madmorett/bullpane

Bullpane

A fast, self-hosted dashboard for BullMQ and BullMQ Pro.

bullpane.com · Live demo · Documentation · Changelog · llms.txt

Point it at the Redis your workers already use and get queues, jobs, failures, progress, logs, flows and Pro groups in a UI that is pleasant to look at.

The free edition asks for nothing: no account, no login, no first-run wizard. Start the container, open it, use it.

Works with BullMQ 4, 5 and 6 on Redis, Redis Cluster and Valkey, with BullMQ Pro, and with BullMQ 6 on PostgreSQL (behind PgBouncer, over TLS, or with a read-only role): npx bullpane --postgres postgres://user:pass@host:5432/db. See docs/POSTGRES.md.

It exists because the alternatives make you choose. bull-board is a viewer: no search inside job data, no roles, no alerts. Taskforce.sh is hosted, so your job payloads transit its servers, and it is priced per connection. Bullpane runs in a single container next to your stack, is free for the core, and USD 39/month (or 390/year) unlocks the team features for one installation with unlimited users.

A dashboard that slows down the workload it watches is worse than no dashboard. These rules are enforced in packages/redis-inspector, which owns every read of your Redis:

1. No KEYS, ever. Discovery is a bounded SCAN, cached.
2. One round trip per read. Counts, pages and details are Lua scripts (EVALSHA); multi-queue reads are one pipeline.
3. Truncate inside Redis. Lists return string.sub(data, 1, previewBytes), so a queue of 500 KB payloads renders as cheaply as a queue of tiny ones.
4. Search is bounded and resumable. At most N job hashes per call, a cursor comes back, the UI streams results in.
5. Writes use the official bullmq library. Retry, promote, remove and clean inherit BullMQ's atomic scripts and stay correct across versions.
6. Cluster safe. Each script touches keys of exactly one queue (one hash tag).
7. Connections fail fast. 5 s connect timeout, one retry, no offline queue — a dead Redis is a red badge, not a hung dashboard.

Measured command by command in deploy/ecs/REDIS-SAFETY.md, and held to it by the harness in docs/STRESS-TEST.md.

BullMQ 6 can keep queues in PostgreSQL. Add a connection of kind Postgres and Bullpane reads BullMQ's own schema with the same rules: one SQL statement per read, every job query on its partial index, payloads truncated in SQL, and writes through the official bullmq API. It never runs migrations on your database. Details, costs and the differences from Redis: docs/POSTGRES.md.

docker run -d -p 3000:3000 -v bullpane-data:/data bullpane/bullpane

No Docker? npx bullpane --redis redis://localhost:6379 runs the same dashboard on your machine (Node 20+, listens on 127.0.0.1, data in ~/.bullpane).

No database to set up: the dashboard keeps its own data (connections, settings, and on Pro users, alerts and the audit log) in a SQLite file in /data. Keep the volume, or that data dies with the container. Prefer Compose? docker compose up -d does the same with this repository's docker-compose.yml.

1. Open http://localhost:3000. The free edition drops you straight into the dashboard — there is nothing to sign up for.
2. Connections → Add: Redis URL, BullMQ prefix (bull unless you changed it), cluster yes/no. Queues are discovered by scanning for prefix:*:meta, cached for 30 s.
3. That is it. Add more connections for staging/prod, or other prefixes.

MySQL is optional. Running more than one replica, or want a managed database? Set DATABASE_URL=mysql://user:pass@host:3306/bullpane (MySQL 8 or MariaDB) and Bullpane uses it instead. With Compose, COMPOSE_PROFILES=mysql in .env also starts a bundled MySQL (see the header of docker-compose.yml). The image is one Node process: put it behind your reverse proxy and set PUBLIC_URL so alert links point at the right host.

Read docs/PRODUCTION-TRIAL.md before pointing it at a busy production Redis, and deploy/README.md for EC2, ECS Fargate and Compose.

A throwaway Redis plus a simulator that behaves like a mid-sized company:

git clone https://github.com/madmorett/bullpane && cd bullpane
pnpm demo        # = docker compose -f docker-compose.demo.yml up --build

Open http://localhost:3000 and log in with demo@bullpane.com / demo1234.

Payments with ~4% declines, a bursty webhook dispatcher whose worker "dies" every four minutes, a rate-limited SMS queue, real BullMQ flows (ingest → transform → load), delayed and repeatable reports, a paused legacy queue and a fake BullMQ Pro grouped queue. Everything is unlocked (the demo runs as Pro, which is why it has a login) and everything can be poked at — the simulator refills it. Details in docs/DEMO.md.

USD 39/month or 390/year, one installation, unlimited users. Pro features are visible in the free edition with a lock icon, never hidden. Gating lives in exactly two places: requireFeature() on the server (HTTP 402) and useEdition() on the web.

Bullpane is an MCP server. Add <PUBLIC_URL>/mcp to Claude (claude.ai, Claude Desktop, Claude Code) or any MCP client that supports OAuth, sign in with your Bullpane login or SSO, and pick read or read & write. The client acts as you, through the same API as the dashboard: access is the lowest of the admin's ceiling (Settings → MCP, off by default), what you approved and your role, so a viewer never writes. Every write is in the audit log with via: mcp; drain, clean and obliterate are never run from MCP, the client gets a link to confirm them in the dashboard. Design: docs/ARCHITECTURE.md.

bull-board has no users at all, so it cannot tell you who did anything. Taskforce is hosted, so the answer lives in someone else's account. If you run queues for a regulated customer, "who drained the payments queue on the 14th, and from which IP?" is a question you have to answer from your own database.

Every mutating call is recorded — jobs, queues, connections, users, license, logins — with the actor, target, parameters, result and IP. Three choices make it worth trusting:

• Refused attempts are recorded too. "Tried to obliterate and got a 403" is a finding. A success-only log shows silence in exactly the case you care about.
• The job payload is never stored. The log keeps the parameters of an action ({ state: "completed", removed: 3412 }) and, where useful, the payload size in bytes. Customer PII does not belong in a table you export as CSV.
• Nothing can edit or delete a row. There is no such endpoint. Rows leave only by age (BULLPANE_AUDIT_RETENTION_DAYS, default one year).

Recording happens in every edition; reading and exporting are Pro, because on a single-admin install the log only ever says "it was me". Nothing is lost by upgrading later — the history is already there.

Two kinds of key, both verified with Ed25519 against a public key compiled into the server:

• Subscription key (BULLPANE-XXXX-…), bought on bullpane.com. Activated once against api.bullpane.com, which issues a signed 7-day lease that the server re-checks every 24 h. It keeps working for 7 days without contact, so a network blip is not an outage.
• Offline key, hand-signed for air-gapped installs and procurement. Verified locally, never talks to the internet.

Paste either in Settings → License, or set BULLPANE_LICENSE_KEY. The signing and verification tooling (scripts/gen-license.ts) is in this repository so the format is auditable. Full lifecycle, including what the server sends on activation, is in docs/PRO.md.

pnpm install
cp .env.example .env
pnpm dev                         # server :3000 (tsx watch) + web (Vite, proxied); SQLite in apps/server/data
pnpm dev:simulator               # optional: fill local Redis with demo traffic

Useful: pnpm typecheck, pnpm test, pnpm build.

The simulator honours REDIS_URL, BULL_PREFIX, SIM_INTENSITY (0.2–3) and SIM_RESET=true (wipes the prefix first, SCAN+UNLINK only). To test Pro locally: pnpm --filter @bullpane/server exec tsx scripts/print-dev-license.ts.

See CONTRIBUTING.md before opening a pull request.

apps/server/               Fastify API + serves the built web UI. SQLite/MySQL, auth, alerts, licensing.
apps/web/                  React + Vite + Tailwind dashboard.
apps/simulator/            Demo traffic generator + the stress harness.
apps/website/              bullpane.com (static, Cloudflare Worker).
apps/license-api/          api.bullpane.com — activates keys, signs leases (Cloudflare Worker).
packages/shared/           Types + zod schemas. The contract between everything.
packages/inspector/        The backend-neutral Inspector contract the server codes against.
packages/redis-inspector/  ioredis + Lua. Every read of a customer's Redis goes here.
packages/pg-inspector/     SQL over BullMQ 6's Postgres schema. Every read of a customer's Postgres goes here.
scripts/gen-license.ts     Ed25519 keypair + license signing (vendor side).
Dockerfile                 Multi-stage; targets `runner` (dashboard) and `simulator`.
docker-compose.yml         app on SQLite; COMPOSE_PROFILES=mysql adds MySQL (bring your own Redis).
docker-compose.demo.yml    app + mysql + redis + simulator, DEMO_MODE=true.

Start with docs/ARCHITECTURE.md and docs/API.md.

• WebSocket live updates (today it polls; one EVALSHA per queue per refresh)
• Prometheus exporter for queue counts and failure rates
• Job data redaction rules (mask fields by path before they reach the browser)
• Audit log: per-action retention and a signed export for external auditors
• Queue-level retention policies (auto-clean completed/failed older than N)

Two small libraries for the same queues, dependency-free and MIT, built for the same production that Bullpane watches:

• bullmq-outbox — when Redis is out of memory or unreachable, jobs land in a store you own instead of disappearing. Works with BullMQ v5, v6 and Pro.
• bullmq-fanout — turn BullMQ into a message bus: publish one domain event to many queues, each with its own worker, retries and failure domain. Works with BullMQ v5, v6 and Pro.

Open core — see LICENSE. Everything outside an ee/ directory is MIT: the free edition, the Redis inspector, the shared contract. The code of the Pro features lives in apps/server/src/ee/ and apps/web/src/ee/ under the Bullpane Commercial License: you can read it, modify it and run it for development and testing, but running it in production needs a Pro subscription, and builds with the license check removed are not allowed. Releases up to 0.3.0 were MIT in full and stay that way.

Security issues: please see SECURITY.md rather than opening a public issue.
