Overview
redroid (Remote anDroid) is a GPU accelerated AIC (Android In Cloud) solution. You can boot many
instances in Linux host (Docker, podman, k8s etc.). redroid supports both arm64 and amd64 architectures.
redroid is suitable for Cloud Gaming, Virtualise Phones, Automation Test and more.
Currently supported:
- Android 16 (
redroid/redroid:16.0.0-latest) - Android 16 64bit only (
redroid/redroid:16.0.0_64only-latest) - Android 15 (
redroid/redroid:15.0.0-latest) - Android 15 64bit only (
redroid/redroid:15.0.0_64only-latest) - Android 14 (
redroid/redroid:14.0.0-latest) - Android 14 64bit only (
redroid/redroid:14.0.0_64only-latest) - Android 13 (
redroid/redroid:13.0.0-latest) - Android 13 64bit only (
redroid/redroid:13.0.0_64only-latest) - Android 12 (
redroid/redroid:12.0.0-latest) - Android 12 64bit only (
redroid/redroid:12.0.0_64only-latest) - Android 11 (
redroid/redroid:11.0.0-latest) - Android 10 (
redroid/redroid:10.0.0-latest) - Android 9 (
redroid/redroid:9.0.0-latest) - Android 8.1 (
redroid/redroid:8.1.0-latest)
Getting Started
redroid should be able to run on any linux distribution (with some kernel features enabled).
Quick start on Ubuntu 20.04 here; Check deploy section for other distros.
## install docker https://docs.docker.com/engine/install/#server ## install required kernel modules apt install linux-modules-extra-`uname -r` modprobe binder_linux devices="binder,hwbinder,vndbinder" modprobe ashmem_linux ## running redroid docker run -itd --rm --privileged \ --pull always \ -v ~/data:/data \ -p 5555:5555 \ redroid/redroid:12.0.0_64only-latest ### Explanation: ### --pull always -- use latest image ### -v ~/data:/data -- mount data partition ### -p 5555:5555 -- expose adb port ### DISCLAIMER ### Should NOT expose adb port on public network ### otherwise, redroid container (even host OS) may get compromised ## install adb https://developer.android.com/studio#downloads adb connect localhost:5555 ### NOTE: change localhost to IP if running redroid remotely ## view redroid screen ## install scrcpy https://github.com/Genymobile/scrcpy/blob/master/README.md#get-the-app scrcpy -s localhost:5555 ### NOTE: change localhost to IP if running redroid remotely ### typically running scrcpy on your local PC
Configuration
## running redroid with custom settings (custom display for example)
docker run -itd --rm --privileged \
--pull always \
-v ~/data:/data \
-p 5555:5555 \
redroid/redroid:12.0.0_64only-latest \
androidboot.redroid_width=1080 \
androidboot.redroid_height=1920 \
androidboot.redroid_dpi=480 \
| Param | Description | Default |
|---|---|---|
androidboot.redroid_width |
display width | 720 |
androidboot.redroid_height |
display height | 1280 |
androidboot.redroid_fps |
display FPS | 30(GPU enabled) 15 (GPU not enabled) |
androidboot.redroid_dpi |
display DPI | 320 |
androidboot.use_memfd |
use memfd to replace deprecated ashmemplan to enable by default |
false |
androidboot.use_redroid_overlayfs |
use overlayfs to share data partition/data-base: shared data partition/data-diff: private data |
0 |
androidboot.redroid_net_ndns |
number of DNS server, 8.8.8.8 will be used if no DNS server specified |
0 |
androidboot.redroid_net_dns<1..N> |
DNS | |
androidboot.redroid_net_proxy_type |
Proxy type; choose from: static, pac, none, unassigned |
|
androidboot.redroid_net_proxy_host |
||
androidboot.redroid_net_proxy_port |
3128 | |
androidboot.redroid_net_proxy_exclude_list |
comma seperated list | |
androidboot.redroid_net_proxy_pac |
||
androidboot.redroid_gpu_mode |
choose from: auto, host, guest;guest: use software rendering;host: use GPU accelerated rendering;auto: auto detect |
guest |
androidboot.redroid_gpu_node |
auto-detect | |
ro.xxx |
DEBUG purpose, allow override ro.xxx prop; For example, set ro.secure=0, then root adb shell provided by default |
Native Bridge Support
It's possible to run arm Apps in x86 redroid instance via libhoudini, libndk_translation or QEMU translator.
Check @zhouziyang/libndk_translation for prebuilt libndk_translation.
Published redroid images already got libndk_translation included.
# example structure, be careful the file owner and mode
system/
├── bin
│ ├── arm
│ └── arm64
├── etc
│ ├── binfmt_misc
│ └── init
├── lib
│ ├── arm
│ └── libnb.so
└── lib64
├── arm64
└── libnb.so# Dockerfile FROM redroid/redroid:11.0.0-latest ADD native-bridge.tar /
# build docker image docker build . -t redroid:11.0.0-nb # running docker run -itd --rm --privileged \ -v ~/data11-nb:/data \ -p 5555:5555 \ redroid:11.0.0-nb \
GMS Support
It's possible to add GMS (Google Mobile Service) support in redroid via Open GApps, MicroG or MindTheGapps.
Check android-builder-docker for details.
WebRTC Streaming
Plan to port WebRTC solutions from cuttlefish, including frontend (HTML5), backend and many virtual HALs.
How To Build
It's the same way as AOSP building process, but I suggest to use docker to build it.
Check android-builder-docker for details.
Troubleshooting
- How to collect debug blobs
curl -fsSL https://raw.githubusercontent.com/remote-android/redroid-doc/master/debug.sh | sudo bash -s -- [CONTAINER]omit CONTAINER if not exist any more
- Container disappeared immediately
make sure the required kernel modules are installed; run
dmesg -Tfor detailed logs
- Container running, but adb cannot connect (device offline etc.)
run
docker exec -it <container> sh, then checkps -Aandlogcattry
dmesg -Tif cannot get a container shell
Contact Me
License
redroid itself is under Apache License, since redroid includes many 3rd party modules, you may need to examine license carefully.
redroid kernel modules are under GPL v2
