) / 2 + var(--b-out));
    --b-y: calc(var(--b-size) / 2 - var(--b-out));
    --b-reach: calc(var(--b-size) / 2 + var(--b-gap));
  }

  .route > .button:not(.active) {
    --b-x: calc(50% + var(--navbar-route-icon-size) / 2);
    --b-y: calc(50% - var(--navbar-route-icon-size) / 2);
  }

  .route > .button:has(.badge:not(.with-counter)) {
    --b-size: var(--dot-size);
  }

  .route > .button:has(.badge) {
    --b-cutout: radial-gradient(circle at var(--b-x) var(--b-y),
      #0000 var(--b-reach), #000 calc(var(--b-reach) + .5px));
  }

  .route > .button:not(.active):has(.badge) > .icon {
    -webkit-mask: radial-gradient(circle at 100% 0, #0000 var(--b-reach), #000 calc(var(--b-reach) + .5px));
    mask: radial-gradient(circle at 100% 0, #0000 var(--b-reach), #000 calc(var(--b-reach) + .5px));
  }

  .route .badge {
    width: var(--b-size) !important;
    height: var(--b-size) !important;
    min-width: 0 !important;
    padding: 0 !important;
    left: calc(var(--b-x) - var(--b-size) / 2) !important;
    top: calc(var(--b-y) - var(--b-size) / 2) !important;
    right: auto !important;
    border-radius: var(--radius-circle) !important;
    background: var(--navbar-primary-color) !important;
    color: var(--text-color-active) !important;
    font-size: calc(var(--b-size) * .55) !important;
    font-weight: var(--ha-font-weight-bold) !important;
    line-height: 1 !important;
    font-variant-numeric: tabular-nums;
    animation: navbar-badge-in var(--duration-normal) var(--ease-standard);
  }

  @keyframes navbar-badge-in {
    from { scale: .4; opacity: 0; }
  }

  @keyframes navbar-fade-in {
    from { opacity: 0; }
  }

  @media (prefers-reduced-motion: reduce) {
    .route .badge,
    .button.active::before { animation: none; }
    .route:active > .button { scale: none; }
  }

  /* Pop-ups */
  .navbar-popup-backdrop {
    background: transparent !important;
    backdrop-filter: var(--blur-strong);
    -webkit-backdrop-filter: var(--blur-strong);
  }

  /* The menu on the right is aligned with the screen edge */
  .navbar-popup.mobile.open-up.label-left {
    right: var(--view-bleed) !important;
  }

  .popup-item {
    background-color: var(--ha-card-background);
    box-shadow: var(--ha-card-box-shadow);
    border-radius: var(--ha-card-border-radius) !important;
  }

  .navbar-popup.mobile .popup-item .button {
    width: 70px !important;
    height: 60px !important;
  }

  .popup-item .button {
    background: transparent !important;
    box-shadow: none !important;
  }

  .label {
    padding: 0px 0px 0px var(--ha-space-4) !important;
    font-size: var(--ha-font-size-l) !important;
    font-weight: 600 !important;
  }

  /* Pop-ups that open to the right, such as the light scenes, need mirrored padding */
  .navbar-popup.mobile .popup-item.label-right .label {
    padding: 0px var(--ha-space-4) 0px 0px !important;
  }

  /* Active scene. The icon is amber on an amber tint, and the label keeps the text color. */
  .popup-item.active {
    --icon-primary-color: var(--state-light-active-color);
    background-color: color-mix(in srgb, var(--state-light-active-color) var(--tint-strength), var(--ha-card-background)) !important;
  }

  .popup-item.active .button {
    color: inherit !important;
  }

  /* The now playing card is as wide as the dashboard cards.
     It stays above the content, so it uses the elevated shadow. */
  .navbar.mobile {
    gap: var(--ha-space-3) !important;
  }

  .media-player {
    --navbar-primary-color: var(--state-media_player-active-color);
    background: var(--ha-card-background) !important;
    box-shadow: var(--shadow-elevated) !important;
    border-radius: var(--ha-card-border-radius) !important;
    padding: var(--card-padding) !important;
    gap: var(--ha-space-3) !important;
  }

  .media-player.mobile {
    width: auto !important;
    align-self: stretch !important;
    margin: 0 var(--view-bleed) !important;
  }

  .media-player-image,
  .media-player-info {
    position: relative;
  }

  /* The cover's colors glow only behind the artwork and fade out before the text */
  .media-player .media-player-bg {
    -webkit-mask: linear-gradient(to right, #000, transparent 55%);
    mask: linear-gradient(to right, #000, transparent 55%);
  }

  /* Text that does not fit ends in an ellipsis before the buttons */
  .media-player .media-player-info {
    padding-right: var(--ha-space-10, 40px);
  }

  .media-player .media-player-title,
  .media-player .media-player-artist {
    white-space: nowrap;
    overflow: hidden;
    text-overflow: ellipsis !important;
  }

  /* The progress bar is hidden. The card only reads media_position and does not update in between,
     so the bar would not move smoothly. */
  .media-player .media-player-progress-bar {
    display: none !important;
  }

  .media-player-image {
    width: var(--tile-size) !important;
    height: var(--tile-size) !important;
    margin: 0 !important;
    border-radius: var(--radius-inner) !important;
  }

  .media-player-icon-fallback {
    color: var(--state-media_player-active-color);
    --icon-primary-color: currentColor;
    background: var(--tint) !important;
  }

  .media-player-title {
    font-size: var(--ha-font-size-m) !important;
    font-weight: var(--ha-font-weight-bold) !important;
    line-height: var(--ha-line-height-normal);
    margin-bottom: 3px;
  }

  .media-player-artist {
    font-size: var(--ha-font-size-s) !important;
    color: var(--secondary-text-color) !important;
    line-height: var(--ha-line-height-normal);
  }

  .navbar-icon-button.media-player-button {
    width: var(--control-height-icon) !important;
    height: var(--control-height-icon) !important;
    flex-shrink: 0;
    color: var(--secondary-text-color);
    --icon-primary-color: currentColor;
  }

  /* The play and pause button has a filled background and an icon in the active text color */
  .navbar-icon-button.media-player-button-play-pause {
    width: calc(var(--tile-size) - var(--ha-space-2)) !important;
    height: calc(var(--tile-size) - var(--ha-space-2)) !important;
    background: var(--fill-active) !important;
    color: var(--text-color-active) !important;
  }

  /* The group badge on the cover is a tinted circle with a link icon in the media color.
     The subtitle template sets --navbar-player-group to 1 when the speaker is grouped and to 0 otherwise. */
  .media-player {
    --g-on: var(--navbar-player-group, 0);
    --g-size: var(--icon-size-s);
    --g-gap: 3px;
    --g-out: 3px;
    --g-reach: calc(var(--g-size) / 2 + var(--g-gap));
  }

  .media-player::before,
  .media-player::after {
    content: "";
    position: absolute;
    z-index: 2;
    width: var(--g-size);
    height: var(--g-size);
    left: calc(var(--card-padding) + var(--tile-size) - var(--g-size) + var(--g-out));
    top: calc(50% - var(--tile-size) / 2 - var(--g-out));
    scale: var(--g-on);
    transition: scale var(--duration-normal) var(--ease-standard);
    pointer-events: none;
  }

  .media-player-image {
    -webkit-mask: radial-gradient(circle at calc(100% - var(--g-size) / 2 + var(--g-out)) calc(var(--g-size) / 2 - var(--g-out)),
      #0000 calc(var(--g-reach) * var(--g-on)), #000 calc((var(--g-reach) + .5px) * var(--g-on)));
    mask: radial-gradient(circle at calc(100% - var(--g-size) / 2 + var(--g-out)) calc(var(--g-size) / 2 - var(--g-out)),
      #0000 calc(var(--g-reach) * var(--g-on)), #000 calc((var(--g-reach) + .5px) * var(--g-on)));
  }

  .media-player::before {
    border-radius: var(--radius-circle);
    background: color-mix(in srgb, var(--state-media_player-active-color) var(--tint-strength), var(--ha-card-background));
  }

  .media-player::after {
    background: var(--state-media_player-active-color);
  }

  /* The TV card is recognized by its cover or its fallback icon. It has no group
     badge, and its buttons show remote control icons. OK (a ring) replaces
     play and pause, and right replaces skip. */
  .media-player:is(:has(img.media-player-image[src*="media_player.tv_ump"]),
                   :has(.media-player-icon-fallback[icon="mdi:television"])) {
    --g-on: 0;
  }

  .media-player:is(:has(img.media-player-image[src*="media_player.tv_ump"]),
                   :has(.media-player-icon-fallback[icon="mdi:television"])) .media-player-button > ha-icon {
    display: none;
  }

  .media-player:is(:has(img.media-player-image[src*="media_player.tv_ump"]),
                   :has(.media-player-icon-fallback[icon="mdi:television"])) .media-player-button-play-pause::after {
    content: "";
    width: var(--mdc-icon-size, 24px);
    height: var(--mdc-icon-size, 24px);
    background: currentColor;
  }

  .media-player:is(:has(img.media-player-image[src*="media_player.tv_ump"]),
                   :has(.media-player-icon-fallback[icon="mdi:television"])) .media-player-button-skip::after {
    content: "";
    width: var(--mdc-icon-size, 24px);
    height: var(--mdc-icon-size, 24px);
    background: currentColor;
  }

  /* On desktop, the bar is attached to the right edge and centered vertically. */
  .navbar.desktop {
    overflow: visible !important;
  }

  .navbar.desktop.right {
    right: 0px !important;
    margin-right: 0px !important;
    --navbar-border-radius: var(--ha-card-border-radius);
  }

  .navbar.desktop.right .navbar-card.desktop.right {
    border-radius: var(--ha-card-border-radius) 0px 0px var(--ha-card-border-radius) !important;
    border: 2px solid var(--border-color) !important;
    border-right: none !important;
    padding: var(--ha-space-4) var(--ha-space-4) var(--ha-space-4) var(--ha-space-3) !important;
    margin: 0px !important;
    min-width: 0px !important;
    overflow: hidden;
  }

  /* Mobile */
  .navbar-card.mobile,
  .navbar-card.mobile.floating {
    width: 100% !important;
    border-radius: var(--ha-card-border-radius) var(--ha-card-border-radius) 0px 0px !important;
  }

  .navbar-card.mobile .route {
    height: 50px !important;
  }

  .navbar-card.mobile .route .button {
    height: 100% !important;
  }

Pop-ups

The dashboard contains three Bubble Card pop-ups for a room, the TV and the fan. They are at the end of dashboard.yaml, under # Pop-ups. A pop-up opens when a button navigates to its hash, such as #popup_tv. To close a pop-up, tap the close button or swipe down. The scripts and helpers that the pop-ups use are in the package. Each pop-up's YAML section contains the whole pop-up as one Bubble card. Add it to the same view as the button that opens it.

Room

Each room can have the same kind of pop-up, which opens from its room card. From top to bottom, the pop-up shows the media in the room, the lights and the climate. The living room pop-up is the example to copy for other rooms.

How it works

The pop-up's hash is #popup_living_room, which is the living room card's navigation path.
The media card shows the TV while it is on, and the speaker at all other times. Tap the TV card to open the TV pop-up. Smaller controls for the room go under the media card. In this example, a smart plug appears as a compact row with a switch.
The lights header shows how many lights in the room's light group are on. The power button on the All card turns the whole group on or off, and the arrow next to it shows the scenes. A tap on the card opens the group's details. The scene that was turned on last is highlighted.
The climate header shows the temperature and humidity, with a dot in the room's comfort color. Tap the fan card to open the fan pop-up. The plus and minus buttons change the thermostat's target temperature by half a degree.
Everything off turns off the lights, fans, media players and switches in the room's area. The list of these domains is in script.room_off.
When you close the pop-up, the scenes are hidden again.

Entities

Entity	Purpose
`media_player.living_room_tv`, `media_player.living_room_tv_cast`	The TV card, which the TV section explains
`media_player.living_room`	The speaker and both volume sliders
`switch.living_room_console`	The smart plug
`light.living_room`	The room's light group. The header counts the lights in this group.
`scene.living_room_*`, `sensor.living_room_scene`	The scenes and the scene that was turned on last
`input_boolean.living_room_scenes`	Whether the scenes are visible
`sensor.climate_living_room`	The temperature, humidity and comfort color
`fan.living_room`, `climate.living_room`	The fan and the thermostat
`script.thermostat_step`, `script.room_off`	The thermostat buttons and Everything off

All of these entities are examples. The scripts, the toggle and sensor.living_room_scene are in the package, and the sensor contains the list of scenes.

To create a pop-up for another room, copy the living room pop-up and give it the hash that the room card opens, such as #popup_bedroom. Then change the name, the entities and the area of Everything off. The new room's scenes need their own toggle and scene sensor. You can also remove the scenes. A different fan needs its own fan pop-up.

YAML

This pop-up needs Bubble Card and the package.

type: custom:bubble-card
card_type: pop-up
hash: '#popup_living_room'
name: Living room
button_type: name
show_header: true
show_name: true
show_icon: false
card_layout: large
buttons_position: right
scrolling_effect: false
margin: 7px
margin_top_mobile: 22px
margin_top_desktop: 30%
bg_color: transparent
bg_opacity: '100'
bg_blur: '0'
shadow_opacity: '12'
hide_backdrop: false
modules:
  - default
  - origami_popup
origami_popup:
  subtitle_style: text
# Hides the scenes again when you close the pop-up
close_action:
  action: perform-action
  perform_action: input_boolean.turn_off
  target:
    entity_id: input_boolean.living_room_scenes
cards:
  - type: vertical-stack
    cards:
      # The media card shows the TV while it is on and the speaker at all other times.
      - type: vertical-stack
        cards:
          - type: conditional
            conditions:
              - condition: state
                entity: media_player.living_room_tv
                state_not:
                  - 'off'
                  - standby
                  - unavailable
                  - unknown
            card:
              type: custom:bubble-card
              card_type: media-player
              button_type: state
              entity: media_player.living_room_tv
              name: TV
              icon: mdi:television
              modules:
                - origami_base
                - origami_media
              origami_media:
                art_entity: media_player.living_room_tv_cast
                app_entity: media_player.living_room_tv
              hide:
                power_button: true
                previous_button: true
                next_button: true
                volume_button: true
                play_pause_button: true
              tap_action:
                action: navigate
                navigation_path: '#popup_tv'
              button_action:
                tap_action:
                  action: navigate
                  navigation_path: '#popup_tv'
              sub_button:
                main:
                  - icon: mdi:power
                    show_background: true
                    tap_action:
                      action: perform-action
                      perform_action: media_player.toggle
                      target:
                        entity_id: media_player.living_room_tv
                bottom:
                  - entity: media_player.living_room
                    sub_button_type: slider
                    always_visible: true
              rows: '2.2'
              state_content: state
          - type: conditional
            conditions:
              - condition: state
                entity: media_player.living_room_tv
                state:
                  - 'off'
                  - standby
                  - unavailable
                  - unknown
            card:
              type: custom:bubble-card
              card_type: media-player
              button_type: state
              entity: media_player.living_room
              name: Speaker
              icon: mdi:speaker
              scrolling_effect: true
              modules:
                - origami_base
                - origami_media
              origami_base:
                group: true
              hide:
                power_button: true
                previous_button: true
                next_button: true
                volume_button: true
                play_pause_button: true
              tap_action:
                action: more-info
              button_action:
                tap_action:
                  action: more-info
              sub_button:
                main:
                  # Play or pause, depending on the state
                  - icon: mdi:play
                    show_background: true
                    tap_action:
                      action: perform-action
                      perform_action: media_player.media_play_pause
                      target:
                        entity_id: media_player.living_room
                    visibility:
                      - condition: state
                        entity: media_player.living_room
                        state_not: playing
                  - icon: mdi:pause
                    show_background: true
                    tap_action:
                      action: perform-action
                      perform_action: media_player.media_play_pause
                      target:
                        entity_id: media_player.living_room
                    visibility:
                      - condition: state
                        entity: media_player.living_room
                        state: playing
                  - icon: mdi:skip-next
                    show_background: false
                    tap_action:
                      action: perform-action
                      perform_action: media_player.media_next_track
                      target:
                        entity_id: media_player.living_room
                  # Bluetooth as the source, filled while it is active
                  - icon: mdi:bluetooth
                    show_background: false
                    tap_action:
                      action: perform-action
                      perform_action: media_player.select_source
                      target:
                        entity_id: media_player.living_room
                      data:
                        source: Bluetooth
                    visibility:
                      - condition: state
                        entity: media_player.living_room
                        attribute: source
                        state_not: Bluetooth
                  - icon: mdi:bluetooth-connect
                    show_background: true
                    tap_action:
                      action: perform-action
                      perform_action: media_player.select_source
                      target:
                        entity_id: media_player.living_room
                      data:
                        source: Bluetooth
                    visibility:
                      - condition: state
                        entity: media_player.living_room
                        attribute: source
                        state: Bluetooth
                bottom:
                  - entity: media_player.living_room
                    sub_button_type: slider
                    always_visible: true
              rows: '2.2'
              state_content: state
          # A plug as a compact row with a switch
          - type: custom:bubble-card
            card_type: button
            button_type: switch
            entity: switch.living_room_console
            name: Console
            icon: mdi:controller
            modules:
              - origami_base
            origami_base:
              compact: true
              toggle: true
              tile: true
            sub_button:
              main:
                - icon: mdi:circle
                  show_background: true
                  tap_action:
                    action: toggle
            rows: 1

      # Lights header, all lights and the scenes
      - type: vertical-stack
        cards:
          - type: custom:bubble-card
            card_type: separator
            name: Lights
            modules:
              - origami_header
            origami_header:
              icon_size: var(--icon-size-s)
            grid_options:
              rows: auto
            sub_button:
              main:
                # Counts the lights in the group that are on
                - entity: light.living_room
                  icon: mdi:chevron-right
                  show_name: true
                  content_layout: icon-right
                  show_background: false
                  origami_header:
                    name: >-
                      ${(ids => (n => n ? n + ' of ' + ids.length + ' on' : 'All off')(ids.filter((id) => states(id) === 'on').length))(attr.entity_id ?? [])}
                  tap_action:
                    action: more-info
          - type: custom:bubble-card
            card_type: button
            button_type: switch
            entity: light.living_room
            name: All
            icon: mdi:lightbulb-multiple
            modules:
              - origami_base
              - origami_light
            origami_base:
              tile: true
            scrolling_effect: false
            tap_action:
              action: more-info
            button_action:
              tap_action:
                action: more-info
            sub_button:
              main:
                # Shows and hides the scenes below
                - entity: input_boolean.living_room_scenes
                  icon: mdi:chevron-down
                  show_background: true
                  tap_action:
                    action: toggle
                - icon: mdi:power
                  show_background: true
                  tap_action:
                    action: perform-action
                    perform_action: light.toggle
                    target:
                      entity_id: light.living_room
            state_content:
              - state
              - brightness
            rows: 1.375
          - type: conditional
            conditions:
              - condition: state
                entity: input_boolean.living_room_scenes
                state: 'on'
            card:
              type: custom:bubble-card
              card_type: sub-buttons
              modules:
                - origami_button
              origami_button:
                columns: 2
                animate: true
                padding: var(--ha-space-1) 0 0 0
                # The scene that was turned on last is highlighted
                active: "{{ states('sensor.living_room_scene') }}"
              sub_button:
                main: []
                bottom:
                  - name: Evening
                    icon: mdi:weather-sunset-down
                    show_name: true
                    tap_action:
                      action: perform-action
                      perform_action: scene.turn_on
                      target:
                        entity_id: scene.living_room_evening
                  - name: Late
                    icon: mdi:weather-night-partly-cloudy
                    show_name: true
                    tap_action:
                      action: perform-action
                      perform_action: scene.turn_on
                      target:
                        entity_id: scene.living_room_late
                  - name: Night
                    icon: mdi:weather-night
                    show_name: true
                    tap_action:
                      action: perform-action
                      perform_action: scene.turn_on
                      target:
                        entity_id: scene.living_room_night
                  - name: Dinner
                    icon: mdi:silverware-fork-knife
                    show_name: true
                    tap_action:
                      action: perform-action
                      perform_action: scene.turn_on
                      target:
                        entity_id: scene.living_room_dinner

      # Climate header, the fan and the thermostat
      - type: vertical-stack
        cards:
          - type: custom:bubble-card
            card_type: separator
            name: Climate
            modules:
              - origami_header
            origami_header:
              # The dot uses the comfort color
              icon_color: '{{ state_attr("sensor.climate_living_room", "color_code") }}'
            grid_options:
              rows: auto
            sub_button:
              main:
                - entity: sensor.climate_living_room
                  icon: mdi:circle
                  show_name: true
                  show_background: false
                  origami_header:
                    name: ${attr.temperature}° / ${attr.humidity} %
                  tap_action:
                    action: more-info
          - type: conditional
            conditions:
              - condition: state
                entity: fan.living_room
                state_not: unavailable
            card:
              type: custom:bubble-card
              card_type: button
              button_type: switch
              entity: fan.living_room
              name: Fan
              icon: mdi:fan
              modules:
                - origami_base
                - origami_fan
              origami_base:
                group: true
                tile: true
              scrolling_effect: false
              # A tap on the card opens the fan pop-up
              tap_action:
                action: navigate
                navigation_path: '#popup_fan'
              button_action:
                tap_action:
                  action: navigate
                  navigation_path: '#popup_fan'
              sub_button:
                main:
                  - icon: mdi:power
                    show_background: true
                    tap_action:
                      action: perform-action
                      perform_action: fan.toggle
                      target:
                        entity_id: fan.living_room
                  - name: '1'
                    show_icon: false
                    show_name: true
                    show_background: false
                    tap_action:
                      action: perform-action
                      perform_action: fan.set_percentage
                      target:
                        entity_id: fan.living_room
                      data:
                        percentage: 33
                  - name: '2'
                    show_icon: false
                    show_name: true
                    show_background: false
                    tap_action:
                      action: perform-action
                      perform_action: fan.set_percentage
                      target:
                        entity_id: fan.living_room
                      data:
                        percentage: 66
                  - name: '3'
                    show_icon: false
                    show_name: true
                    show_background: false
                    tap_action:
                      action: perform-action
                      perform_action: fan.set_percentage
                      target:
                        entity_id: fan.living_room
                      data:
                        percentage: 100
              state_content:
                - state
                - percentage
              rows: 1.375
          - type: custom:bubble-card
            card_type: button
            button_type: switch
            entity: climate.living_room
            name: Thermostat
            icon: mdi:thermostat
            modules:
              - origami_base
              - origami_climate
            origami_base:
              group: true
              tile: true
            scrolling_effect: false
            tap_action:
              action: more-info
            button_action:
              tap_action:
                action: more-info
            sub_button:
              main:
                - icon: mdi:minus
                  show_background: true
                  tap_action:
                    action: perform-action
                    perform_action: script.thermostat_step
                    data:
                      thermostat: climate.living_room
                      step: -0.5
                - entity: climate.living_room
                  css_class: readout
                  show_icon: false
                  show_name: false
                  show_background: false
                  state_content: temperature
                  tap_action:
                    action: more-info
                - icon: mdi:plus
                  show_background: true
                  tap_action:
                    action: perform-action
                    perform_action: script.thermostat_step
                    data:
                      thermostat: climate.living_room
                      step: 0.5
            state_content: []
            rows: 1.375

      # Turns everything in the room off, shown as a plain text button
      - type: custom:bubble-card
        card_type: sub-buttons
        modules:
          - origami_button
        origami_button:
          background: false
          align: center
          muted: true
          icon_size: var(--icon-size-xs)
          padding: var(--ha-space-6, 24px) 0 100px 0
        sub_button:
          main: []
          bottom:
            - name: Everything off
              icon: mdi:power
              show_name: true
              tap_action:
                action: perform-action
                perform_action: script.room_off
                data:
                  area: living_room
        rows: 1.75

TV

The TV pop-up is a remote control for the TV. It opens from TV in the navigation bar or from the TV card in the room pop-up.

How it works

The top card shows the TV, its current program and its power button. A separate speaker plays the TV's sound, and the card's slider sets the speaker's volume. A blurred picture of the current program appears behind the pop-up.
The input button sends the TV_INPUT command to the TV. The TV button switches the speaker to its TV input, and it is filled while the speaker uses that input.
The minus and plus buttons change the volume by 1%. A double tap changes it by 5%, and holding the button changes it by 10%. Tap the number to mute the speaker.
The app buttons scroll sideways, and the running app's button is filled. Tap an app to start it with media_player.select_source.
The remote has a back button, a home button and a round pad with an OK button. Hold an arrow button to repeat its command.

The commands, such as DPAD_UP, DPAD_CENTER and TV_INPUT, are for the Android TV Remote integration. Other remotes use different command names. The app buttons need your TV's source names.

Entities

Entity	Purpose
`media_player.living_room_tv`	The TV and its apps, from Android TV Remote
`remote.living_room_tv`	The remote, from Android TV Remote
`media_player.living_room_tv_cast`	The current program and its picture, from Google Cast
`media_player.living_room`	The speaker that plays the TV's sound
`script.volume`	The volume steps and mute, from the package

In this example, the speaker's TV input is called Optical In. If you do not have a separate speaker, point the volume buttons and the slider to the TV and delete the TV button.

YAML

This pop-up needs Bubble Card, Paper Buttons Row and script.volume from the package.

type: custom:bubble-card
card_type: pop-up
hash: '#popup_tv'
name: TV
button_type: name
show_icon: false
margin_top_mobile: 72px
margin_top_desktop: 300px
bg_opacity: 100
shadow_opacity: '12'
popup_mode: adaptive-dialog
with_bottom_offset: true
performance_mode: performance
modules:
  - origami_popup
# A blurred picture of the current program appears behind the pop-up
styles: |-
  ${(() => {
    const cast = hass.states["media_player.living_room_tv_cast"];
    const art = cast?.attributes?.entity_picture_local ?? cast?.attributes?.entity_picture;
    const on = ["playing", "paused", "buffering"].includes(cast?.state);
    const url = on && typeof art === "string" && art ? 'url("' + art.replace(/"/g, "%22") + '")' : null;
    return `.bubble-pop-up-background::after {
      content: "";
      position: absolute;
      inset: 0;
      z-index: 0;
      border-radius: inherit;
      background-image: ${url ?? "none"};
      background-size: cover;
      background-position: center;
      filter: blur(50px) saturate(170%);
      opacity: ${url ? "0.16" : "0"};
      pointer-events: none;
      clip-path: inset(0 round var(--bubble-pop-up-border-radius, var(--bubble-border-radius, 42px)) var(--bubble-pop-up-border-radius, var(--bubble-border-radius, 42px)) 0 0);
      transition: opacity var(--duration-normal, 0.3s) ease;
    }
    .bubble-pop-up-container > * {
      position: relative;
      z-index: 1;
    }`;
  })()}
cards:
  - type: vertical-stack
    cards:
      # The TV card shows the app or the cast program, a power button and the speaker's volume
      - type: custom:bubble-card
        card_type: media-player
        button_type: state
        entity: media_player.living_room_tv
        name: TV
        icon: mdi:television
        modules:
          - origami_base
          - origami_media
          - '!default'
        origami_media:
          art_entity: media_player.living_room_tv_cast
          app_entity: media_player.living_room_tv
        scrolling_effect: false
        slider_live_update: false
        cover_background: false
        hide:
          power_button: true
          previous_button: true
          next_button: true
          volume_button: true
          play_pause_button: true
        tap_action:
          action: more-info
        button_action:
          tap_action:
            action: more-info
        sub_button:
          main:
            - icon: mdi:power
              show_background: true
              tap_action:
                action: perform-action
                perform_action: media_player.toggle
                target:
                  entity_id: media_player.living_room_tv
          bottom:
            - entity: media_player.living_room
              sub_button_type: slider
              always_visible: true
              custom_height: 26
        rows: '2.2'
        state_content: state

      # Input, TV sound through the speaker, and the volume in steps
      - type: custom:paper-buttons-row
        extra_styles: >-
          paper-button:active { background-color: var(--fill-strong) !important }
          paper-button[data-state="optical in" i], paper-button[data-state="optical in" i] + paper-button { background-image: none !important }
        styles:
          align-items: stretch
          margin: var(--ha-space-2) 0px
          padding: 0px
          background-color: transparent
          box-shadow: none
          --pbs-button-bg-color: var(--fill-subtle)
        base_config:
          layout: icon
          tap_action:
            action: call-service
            service: script.volume
          styles:
            button:
              flex: 1
              height: var(--control-height)
              padding: 0px
              border-radius: 0px
              box-shadow: none
              background-image: linear-gradient(var(--fill-loud), var(--fill-loud))
              background-repeat: no-repeat
              background-size: 2px 50%
              background-position: left center
              transition: var(--transition-interactive)
            icon:
              --mdc-icon-size: var(--icon-size-m)
              margin-right: 0px
              opacity: var(--opacity-strong)
        buttons:
          - icon: mdi:import
            tooltip: Input
            tap_action:
              service: remote.send_command
              target:
                entity_id: remote.living_room_tv
              service_data:
                command: TV_INPUT
            styles:
              button:
                border-radius: var(--radius-inner) 0px 0px var(--radius-inner)
                background-image: none
          # The button is filled while the speaker plays the TV's sound, like the active buttons in the fan pop-up
          - layout: name
            name: TV
            tooltip: TV sound through the speaker
            state:
              entity: media_player.living_room
              attribute: source
            active:
              - optical in
            state_styles:
              optical in:
                button:
                  background-color: var(--fill-subtle)
                name:
                  color: var(--ha-card-background)
                  background-color: var(--fill-active)
                  opacity: 1
            tap_action:
              service: media_player.select_source
              target:
                entity_id: media_player.living_room
              service_data:
                source: Optical In
            styles:
              button:
                box-sizing: border-box
                padding: var(--ha-space-1)
                margin-right: var(--ha-space-3)
                border-radius: 0px var(--radius-inner) var(--radius-inner) 0px
              name:
                display: flex
                align-items: center
                justify-content: center
                box-sizing: border-box
                width: 100%
                height: 100%
                padding: 0px
                border-radius: calc(var(--radius-inner) - var(--ha-space-1))
                font-size: var(--ha-font-size-l)
                font-weight: var(--ha-font-weight-bold)
                transition: var(--transition-interactive)
          # A tap changes the volume by 1%, a double tap by 5% and holding by 10%
          - icon: mdi:minus
            tooltip: Quieter
            tap_action:
              service_data:
                speaker: media_player.living_room
                step: -0.01
            double_tap_action:
              action: call-service
              service: script.volume
              service_data:
                speaker: media_player.living_room
                step: -0.05
            hold_action:
              action: call-service
              service: script.volume
              service_data:
                speaker: media_player.living_room
                step: -0.1
            styles:
              button:
                border-radius: var(--radius-inner) 0px 0px var(--radius-inner)
                background-image: none
          # Shows the volume, or a muted icon while the speaker is muted. A tap mutes the speaker.
          - layout: state|icon
            icon: mdi:volume-off
            tooltip: Mute
            state: >-
              {% set s = 'media_player.living_room' %}{{ 'off' if states(s) in ['unavailable', 'unknown', 'off']
              else 'muted' if state_attr(s, 'is_volume_muted')
              else ((state_attr(s, 'volume_level') | float(0)) * 100) | round(0) | int }}
            state_text:
              'off': –
              muted: ' '
            state_styles:
              muted:
                state:
                  transform: scale(0)
                icon:
                  transform: scale(1)
            tap_action:
              service_data:
                speaker: media_player.living_room
                mute: true
            hold_action:
              action: more-info
              entity: media_player.living_room
            styles:
              button:
                position: relative
              state:
                padding: 0px
                font-size: var(--ha-font-size-l)
                font-weight: var(--ha-font-weight-bold)
                font-variant-numeric: tabular-nums
                transition: transform var(--duration-normal) ease
              icon:
                --mdc-icon-size: var(--icon-size-s)
                position: absolute
                transform: scale(0)
                transition: transform var(--duration-normal) ease
          - icon: mdi:plus
            tooltip: Louder
            tap_action:
              service_data:
                speaker: media_player.living_room
                step: 0.01
            double_tap_action:
              action: call-service
              service: script.volume
              service_data:
                speaker: media_player.living_room
                step: 0.05
            hold_action:
              action: call-service
              service: script.volume
              service_data:
                speaker: media_player.living_room
                step: 0.1
            styles:
              button:
                border-radius: 0px var(--radius-inner) var(--radius-inner) 0px

      # The app buttons scroll sideways. The running app's button is filled.
      - type: custom:paper-buttons-row
        extra_styles: >-
          paper-button.button-active { background-color: var(--fill-active) !important; box-shadow: none !important }
          paper-button.button-active span { color: var(--ha-card-background) !important; opacity: 1 !important }
        styles:
          justify-content: start
          gap: var(--ha-space-2)
          margin: calc(var(--scroller-bleed) * -1)
          padding: var(--scroller-padding)
          overflow-x: scroll
          overscroll-behavior-x: contain
          scroll-snap-type: x mandatory
          scrollbar-width: none
          mask-image: var(--scroller-mask)
        base_config:
          layout: name
          state:
            entity: media_player.living_room_tv
            attribute: app_id
          tap_action:
            action: call-service
            service: media_player.select_source
            target:
              entity_id: media_player.living_room_tv
          styles:
            button:
              scroll-snap-align: start
              scroll-margin-left: var(--scroller-bleed)
              padding: calc(var(--control-padding-x) / 1.4) var(--control-padding-x)
              border-radius: var(--ha-card-border-radius)
              background-color: var(--fill-subtle)
              box-shadow: var(--card-ring)
              transition: var(--transition-interactive)
            name:
              padding: 0px
              font-size: var(--ha-font-size-m)
              font-weight: var(--ha-font-weight-normal)
              white-space: nowrap
        buttons:
          - name: Netflix
            active:
              - com.netflix.ninja
            tap_action:
              service_data:
                source: Netflix
          - name: YouTube
            active:
              - com.google.android.youtube.tv
            tap_action:
              service_data:
                source: YouTube
          - name: Prime Video
            active:
              - com.amazon.amazonvideo.livingroom
            tap_action:
              service_data:
                source: Prime Video
          - name: Disney+
            active:
              - com.disney.disneyplus
            tap_action:
              service_data:
                source: Disney+
          - name: Spotify
            active:
              - com.spotify.tv.android
            tap_action:
              service_data:
                source: Spotify
          - name: Plex
            active:
              - com.plexapp.android
            tap_action:
              service_data:
                source: Plex

      # The remote has back and home buttons and a round pad. Holding an arrow repeats its command.
      - type: custom:paper-buttons-row
        extra_styles: 'paper-button:active { transform: scale(var(--press-scale)) }'
        styles:
          display: grid
          grid-template-columns: 1fr var(--control-height-lg) var(--control-height-lg) var(--control-height-lg) 1fr
          grid-template-rows: repeat(3, var(--control-height-lg))
          grid-template-areas: '"back . up . home" ". left ok right ." ". . down . ."'
          gap: var(--ha-space-2)
          margin-top: var(--ha-space-2)
          align-items: center
          justify-items: center
        base_config:
          layout: icon
          tap_action:
            action: call-service
            service: remote.send_command
            target:
              entity_id: remote.living_room_tv
          hold_action:
            action: call-service
            service: remote.send_command
            target:
              entity_id: remote.living_room_tv
            repeat: 300
          styles:
            button:
              width: var(--control-height)
              height: var(--control-height)
              padding: 0px
              border-radius: var(--radius-inner)
              background-color: transparent
              box-shadow: none
            icon:
              --mdc-icon-size: var(--icon-size-l)
              margin-right: 0px
              opacity: var(--opacity-strong)
            name:
              padding: 0px
        buttons:
          # The round pad behind the arrows
          - layout: name
            name: ' '
            tooltip: false
            tap_action:
              action: none
            hold_action:
              action: none
            styles:
              button:
                grid-row: 1 / 4
                grid-column: 2 / 5
                width: calc(var(--control-height-lg) * 3 + var(--ha-space-2) * 2)
                height: calc(var(--control-height-lg) * 3 + var(--ha-space-2) * 2)
                border-radius: var(--radius-circle)
                background-color: var(--fill-subtle)
                box-shadow: var(--card-ring)
                pointer-events: none
          - icon: mdi:arrow-left
            tooltip: Back
            tap_action:
              service_data:
                command: BACK
            hold_action:
              action: none
            styles:
              button:
                grid-area: back
                justify-self: start
                width: var(--control-height-sm)
                height: var(--control-height-sm)
                border-radius: var(--ha-card-border-radius)
                background-color: var(--fill-subtle)
                box-shadow: var(--card-ring)
              icon:
                --mdc-icon-size: var(--icon-size-m)
          - icon: mdi:home
            tooltip: Home
            tap_action:
              service_data:
                command: HOME
            hold_action:
              action: none
            styles:
              button:
                grid-area: home
                justify-self: end
                width: var(--control-height-sm)
                height: var(--control-height-sm)
                border-radius: var(--ha-card-border-radius)
                background-color: var(--fill-subtle)
                box-shadow: var(--card-ring)
              icon:
                --mdc-icon-size: var(--icon-size-m)
          - icon: mdi:chevron-up
            tap_action:
              service_data:
                command: DPAD_UP
            hold_action:
              service_data:
                command: DPAD_UP
            styles:
              button:
                grid-area: up
          - icon: mdi:chevron-left
            tap_action:
              service_data:
                command: DPAD_LEFT
            hold_action:
              service_data:
                command: DPAD_LEFT
            styles:
              button:
                grid-area: left
          - layout: name
            name: OK
            tap_action:
              service_data:
                command: DPAD_CENTER
            hold_action:
              action: none
            styles:
              button:
                grid-area: ok
                width: var(--control-height-lg)
                height: var(--control-height-lg)
                border-radius: var(--radius-circle)
                background-color: var(--ha-card-background)
                box-shadow: var(--ha-card-box-shadow)
              name:
                font-size: var(--ha-font-size-m)
                font-weight: var(--ha-font-weight-bold)
                opacity: var(--opacity-muted)
          - icon: mdi:chevron-right
            tap_action:
              service_data:
                command: DPAD_RIGHT
            hold_action:
              service_data:
                command: DPAD_RIGHT
            styles:
              button:
                grid-area: right
          - icon: mdi:chevron-down
            tap_action:
              service_data:
                command: DPAD_DOWN
            hold_action:
              service_data:
                command: DPAD_DOWN
            styles:
              button:
                grid-area: down

Fan

The fan pop-up controls one fan. It sets the speed, the mode and a timer, and turns oscillation on or off. The pop-up opens from the fan card in the room pop-up.

How it works

The title shows the fan's name. Both the power button and the fan button turn the fan on and off, and the fan icon spins while the fan is running.
The arrow buttons turn the fan's head with fan.set_direction. This works with fans that use the direction setting to turn the head, such as Xiaomi fans. The middle button turns oscillation on or off.
The slider can set any speed. The leaf button selects the nature preset, and the wind button selects normal. Buttons 1, 2 and 3 set the speed to 33, 66 and 100%.
The timer button shows the timer row, which has the options Off, 1 hour, 3 hours and 5 hours. When the timer ends, an automation in the package turns the fan off.
Small templates in the buttons decide which button is filled, for example the button for the fan's current speed range.

Entities

Entity	Purpose
`fan.living_room`	The fan, which is an example
`timer.living_room_fan`	The timer, together with the automation that turns the fan off
`input_boolean.fan_popup_timer`	Whether the timer row is visible
`script.fan_oscillation`	Turning oscillation on or off

The timer, the toggle, the script and the automation are in the package. To use your own fan, replace fan.living_room in the pop-up and in the automation. If your fan uses other preset names, change nature and normal. You can delete the buttons that your fan does not support, such as the arrows. A second fan needs its own copy of the pop-up with its own hash, timer, toggle and automation.

YAML

This pop-up needs Bubble Card, Paper Buttons Row and the package.

type: custom:bubble-card
card_type: pop-up
hash: '#popup_fan'
name: Fan
show_header: false
show_close_button: false
show_name: false
show_icon: false
card_layout: large
margin: 7px
bg_color: var(--popup-background)
bg_opacity: '100'
bg_blur: '10'
shadow_opacity: '20'
hide_backdrop: false
popup_mode: fit-content
with_bottom_offset: true
modules:
  - origami_popup
styles: '.bubble-pop-up-container { mask-image: none !important; }'
# Hides the timer row again when you close the pop-up
close_action:
  action: perform-action
  perform_action: input_boolean.turn_off
  target:
    entity_id: input_boolean.fan_popup_timer
cards:
  - type: vertical-stack
    cards:
      # The fan's name and the power, timer and close buttons
      - type: custom:paper-buttons-row
        extra_styles: |
          paper-button:active { transform: scale(var(--press-scale)) }
        styles:
          margin: var(--ha-space-5) 0 var(--ha-space-2) 0
          display: grid
          grid-template-columns: auto 1fr auto auto auto
          grid-template-areas: '"title title power timer close" "chip . power timer close"'
          align-items: flex-start
          gap: var(--ha-space-1) var(--ha-space-3)
        base_config:
          layout: icon
          styles:
            button:
              width: var(--control-height-icon)
              height: var(--control-height-icon)
              padding: 0px
              justify-content: center
              border-radius: var(--radius-circle)
              background-color: var(--fill-subtle)
              box-shadow: none
            icon:
              --mdc-icon-size: var(--icon-size-xs)
              margin-right: 0px
            name:
              padding: 0px
            state:
              padding: 0px
        buttons:
          # The fan's name as the title
          - entity: fan.living_room
            layout: name
            tap_action:
              action: none
            hold_action:
              action: none
            styles:
              button:
                grid-area: title
                width: auto
                height: auto
                justify-content: flex-start
                background-color: transparent
                box-shadow: none
                pointer-events: none
              name:
                padding: 0px
                font-size: var(--font-size-headline)
                font-weight: var(--ha-font-weight-bold)
                line-height: var(--ha-line-height-normal)
                color: var(--primary-text-color)
          - entity: fan.living_room
            icon: mdi:power
            tooltip: On or off
            tap_action:
              action: toggle
            state_styles:
              'on':
                button:
                  background-color: var(--fill-active)
                icon:
                  color: var(--ha-card-background)
                  opacity: 1
            styles:
              button:
                grid-area: power
          - entity: input_boolean.fan_popup_timer
            icon: mdi:timer-outline
            tooltip: Timer
            tap_action:
              action: toggle
            state_styles:
              'on':
                button:
                  background-color: var(--fill-active)
                icon:
                  color: var(--ha-card-background)
                  opacity: 1
            styles:
              button:
                grid-area: timer
          - icon: mdi:close
            tooltip: Close
            tap_action:
              action: navigate
              navigation_path: '#'
            styles:
              button:
                grid-area: close
                margin-left: var(--ha-space-2)
                background-color: transparent
              icon:
                --mdc-icon-size: var(--icon-size-l)
                color: var(--primary-text-color)
                opacity: var(--opacity-muted)
      # An empty row that keeps the spacing even
      - type: custom:paper-buttons-row
        base_config:
          layout: icon
          tap_action:
            action: none
          styles:
            button:
              min-height: 0px
              max-height: 0px
              padding: 0px
              justify-content: flex-start
              pointer-events: none
            icon:
              --mdc-icon-size: 0px
            name:
              padding: 0px
            state:
              padding: 0px
        buttons:
          - icon: mdi:backspace-reverse
      # Speed and head direction, then the slider
      - type: entities
        entities:
          - type: custom:paper-buttons-row
            extra_styles: >-
              paper-button:active { transform: scale(var(--press-scale)) }
              paper-button[title^="Turn"]:active, paper-button[title="Oscillate"]:active { transform: none; background-color: var(--fill-strong) !important }
            styles:
              display: flex
              flex-wrap: wrap
              align-items: center
              gap: var(--ha-space-2)
              margin-bottom: var(--ha-space-3)
            base_config:
              layout: icon
              styles:
                button:
                  flex: 1 1 30%
                  min-width: 0px
                  height: var(--control-height-row)
                  padding: 0px
                  justify-content: center
                  border-radius: var(--radius-inner)
                  background-color: var(--fill-subtle)
                  box-shadow: none
                icon:
                  --mdc-icon-size: var(--icon-size-m)
                  margin-right: 0px
                  opacity: var(--opacity-muted)
                name:
                  padding: 0px
                  font-size: var(--ha-font-size-s)
                  font-weight: var(--ha-font-weight-bold)
                state:
                  padding: 0px
                  font-size: var(--ha-font-size-s)
                  font-weight: var(--ha-font-weight-medium)
                  opacity: var(--opacity-quiet)
            buttons:
              # Turns the fan on and off. The icon spins while the fan runs and uses the same colors as the Bubble cards' icons.
              - entity: fan.living_room
                icon: mdi:fan
                tap_action:
                  action: toggle
                state_styles:
                  'on':
                    button:
                      background-color: color-mix(in srgb, var(--org-fan-color) var(--tint-strength), var(--fill-subtle))
                    icon:
                      color: var(--org-fan-color)
                      animation: rotating 2.4s linear infinite
                styles:
                  button:
                    flex: 0 0 auto
                    width: var(--control-height)
                    height: var(--control-height)
                    --org-fan-color: var(--state-fan-on-color, var(--state-fan-active-color, var(--state-active-color)))
                  icon:
                    color: var(--primary-text-color)
                    opacity: 1
              # The speed in percent and its name
              - layout: name_state
                name: >-
                  {{ state_attr('fan.living_room', 'percentage') | int(0) if is_state('fan.living_room', 'on') else 0 }} %
                state: >-
                  {% set p = state_attr('fan.living_room', 'percentage') | float(0) %}
                  {%- if not is_state('fan.living_room', 'on') %}Off
                  {%- elif state_attr('fan.living_room', 'preset_mode') == 'nature' %}Breeze
                  {%- elif p <= 34 %}Low
                  {%- elif p <= 67 %}Medium
                  {%- else %}High{% endif %}
                tap_action:
                  action: none
                hold_action:
                  action: none
                styles:
                  button:
                    flex: 1 1 0px
                    min-width: 0px
                    height: auto
                    margin-left: var(--ha-space-2)
                    align-items: center
                    justify-content: flex-start
                    background-color: transparent
                    box-shadow: none
                    pointer-events: none
                  name:
                    align-self: flex-start
                    padding: 0px
                    font-size: var(--ha-font-size-2xl, 24px)
                    font-weight: var(--ha-font-weight-bold)
                    line-height: var(--ha-line-height-condensed)
                  state:
                    align-self: flex-start
                    margin-top: var(--ha-space-1)
                    padding: 0px
                    font-size: var(--ha-font-size-m)
                    font-weight: var(--ha-font-weight-bold)
                    color: var(--secondary-text-color)
              # Turns the fan's head on fans that use the direction for this. Holding the button repeats the step.
              - icon: mdi:chevron-left
                tooltip: Turn left
                tap_action:
                  action: call-service
                  service: fan.set_direction
                  target:
                    entity_id: fan.living_room
                  service_data:
                    direction: reverse
                hold_action:
                  action: call-service
                  service: fan.set_direction
                  target:
                    entity_id: fan.living_room
                  service_data:
                    direction: reverse
                  repeat: 400
                styles:
                  button:
                    flex: 0 0 auto
                    width: calc(var(--control-height) - var(--ha-space-2))
                    height: var(--control-height)
                    border-radius: var(--radius-inner) 0px 0px var(--radius-inner)
              # The oscillation button is filled while oscillation is on
              - icon: mdi:arrow-left-right
                tooltip: Oscillate
                state: >-
                  {{ 'on' if is_state('fan.living_room', 'on') and state_attr('fan.living_room', 'oscillating') else 'off' }}
                tap_action:
                  action: call-service
                  service: script.fan_oscillation
                  service_data:
                    fan: fan.living_room
                state_styles:
                  'on':
                    icon:
                      color: var(--ha-card-background)
                      background-color: var(--fill-active)
                      opacity: 1
                styles:
                  button:
                    flex: 0 0 auto
                    box-sizing: border-box
                    width: calc(var(--control-height) - var(--ha-space-2))
                    height: var(--control-height)
                    padding: var(--ha-space-1)
                    border-radius: 0px
                    margin-left: calc(0px - var(--ha-space-2))
                  icon:
                    display: flex
                    align-items: center
                    justify-content: center
                    box-sizing: border-box
                    width: 100%
                    height: 100%
                    border-radius: calc(var(--radius-inner) - var(--ha-space-1))
                    transition: var(--transition-interactive)
              - icon: mdi:chevron-right
                tooltip: Turn right
                tap_action:
                  action: call-service
                  service: fan.set_direction
                  target:
                    entity_id: fan.living_room
                  service_data:
                    direction: forward
                hold_action:
                  action: call-service
                  service: fan.set_direction
                  target:
                    entity_id: fan.living_room
                  service_data:
                    direction: forward
                  repeat: 400
                styles:
                  button:
                    flex: 0 0 auto
                    width: calc(var(--control-height) - var(--ha-space-2))
                    height: var(--control-height)
                    border-radius: 0px var(--radius-inner) var(--radius-inner) 0px
                    margin-left: calc(0px - var(--ha-space-2))
          - type: custom:bubble-card
            card_type: button
            button_type: slider
            entity: fan.living_room
            show_name: false
            show_state: false
            show_icon: false
            scrolling_effect: false
            slider_value_position: hidden
            modules:
              - origami_base
              - origami_slider
      # Mode and three speeds, as one segmented row
      - type: custom:paper-buttons-row
        extra_styles: >-
          paper-button:active { background-color: var(--fill-strong) !important }
          paper-button[data-state="on"], paper-button[data-state="on"] + paper-button { background-image: none !important }
        styles:
          align-items: stretch
          margin: 0px 0px var(--ha-space-3) 0px
          padding: 0px
          background-color: transparent
          box-shadow: none
          --pbs-button-bg-color: var(--fill-subtle)
        base_config:
          layout: name
          # The active button shows a filled pill inside the track, like the timer buttons
          state_styles:
            'on':
              button:
                background-color: var(--fill-subtle)
              icon:
                color: var(--ha-card-background)
                background-color: var(--fill-active)
                opacity: 1
              name:
                color: var(--ha-card-background)
                background-color: var(--fill-active)
                opacity: 1
          tap_action:
            action: call-service
            target:
              entity_id: fan.living_room
          styles:
            button:
              flex: 1
              box-sizing: border-box
              height: var(--control-height)
              padding: var(--ha-space-1)
              background-color: var(--fill-subtle)
              border-radius: 0px
              box-shadow: none
              background-image: linear-gradient(var(--fill-loud), var(--fill-loud))
              background-repeat: no-repeat
              background-size: 2px 50%
              background-position: left center
              transition: var(--transition-interactive)
            icon:
              --mdc-icon-size: var(--icon-size-s)
              display: flex
              align-items: center
              justify-content: center
              box-sizing: border-box
              width: 100%
              height: 100%
              margin-right: 0px
              border-radius: calc(var(--radius-inner) - var(--ha-space-1))
              opacity: var(--opacity-strong)
              transition: var(--transition-interactive)
            name:
              display: flex
              align-items: center
              justify-content: center
              box-sizing: border-box
              width: 100%
              height: 100%
              padding: 0px
              border-radius: calc(var(--radius-inner) - var(--ha-space-1))
              font-size: var(--ha-font-size-m)
              font-weight: var(--ha-font-weight-bold)
              opacity: var(--opacity-strong)
              transition: var(--transition-interactive)
        buttons:
          # These are the fan's presets. Use your fan's preset names.
          - layout: icon
            icon: mdi:leaf
            tooltip: Breeze
            state: >-
              {{ 'on' if is_state('fan.living_room', 'on') and state_attr('fan.living_room', 'preset_mode') == 'nature' else 'off' }}
            tap_action:
              service: fan.set_preset_mode
              service_data:
                preset_mode: nature
            styles:
              button:
                flex: 1.5
                border-radius: var(--radius-inner) 0px 0px var(--radius-inner)
                background-image: none
          - layout: icon
            icon: mdi:weather-windy
            tooltip: Normal
            state: >-
              {{ 'on' if is_state('fan.living_room', 'on') and state_attr('fan.living_room', 'preset_mode') != 'nature' else 'off' }}
            tap_action:
              service: fan.set_preset_mode
              service_data:
                preset_mode: normal
            styles:
              button:
                flex: 1.5
                border-radius: 0px var(--radius-inner) var(--radius-inner) 0px
                margin-right: var(--ha-space-2)
          # Three speeds. The button for the current speed range is filled.
          - name: '1'
            tooltip: Low
            state: >-
              {{ 'on' if is_state('fan.living_room', 'on') and state_attr('fan.living_room', 'percentage') | float(0) <= 34 else 'off' }}
            tap_action:
              service: fan.set_percentage
              service_data:
                percentage: 33
            styles:
              button:
                border-radius: var(--radius-inner) 0px 0px var(--radius-inner)
                background-image: none
          - name: '2'
            tooltip: Medium
            state: >-
              {% set p = state_attr('fan.living_room', 'percentage') | float(0) %}{{ 'on' if is_state('fan.living_room', 'on') and 34 < p <= 67 else 'off' }}
            tap_action:
              service: fan.set_percentage
              service_data:
                percentage: 66
          - name: '3'
            tooltip: High
            state: >-
              {{ 'on' if is_state('fan.living_room', 'on') and state_attr('fan.living_room', 'percentage') | float(0) > 67 else 'off' }}
            tap_action:
              service: fan.set_percentage
              service_data:
                percentage: 100
            styles:
              button:
                border-radius: 0px var(--radius-inner) var(--radius-inner) 0px
      # Timer row, shown by the timer button. It turns the fan off after 1, 3 or 5 hours.
      - type: conditional
        conditions:
          - condition: state
            entity: input_boolean.fan_popup_timer
            state: 'on'
        card:
          type: custom:paper-buttons-row
          extra_styles: |
            paper-button:active { transform: scale(var(--press-scale)) }
          styles:
            display: flex
            flex-wrap: wrap
            align-items: center
            gap: var(--ha-space-2)
            padding: 0px
          base_config:
            layout: name
            tap_action:
              action: call-service
              service: timer.start
              target:
                entity_id: timer.living_room_fan
            state_styles:
              'on':
                button:
                  background-color: var(--fill-active)
                  box-shadow: none
                name:
                  color: var(--ha-card-background)
                  opacity: 1
            styles:
              button:
                flex: 1 1 0px
                min-width: 0px
                height: var(--control-height-row)
                padding: 0px var(--ha-space-2)
                justify-content: center
                border-radius: var(--radius-inner)
                background-color: var(--fill-subtle)
              name:
                padding: 0px
                font-size: var(--ha-font-size-s)
                font-weight: var(--ha-font-weight-bold)
              state:
                padding: 0px
                font-size: var(--ha-font-size-s)
                font-weight: var(--ha-font-weight-medium)
                opacity: var(--opacity-quiet)
          buttons:
            # The remaining time
            - layout: name|state
              name: Timer
              state: >-
                {% set t = 'timer.living_room_fan' %}{% set end = as_timestamp(state_attr(t, 'finishes_at'), 0) %}
                {%- if is_state(t, 'active') and end > 0 %}{% set m = ((end - as_timestamp(now())) / 60) | round(0, 'ceil') | int %}{{ m // 60 }}:{{ '%02d' | format(m % 60) }} left
                {%- else %}Off{% endif %}
              tap_action:
                action: none
              hold_action:
                action: none
              styles:
                button:
                  flex: 1 1 100%
                  height: var(--control-height-mini)
                  padding: 0px
                  justify-content: flex-start
                  background-color: transparent
                  box-shadow: none
                  pointer-events: none
                name:
                  padding: 0px
                  font-size: var(--ha-font-size-l)
                  font-weight: var(--ha-font-weight-bold)
                state:
                  margin-left: auto
                  padding: 0px
                  font-size: var(--ha-font-size-s)
                  font-weight: var(--ha-font-weight-medium)
                  opacity: var(--opacity-quiet)
            - name: 'Off'
              state: >-
                {{ 'off' if is_state('timer.living_room_fan', 'active') else 'on' }}
              tap_action:
                service: timer.cancel
            - name: 1 h
              state: >-
                {{ 'on' if is_state('timer.living_room_fan', 'active') and state_attr('timer.living_room_fan', 'duration') == '1:00:00' else 'off' }}
              tap_action:
                service_data:
                  duration: '01:00:00'
            - name: 3 h
              state: >-
                {{ 'on' if is_state('timer.living_room_fan', 'active') and state_attr('timer.living_room_fan', 'duration') == '3:00:00' else 'off' }}
              tap_action:
                service_data:
                  duration: '03:00:00'
            - name: 5 h
              state: >-
                {{ 'on' if is_state('timer.living_room_fan', 'active') and state_attr('timer.living_room_fan', 'duration') == '5:00:00' else 'off' }}
              tap_action:
                service_data:
                  duration: '05:00:00'

Helpers

Most of the logic is in template sensors, so the cards usually only display a result. All helpers are in packages/origami.yaml, together with the scripts that the pop-ups use. To use the helpers in your home, make these changes.

Copy one Climate | <room> block for each room and set its two source sensors.
The peak and average sensors build sensor names from a list of rooms, such as sensor.<room>_temperature. Name your sensors in the same way, or change these templates.
Add your lights, window contacts and speakers to the counters, to sensor.active_target, to sensor.active_speaker and to input_select.selected_speaker.
Add your scenes to sensor.living_room_scene, and add your fan to the Living room fan timer automation.
Assign your devices to areas so that Everything off in a room pop-up can find them.

Helper	Purpose
`sensor.climate_<room>`	A room's rounded temperature and humidity, rank and comfort color
`sensor.climate_temperature_peaks`, `sensor.climate_humidity_peaks`	The warmest room and the most humid room. The coldest and driest rooms are attributes.
`sensor.temperature_average`, `sensor.humidity_average`, `sensor.climate_home`	The averages, the open windows and the front door
`sensor.windows_open_count`, `sensor.lights_on_count`, `sensor.active_speaker_count`	The number of open windows, lights that are on and speakers that are playing
`sensor.greetings`	The greeting
`sensor.active_target`, `sensor.active_speaker`	The most relevant speaker and what it is playing
`input_boolean.room_climate_card`, `input_boolean.all_rooms`, `input_select.selected_speaker`	The toggles for the climate table and the extra rooms, and the speaker to show when nothing is playing
`sensor.living_room_scene`, `input_boolean.living_room_scenes`	The scene that was turned on last, and the toggle for the scenes in the room pop-up
`timer.living_room_fan`, `input_boolean.fan_popup_timer`	The fan pop-up's timer and the toggle for its timer row
`script.fan_oscillation`, `script.volume`, `script.thermostat_step`, `script.room_off`	The actions for the pop-up buttons
The Living room fan timer automation	Turning the fan off when its timer ends

Room climate sensor

Each room has one climate sensor. The state is the temperature rounded to one decimal place, and the cards read the attributes.

template:
  - sensor:
      - name: Climate | Living room
        unique_id: climate_living_room
        icon: mdi:thermometer
        state: >
          {% set t = states('sensor.living_room_temperature') | float(none) %}
          {{ t | round(1) if t is not none else '?' }}
        attributes:
          temperature: >
            {% set t = states('sensor.living_room_temperature') | float(none) %}
            {{ t | round(0) | int if t is not none else '?' }}
          humidity: >
            {% set h = states('sensor.living_room_humidity') | float(none) %}
            {{ h | round(0) | int if h is not none else '?' }}
          temp_rank: >
            {{ 'warmest' if is_state('sensor.climate_temperature_peaks', 'living_room')
               else 'coldest' if is_state_attr('sensor.climate_temperature_peaks', 'lowest', 'living_room')
               else 'normal' }}
          humidity_rank: >
            {{ 'most_humid' if is_state('sensor.climate_humidity_peaks', 'living_room')
               else 'driest' if is_state_attr('sensor.climate_humidity_peaks', 'lowest', 'living_room')
               else 'normal' }}
          color_code: >
            {% set t = states('sensor.living_room_temperature') | float(20) %}
            {% set scale = [(12, '114, 143, 168'), (15, '124, 151, 169'), (17, '139, 162, 168'),
               (18.5, '154, 174, 163'), (22, '136, 163, 126'), (24, '153, 166, 119'),
               (25, '174, 167, 111'), (26, '187, 159, 104'), (27, '192, 147, 95'),
               (28, '191, 138, 95'), (29, '187, 126, 93'), (30.5, '179, 115, 92'),
               (32, '170, 106, 90'), (99, '156, 96, 86')] %}
            rgba({{ (scale | selectattr(0, '>=', t) | first)[1] }}, 0.7)

If the source sensor is missing, the temperature and humidity show ?, so the card keeps its size. The comfort dot then uses the color for 20°.
The comfort color goes from blue at 12° to red above 32°. The color is slightly transparent so that it works in both modes.
The peak sensors return none when fewer than two rooms report a value or when all values are equal. In that case, no room gets an arrow.

Active speaker

sensor.active_target selects the speaker to show. It prefers a speaker that is playing, then a speaker on a TV input or on Bluetooth, then a paused speaker, and finally input_select.selected_speaker. If the playing speaker is part of a group, the sensor uses the group leader. sensor.active_speaker has the same state and adds what the speaker is playing. The navigation bar reads this second sensor.

Attribute	Content
`chip`	`playing_art`, `playing_plain`, `paused_art`, `paused_plain`, `tv_art`, `tv_plain` or `off`. `_art` means that a picture is available. For music, this is the cover from Music Assistant. For the TV input, it is the `artwork` attribute of `sensor.tv_source`.
`title`	While music is playing, the title is `Title \| Artist`. Otherwise, it is a short label such as `Bluetooth`, `TV`, `Paused` or `Nothing playing`, so it is never empty.
`speaker`	The speaker's short name, with a count while it is grouped, such as `Living +1`
`group`	`yes` or `no`
`artwork`	The cover or the TV picture, or `none`

The example uses LinkPlay speakers. Each speaker also has a player in Music Assistant, such as media_player.<name>_mass. This player provides the title and cover while the speaker is playing from Music Assistant. The Music Assistant player also reports playing while the speaker plays over Bluetooth or from one of its own streaming sources, so the sensor ignores the player in these cases. Without a Music Assistant player, the sensor uses the speaker's own title and cover, and chip never uses playing_art or paused_art.

The sensor finds the TV input and Bluetooth by name in the speaker's source. It treats optical, coaxial, HDMI and line inputs as TV inputs. Other brands may use different names. sensor.tv_source is optional. Its display and artwork attributes provide the name and picture of what is playing on the TV input.

Techniques

These techniques appear in several places in the dashboard.

Paper Buttons Row as a card

Paper Buttons Row has no background when you use it as a card. To make it look like a card, give the row a background, a corner radius and padding. With display: grid, you can arrange the buttons in rows and columns, as in the climate table. The room cards, the climate table and the server card are each a single Paper Buttons Row.

type: custom:paper-buttons-row
styles:
  padding: var(--ha-space-4)
  background-color: var(--fill-subtle)
  border-radius: var(--ha-card-border-radius)
buttons:
  - entity: light.living_room

Logic in sensors

Where possible, a sensor turns numbers into a single word, and the card changes its look based on that word. In this example from the climate table, a room gets an arrow when it is the warmest or the coldest room.

- entity: sensor.climate_living_room
  icon: mdi:thermometer
  name:
    attribute: temperature
    postfix: °
  state:
    attribute: temp_rank
  state_icons:
    warmest: mdi:arrow-up
    coldest: mdi:arrow-down

No layout shifts

Cards have fixed heights, so long text never moves other elements.
State changes affect colors, but never sizes.
The room helpers return ? instead of an empty value.
Elements that appear and disappear either take no space while they are hidden or keep their space and scale in and out.
Templates run in the browser where possible. The ${ } templates in the Header and Tiles modules and the [[[ ]]] templates in Navbar Card render in the first frame. Jinja templates have to wait for the server.
The font loads from Home Assistant itself. A font that loads late makes all text redraw.
The main view uses grid cards instead of stack cards where it needs a wrapper.

One tap target for each card

Give the row position: relative. An invisible button covers the whole row and receives every tap. All other buttons get pointer-events: none.

type: custom:paper-buttons-row
styles:
  position: relative
base_config:
  styles:
    button:
      pointer-events: none
buttons:
  - entity: light.living_room
    layout: name
    name: false
    tap_action:
      action: navigate
      navigation_path: '#popup_living_room'
    styles:
      button:
        position: absolute
        inset: 0px
        z-index: 3
        pointer-events: all
        border-radius: var(--ha-card-border-radius)

Hidden until needed

The favorites use Bubble Card's visibility conditions. The extra rooms and the climate table appear while a toggle is on. Hidden elements leave no gap.

Sorting tiles

The tiles are sorted with the CSS order property. The oven comes first with order: -2, and the vacuum follows while it is cleaning.

origami_tiles:
  order:
    cleaning: -1

Striped rows

The climate table's background is a single repeating gradient, which is as tall as two table rows. In repeat(6, …), the 6 is the number of rooms.

styles:
  grid-template-rows: repeat(6, var(--control-height-icon))
  background-image: >-
    repeating-linear-gradient(to bottom, transparent, transparent var(--control-height-icon),
    var(--fill-subtle) var(--control-height-icon), var(--fill-subtle) calc(var(--control-height-icon) * 2))

Scaling instead of hiding

To show and hide an element without moving anything else, scale it instead of removing it. CSS cannot read entity states, so a Navbar Card template writes the group state into a CSS variable.

document.documentElement.style.setProperty('--navbar-player-group', a.group === 'yes' ? '1' : '0');

The group badge on the cover scales with this variable.

.media-player::before,
.media-player::after {
  scale: var(--navbar-player-group, 0);
  transition: scale var(--duration-normal) var(--ease-standard);
}

Theme

The theme is a set of tokens. Home Assistant reads these tokens, and so do the cards and modules. To change the style, copy origami.yaml to a new file in /config/themes, such as my-origami.yaml. Give the theme in the copy a new name by changing Origami: at the top, and then edit its tokens. Do not edit the original file, because a HACS update replaces it.

Color

Color mostly shows that something is on. The icon is colored, and the area behind it uses tint, which mixes the same color into the card background. The mix is 14% in light mode and 4% in dark mode. tint uses currentColor, so set color on the same element.

Home Assistant decides which color a device gets, for example deep orange for heating and light blue for media. Origami adjusts the tone of these colors and changes a few of them. Switches and other entities without a color of their own are green instead of amber when they are on, and open windows are cyan. Paused media players and people who are away use the secondary text color, and closed covers and disarmed alarm panels use the accent color.

To change a color, add state-<domain>-active-color to your copy of the theme. Domains with a color for each state need state-<domain>-<state>-color, such as state-climate-heat-color.

Paper Buttons Row

The name Origami comes from Paper Buttons Row, because origami is folded paper. Paper Buttons Row has its own color variables, pbs-button-*, and the theme sets them to the text color. Entity buttons that are on still use their state color. To turn this off, set active: [], as in the room cards. The rgb variables need a triplet such as var(--rgb-primary-text-color), because a hex value breaks the color.

Tokens

Token	Purpose
`ha-space-1` … `ha-space-5`	Spacing from 4 to 20 px
`ha-card-border-radius`	The card corner radius, 22 px. `radius-inner` is this value divided by 1.3, about 17 px. `radius-small` is 8 px.
`border-width`, `border-contrast`	Card outlines, which are off by default
`card-shadow`, `card-shadow-flat`, `shadow-elevated`	Shadows for each mode. `card-shadow-flat` only has the small contact shadow, and the card above the navigation bar uses `shadow-elevated`.
`fill-subtle`, `fill-strong`, `fill-loud`	Neutral surfaces, mixed from `fill-base` so that they stay warm
`fill-contrast`	The strength of `fill-subtle`, 8% in light mode and 5% in dark mode
`fill-active`, `toggle-on`	The text color at 85% on the card background, for switch tracks and active buttons
`tile-background`, `tile-chip-background`	A tile's background and its icon's background
`opacity-disabled`, `opacity-quiet`, `opacity-muted`, `opacity-strong`	Opacity levels of 0.3, 0.45, 0.6 and 0.8
`control-height-mini`, `-icon`, `-row`, `-list`, `-sm`, `control-height`, `-lg`	Fixed control heights of 32, 40, 44, 48, 52, 56 and 64 px
`tile-size`, `tile-size-lg`, `dot-size`	Icon backgrounds of 48 and 80 px, and dots of 12 px
`icon-size-2xs` … `icon-size-xl`	Icon sizes from 14 to 48 px
`ha-font-size-xs` … `ha-font-size-xl`	Text sizes from 14 to 22 px
`primary-font-family`	Montserrat in weights 500 and 700
`duration-fast`, `duration-normal`, `duration-slow`, `ease-standard`	Animation timing
`press-scale`	How much a button shrinks when you press it
`blur-soft`, `blur-strong`	The blur behind the header, dialogs and the navigation bar
`tint-strength`, `fill-strength`	The amount of state color in `tint` (14% in light mode, 4% in dark mode) and in colored fills such as sliders (32% and 30%)
`amber-color`, `green-color`, …	Home Assistant's named colors, with adjusted tones

Troubleshooting

Origami is not in the theme list

Home Assistant only loads themes when configuration.yaml contains the themes line. Add the line, restart Home Assistant and select Origami in your profile.

HACS cannot find Origami

Origami is not in the default HACS store. Use the Open in HACS button under Setup, which adds the repository for you.

A card shows "Custom element doesn't exist"

The card is not installed, or the browser is still using an old version of the page. Install the card and reload the page. In the Companion app, select Reset frontend cache in the app settings.

The font does not change

In a browser, open /local/fonts/montserrat.css on your Home Assistant server, for example http://homeassistant.local:8123/local/fonts/montserrat.css. The file should contain two @font-face rules. If the file does not open, check that the font files are in /config/www/fonts, and restart Home Assistant if you just created the www folder. If the file opens, check that it is under Resources as a Stylesheet and that Origami is your theme. Then reload the page.

Bubble cards look plain

The modules are not loaded. Check that Bubble Card Tools is added as an integration and that the module files are in /config/bubble_card/modules/. Then reload the page.

A tap does not open a pop-up

The pop-up must be in the same view as the button, and its hash must match the button's navigation_path, such as #popup_tv. The included pop-ups are at the end of dashboard.yaml, under # Pop-ups. Bubble Card must also be installed.

A value shows a question mark

A helper cannot find its source sensor. Replace the example sensors in /config/packages/origami.yaml with your own. Then reload Template entities under YAML configuration reloading.

Loading the font from Google Fonts

Instead of copying the font files, you can add https://fonts.googleapis.com/css2?family=Montserrat:wght@500;700&display=swap as the stylesheet. In that case, the font loads from Google's servers. It may arrive after the page, and then all text redraws.

Status

Theme, dashboard and helpers
Bubble Card modules, which are still experimental
Pop-ups for a room, the TV and the fan
More pop-ups, such as those for music, lights, favorites and the server
Desktop layout

License

Origami is licensed under AGPL-3.0. The Montserrat files in www/fonts remain under their own SIL Open Font License.

hazymorning/origami

Historique des étoiles

Rang dans ses thèmes

Signaux de santé

README

Setup

Dashboard

Greeting and notifications

Menu

Weather

Favorites

Rooms

Climate table

Navigation bar

Pop-ups

Room

TV

Fan

Helpers

Techniques

Theme

Troubleshooting

Status

License

0xProbabillity/house-control

NousResearch/hermes-official-plugins

acosta290/fluvy

bertel2020/HA-Housekeeper

Menu

hazymorning/origami

Croissance

Historique des étoiles

Rang dans ses thèmes

Signaux de santé

README

Setup

Dashboard

Greeting and notifications

Menu

Weather

Favorites

Rooms

Climate table

Navigation bar

Pop-ups

Room

TV

Fan

Helpers

Techniques

Theme

Troubleshooting

Status

License
