rockorager/libvaxis

libvaxis

It begins with them, but ends with me. Their son, Vaxis

Features

Usage

Add libvaxis to your project

zig fetch --save git+https://github.com/rockorager/libvaxis.git

    const vaxis = b.dependency("vaxis", .{
        .target = target,
        .optimize = optimize,
    });

    exe.root_module.addImport("vaxis", vaxis.module("vaxis"));

    // create module
    const exe_mod = b.createModule(.{
        .root_source_file = b.path("src/main.zig"),
        .target = target,
        .optimize = optimize,
    });

    // add vaxis dependency to module
    const vaxis = b.dependency("vaxis", .{
        .target = target,
        .optimize = optimize,
    });
    exe_mod.addImport("vaxis", vaxis.module("vaxis"));

    //create executable
    const exe = b.addExecutable(.{
        .name = "project_foo",
        .root_module = exe_mod,
    });
    // install exe below

Sharing uucode with your application

    const uucode = b.dependency("uucode", .{
        .target = target,
        .optimize = optimize,
        .fields = @as([]const []const u8, &.{
            // Add any fields your application needs, plus the fields libvaxis
            // requires. The compiler will tell you which fields are missing
            // (you only need the libvaxis fields for the parts of libvaxis you
            // actually use). See `build.zig` in libvaxis for the full set it
            // uses internally.
        }),
    });

    const vaxis = b.dependency("vaxis", .{
        .target = target,
        .optimize = optimize,
        .external_uucode = true,
    });
    vaxis.module("vaxis").addImport("uucode", uucode.module("uucode"));

    exe.root_module.addImport("vaxis", vaxis.module("vaxis"));
    exe.root_module.addImport("uucode", uucode.module("uucode"));

vxfw (Vaxis framework)

const std = @import("std");
const vaxis = @import("vaxis");
const vxfw = vaxis.vxfw;

/// Our main application state
const Model = struct {
    /// State of the counter
    count: u32 = 0,
    /// The button. This widget is stateful and must live between frames
    button: vxfw.Button,

    /// Helper function to return a vxfw.Widget struct
    pub fn widget(self: *Model) vxfw.Widget {
        return .{
            .userdata = self,
            .eventHandler = Model.typeErasedEventHandler,
            .drawFn = Model.typeErasedDrawFn,
        };
    }

    /// This function will be called from the vxfw runtime.
    fn typeErasedEventHandler(ptr: *anyopaque, ctx: *vxfw.EventContext, event: vxfw.Event) anyerror!void {
        const self: *Model = @ptrCast(@alignCast(ptr));
        switch (event) {
            // The root widget is always sent an init event as the first event. Users of the
            // library can also send this event to other widgets they create if they need to do
            // some initialization.
            .init => return ctx.requestFocus(self.button.widget()),
            .key_press => |key| {
                if (key.matches('c', .{ .ctrl = true })) {
                    ctx.quit = true;
                    return;
                }
            },
            // We can request a specific widget gets focus. In this case, we always want to focus
            // our button. Having focus means that key events will be sent up the widget tree to
            // the focused widget, and then bubble back down the tree to the root. Users can tell
            // the runtime the event was handled and the capture or bubble phase will stop
            .focus_in => return ctx.requestFocus(self.button.widget()),
            else => {},
        }
    }

    /// This function is called from the vxfw runtime. It will be called on a regular interval, and
    /// only when any event handler has marked the redraw flag in EventContext as true. By
    /// explicitly requiring setting the redraw flag, vxfw can prevent excessive redraws for events
    /// which don't change state (ie mouse motion, unhandled key events, etc)
    fn typeErasedDrawFn(ptr: *anyopaque, ctx: vxfw.DrawContext) std.mem.Allocator.Error!vxfw.Surface {
        const self: *Model = @ptrCast(@alignCast(ptr));
        // The DrawContext is inspired from Flutter. Each widget will receive a minimum and maximum
        // constraint. The minimum constraint will always be set, even if it is set to 0x0. The
        // maximum constraint can have null width and/or height - meaning there is no constraint in
        // that direction and the widget should take up as much space as it needs. By calling size()
        // on the max, we assert that it has some constrained size. This is *always* the case for
        // the root widget - the maximum size will always be the size of the terminal screen.
        const max_size = ctx.max.size();

        // The DrawContext also contains an arena allocator that can be used for each frame. The
        // lifetime of this allocation is until the next time we draw a frame. This is useful for
        // temporary allocations such as the one below: we have an integer we want to print as text.
        // We can safely allocate this with the ctx arena since we only need it for this frame.
        const count_text = try std.fmt.allocPrint(ctx.arena, "{d}", .{self.count});
        const text: vxfw.Text = .{ .text = count_text };

        // Each widget returns a Surface from its draw function. A Surface contains the rectangular
        // area of the widget, as well as some information about the surface or widget: can we focus
        // it? does it handle the mouse?
        //
        // It DOES NOT contain the location it should be within its parent. Only the parent can set
        // this via a SubSurface. Here, we will return a Surface for the root widget (Model), which
        // has two SubSurfaces: one for the text and one for the button. A SubSurface is a Surface
        // with an offset and a z-index - the offset can be negative. This lets a parent draw a
        // child and place it within itself
        const text_child: vxfw.SubSurface = .{
            .origin = .{ .row = 0, .col = 0 },
            .surface = try text.draw(ctx),
        };

        const button_child: vxfw.SubSurface = .{
            .origin = .{ .row = 2, .col = 0 },
            .surface = try self.button.draw(ctx.withConstraints(
                ctx.min,
                // Here we explicitly set a new maximum size constraint for the Button. A Button will
                // expand to fill its area and must have some hard limit in the maximum constraint
                .{ .width = 16, .height = 3 },
            )),
        };

        // We also can use our arena to allocate the slice for our SubSurfaces. This slice only
        // needs to live until the next frame, making this safe.
        const children = try ctx.arena.alloc(vxfw.SubSurface, 2);
        children[0] = text_child;
        children[1] = button_child;

        return .{
            // A Surface must have a size. Our root widget is the size of the screen
            .size = max_size,
            .widget = self.widget(),
            // We didn't actually need to draw anything for the root. In this case, we can set
            // buffer to a zero length slice. If this slice is *not zero length*, the runtime will
            // assert that its length is equal to the size.width * size.height.
            .buffer = &.{},
            .children = children,
        };
    }

    /// The onClick callback for our button. This is also called if we press enter while the button
    /// has focus
    fn onClick(maybe_ptr: ?*anyopaque, ctx: *vxfw.EventContext) anyerror!void {
        const ptr = maybe_ptr orelse return;
        const self: *Model = @ptrCast(@alignCast(ptr));
        self.count +|= 1;
        return ctx.consumeAndRedraw();
    }
};

pub fn main(init: std.process.Init) !void {
    const io = init.io;
    const alloc = init.gpa;

    var buffer: [1024]u8 = undefined;
    var app: vxfw.App = try .init(io, alloc, init.environ_map, &buffer);
    defer app.deinit();

    // We heap allocate our model because we will require a stable pointer to it in our Button
    // widget
    const model = try alloc.create(Model);
    defer alloc.destroy(model);

    // Set the initial state of our button
    model.* = .{
        .count = 0,
        .button = .{
            .label = "Click me!",
            .onClick = Model.onClick,
            .userdata = model,
        },
    };

    try app.run(model.widget(), .{});
}

Low level API

const std = @import("std");
const vaxis = @import("vaxis");
const Cell = vaxis.Cell;
const TextInput = vaxis.widgets.TextInput;
const border = vaxis.widgets.border;

// This can contain internal events as well as Vaxis events.
// Internal events can be posted into the same queue as vaxis events to allow
// for a single event loop with exhaustive switching. Booya
const Event = union(enum) {
    key_press: vaxis.Key,
    winsize: vaxis.Winsize,
    focus_in,
    foo: u8,
};

pub fn main(init: std.process.Init) !void {
    const io = init.io;
    const alloc = init.gpa;

    // Initialize a tty
    var buffer: [1024]u8 = undefined;
    var tty = try vaxis.Tty.init(io, &buffer);
    defer tty.deinit();

    // Initialize Vaxis
    var vx = try vaxis.init(io, alloc, init.environ_map, .{});
    // deinit takes an optional allocator. If your program is exiting, you can
    // choose to pass a null allocator to save some exit time.
    defer vx.deinit(alloc, tty.writer());


    // The event loop requires an intrusive init. We create an instance with
    // stable pointers to Vaxis and our TTY, then init the instance. Doing so
    // installs a signal handler for SIGWINCH on posix TTYs
    //
    // This event loop is thread safe. It reads the tty in a separate thread
    var loop: vaxis.Loop(Event) = .init(io, &tty, &vx);

    // Start the read loop. This puts the terminal in raw mode and begins
    // reading user input
    try loop.start();
    defer loop.stop();

    // Optionally enter the alternate screen
    try vx.enterAltScreen(tty.writer());

    // We'll adjust the color index every keypress for the border
    var color_idx: u8 = 0;

    // init our text input widget. The text input widget needs an allocator to
    // store the contents of the input
    var text_input = TextInput.init(alloc);
    defer text_input.deinit();

    // Sends queries to terminal to detect certain features. This should always
    // be called after entering the alt screen, if you are using the alt screen
    try vx.queryTerminal(tty.writer(), .fromSeconds(1));

    while (true) {
        // nextEvent blocks until an event is in the queue
        const event = try loop.nextEvent();
        // exhaustive switching ftw. Vaxis will send events if your Event enum
        // has the fields for those events (ie "key_press", "winsize")
        switch (event) {
            .key_press => |key| {
                color_idx = switch (color_idx) {
                    255 => 0,
                    else => color_idx + 1,
                };
                if (key.matches('c', .{ .ctrl = true })) {
                    break;
                } else if (key.matches('l', .{ .ctrl = true })) {
                    vx.queueRefresh();
                } else {
                    try text_input.update(.{ .key_press = key });
                }
            },

            // winsize events are sent to the application to ensure that all
            // resizes occur in the main thread. This lets us avoid expensive
            // locks on the screen. All applications must handle this event
            // unless they aren't using a screen (IE only detecting features)
            //
            // The allocations are because we keep a copy of each cell to
            // optimize renders. When resize is called, we allocated two slices:
            // one for the screen, and one for our buffered screen. Each cell in
            // the buffered screen contains an ArrayList(u8) to be able to store
            // the grapheme for that cell. Each cell is initialized with a size
            // of 1, which is sufficient for all of ASCII. Anything requiring
            // more than one byte will incur an allocation on the first render
            // after it is drawn. Thereafter, it will not allocate unless the
            // screen is resized
            .winsize => |ws| try vx.resize(alloc, tty.writer(), ws),
            else => {},
        }

        // vx.window() returns the root window. This window is the size of the
        // terminal and can spawn child windows as logical areas. Child windows
        // cannot draw outside of their bounds
        const win = vx.window();

        // Clear the entire space because we are drawing in immediate mode.
        // vaxis double buffers the screen. This new frame will be compared to
        // the old and only updated cells will be drawn
        win.clear();

        // Create a style
        const style: vaxis.Style = .{
            .fg = .{ .index = color_idx },
        };

        // Create a bordered child window
        const child = win.child(.{
            .x_off = win.width / 2 - 20,
            .y_off = win.height / 2 - 3,
            .width = 40 ,
            .height = 3 ,
            .border = .{
                .where = .all,
                .style = style,
            },
        });

        // Draw the text_input in the child window
        text_input.draw(child);

        // Render the screen. Using a buffered writer will offer much better
	// performance, but is not required
        try vx.render(tty.writer());
    }
}

C library

zig build lib

#include <vaxis.h>

vaxis_parser *parser = vaxis_parser_new();

const vaxis_event *event;
size_t consumed;
// bytes read from the tty
const uint8_t input[] = "\x1b[97:65;2u";
vaxis_parser_parse(parser, input, sizeof(input) - 1, &event, &consumed);
// vaxis_event_get_type(event) == VAXIS_EVENT_KEY_PRESS
// vaxis_event_key_matches(event, 'a', VAXIS_MOD_SHIFT) == true

vaxis_parser_free(parser);

Contributing

Community
