btesser/serum2vital

Converts Xfer Serum 1 (.fxp) and Serum 2 (.SerumPreset) presets into Vital (.vital) presets: wavetables, noise samples, LFO shapes and switches, envelopes, filters, warp modes, effects and the modulation matrix.

The mapping is measured rather than guessed. Menu orders and knob curves were read back from the Serum plugin itself, the file formats were verified against single-change fixture presets, and levels, envelopes and warp depths were calibrated by rendering the same notes through both synths. Every preset comes with a list of what was approximated or dropped.

Hear it first: btesser.github.io/serum2vital plays Serum originals next to their Vital conversions, category by category.

Not affiliated with Xfer Records or Vital Audio. You need your own copies of the Serum presets and (for the wavetables) Serum's data folder.

pip install .            # Serum 1 only needs the standard library
pip install .[serum2]    # adds zstandard + cbor2 for Serum 2 presets

Python 3.9 or newer. This installs a serum2vital command; python -m serum2vital works from a checkout without installing.

Nothing is written unless you pass --out, so start with a dry run that only reports what would be lost. SERUM below is Serum's data folder, the one that holds Presets/, Tables/ and Noises/ (Serum calls it "Serum Presets"; on Windows it is usually under Documents/Xfer).

serum2vital "SERUM/Presets" --serum-root "SERUM"

Convert everything into an organised pack, with smaller embedded wavetables:

serum2vital "SERUM/Presets" "SERUM/Serum 2 Presets/Presets" --serum-root "SERUM"     --out "./out/Serum Converted/Presets" --organize --max-frames 16 --report report.json

Start with a handful before committing to the whole library:

serum2vital "SERUM/Presets/Some Pack" --serum-root "SERUM" --out ./out --limit 20 --verbose

To use the result in Vital, copy the Serum Converted folder into Vital's user data directory (the data_directory in Vital's config; Documents/Vital by default) so it appears as a pack, or point Vital's browser at it.

A full library of about 8,000 presets takes a few minutes and about 3 GB with --max-frames 16.

The run ends with a summary of conversion notes grouped by fidelity class: approximation, conflict, unsupported and unknown.

Serum libraries are organised by pack, not by sound. --organize classifies each preset and writes it to <out>/<INSTRUMENT>/<TYPE>/<MODIFIER>/<name>.vital instead of mirroring the input folders:

out/
├── BASS/
│   ├── REESE/DARK/Reese 01.vital
│   ├── GROWL/DISTORTED/AU_HM_bass_growl_distorted.vital
│   └── 808/CLEAN/808 Electric [KARRA].vital
├── LEAD/
│   ├── SCREECH/AGGRESSIVE/SC - Elephant.vital
│   └── HARDSTYLE/WIDE/LD - Good Vibs.vital
├── PAD/GENERAL/WET/PD Compass [KARRA].vital
└── KEYS/ORGAN/CLEAN/OR - Leslie Organ.vital

• INSTRUMENT (BASS, LEAD, PAD, PLUCK, KEYS, FX, DRUM, SEQ, CHORD, VOCAL, SYNTH, INSTRUMENT) comes from the preset name's prefix or keywords (BA/BS/808/REESE…, LD/SCREECH…), then the Serum bank string, then the source folder names, and finally the sound itself (long attack → PAD, short decay with no sustain → PLUCK, …).
• TYPE is a sub-type keyword when the name has one (REESE, WOBBLE, SCREECH, SUPERSAW, PIANO, RISER, KICK, ARP, …), otherwise the genre the pack folder implies (DUBSTEP, HARDSTYLE, TRAP, DNB, TECHNO, …), otherwise GENERAL.
• MODIFIER is a descriptive keyword when present (HARD, DIRTY, SOFT, DARK, WIDE, ANALOG, GATED, …), otherwise derived from the converted parameters: heavy distortion or FM/RM warp → AGGRESSIVE, wide unison or chorus → WIDE, low filter cutoff → DARK, reverb plus delay → WET, else CLEAN.

Presets with the same name in one folder get (author) or (2) appended. The run summary prints a category histogram, and --report entries carry a "category" field with the three parts.

Every unit curve and menu order below was read back from the Serum 1 plugin itself (tools/serum_display_tables.json); nothing is inferred from knob positions. The CLI report groups its notes into approximation, conflict, unsupported and unknown.

Exact — the two synths agree on the underlying quantity:

• oscillator A/B → Vital osc 1/2: level, pan, octave/semi/fine, unison voices, detune (both quadratic over a 2-semitone range), blend, stereo spread, unison warp/WT-pos spread, wavetable position, phase (Vital reads a frame half a cycle later than Serum for the same knob value, which is compensated) and phase randomisation; the sub is phase-locked at note-on, as in Serum
• Serum's sub oscillator → Vital osc 3 (Sine, RoundRect, Saw, Square, Pulse), noise oscillator → Vital's sample source
• envelopes 1–3: Serum's knobs are t = 32·n⁵ seconds and Vital stores t^(1/4); sustain and curve controls; env 1's quadratic amplitude sustain matches Vital's squared amplitude envelope
• LFO shapes (point lists with per-segment tension, both file layouts), and the LFO switches: Hz mode → Vital Seconds with the exact frequency (100·n⁴ Hz), BPM mode → Vital tempo divisions with dotted/triplet, TRIG/ENV/OFF → Vital Trigger/Envelope/Sync, rise and delay
• the modulation matrix: sources (envelopes, LFOs, macros, mod wheel, velocity, note, aftertouch, pitch bend, release velocity, MPE slide/pressure, Chaos 1/2 as Vital random LFOs, note-on random as Vital's per-note random), destinations, amounts, and Serum's aux source as a modulation of the routing's own amount
• FX rack order (Vital's effect chain order is set to match), wet/dry, feedback and cutoff amounts of reverb, delay, chorus, distortion, phaser, flanger, compressor and EQ; delay modes and synced divisions
• macro values and names, preset name, author, bank
• the Serum 1 controls that are not VST parameters, read from the preset's switch block: Mono/Legato and the polyphony count, portamento Always/Scaled, noise one-shot and pitch tracking, filter keytrack, unison detune range and tuning mode (Linear/Exp/Inv → Vital's detune power), Chaos Mono (Vital random-LFO sync) and S&H (Vital's S&H style), the A4 tuning reference, oversampling (1x/2x/4x) and the chorus mono switch

Approximated — reported per preset:

• Filter type. All 96 Serum types are catalogued (serum2vital/filter_map.py): MG → Ladder, SVF types → Analog with blend/style, dual SVFs → Vital filters 1+2 in series with VAR as the second cutoff, morphing types → blend driven by VAR, comb/flanger/phaser types → Comb and Phaser models, formants → Formant, EQ types → shelf/pass approximations. Ring Mod and SampHold have no counterpart and are reported.
• Warp. Sync, Bend, PWM, Asym, Quantize, FM/AM/RM from the other oscillator, FM from noise/sub all map onto Vital's phase distortion; AM is rendered as RM. Flip, Mirror and Remap are reported.
• Hyper/Dimension (on in half the library) → Vital's chorus: voices, rate, detune, mix and Dimension size/mix. When Serum's own chorus is also on, the Hyper goes to the flanger and the conflict is reported. Retrigger is not reproducible.
• Distortion modes map onto Vital's six types; reverb and compressor are different algorithms and are matched by their main controls.
• Serum 2 effect racks are converted module by module where Vital has the effect; buses, convolution, Bode shifting and splitters are reported.

Not converted — dropped and reported:

• Serum 2 granular/spectral/multisample engines, arpeggiator, clips, MPE per-note settings, macros 5–8 and LFOs 9–10
• the LFO 5–8 sync switches in presets from Serum builds that predate LFO 5–8 (loaded as Serum does: synced and free-running; only reported when those LFOs are used)
• Serum 1's Note-on Alt, Noise-osc and Fixed modulation sources; Serum 2's audio-rate (oscillator/filter) and voice-bookkeeping sources
• the reverb's Plate mode (Vital's reverb has no plate); reported

What the readers still cannot interpret in either file format, and the fixture presets that would settle each item, are listed in docs/FORMATS.md and docs/FIXTURE_PRESETS_TASK.md.

A converted preset is a structurally faithful starting point, not a bit-exact clone. Levels, envelope curves, warp depths and filter drive were calibrated by rendering both synths (tools/calibrate.py, tools/ab_render.py); on a random batch most presets land within 3 dB of Serum, heavy-drive and fast-decay patches drift most, so expect to touch up drive and decay on anything you care about.

tools/ holds headless hosts for both synths so that mappings can be measured instead of argued about:

• tools/vital_host.py preset.vital --render out.wav loads Vital (VST3, via pedalboard), injects a preset, reads the parameters back and renders a note.
• tools/serum_host.py preset.fxp --render out.wav does the same for Serum (VST2, via DawDreamer) and can print any parameter's display text.
• tools/serum2_host.py preset.SerumPreset --render out.wav does the same for Serum 2 (VST3, via DawDreamer); it rebuilds the plugin's two XferJson state containers from the preset, which is the part a plain state load gets wrong.
• tools/ab_render.py preset.fxp preset.vital renders the same note through both and prints level, spectral centroid and stereo correlation.
• tools/listen.py "out/.../BASS/REESE" --out out/listen/reese renders every converted preset in a folder next to its Serum original (a held note, a short riff, a held note again) and writes an index.html with side-by-side players, so a whole category can be auditioned in one sitting. tools/publish_listen.py out/listen/reese --site site turns those folders into the MP3 + HTML site served from the gh-pages branch.
• tools/calibrate.py runs the parameter sweeps the unit curves were fitted from.
• tools/fx_fixtures.py craft|serum|vital|compare builds single-purpose effect presets for both Serum generations, renders them through Serum and through the converter into Vital, and compares echo times, tail decay, octave bands and stereo width; the effect laws in serum2vital/fx_common.py come from it.
• tools/verify.py out/ checks the structural invariants Vital's loader needs.

Install them with pip install .[hosts] and set SERUM_VST2, VITAL_VST3 and SERUM_ROOT if your plugins and library are not in the default locations.

serum2vital/
  serum1.py          .fxp reader (container, parameters, mod matrix, LFO shapes)
  serum2.py          .SerumPreset reader (XferJson + zstd + CBOR)
  serum_params.py    Serum's 299-parameter name/range table
  serum_tables.py    generated: Serum menu lists, rate tables and unit curves
  filter_map.py      the 96-entry filter catalog -> Vital filter targets
  fx_common.py       Hyper->chorus, distortion table, effect-order encoder
  serum2_fx.py       Serum 2 FX rack conversion
  mapping.py         Serum -> Vital parameter mapping, with fidelity notes
  wavetables.py      Serum wavetable/sample/.shp -> Vital JSON fragments
  vital_defaults.py  generated Vital parameter table (do not edit)
  writer.py          assembles the .vital document
  convert.py         CLI
tools/
  gen_vital_defaults.py   regenerates vital_defaults.py from Vital's source
  gen_serum_tables.py     regenerates serum_tables.py from serum_display_tables.json
  serum_display_tables.json  what the Serum plugin displays, captured headlessly
  serum_host.py / serum2_host.py / vital_host.py / ab_render.py   headless hosts for validation
docs/
  FORMATS.md         how all three formats are laid out, and how that was verified
  FINDINGS_AND_PLAN.md   the investigation log: what was measured and why
  FIXTURE_PRESETS_TASK.md   how to save fixture presets that pin down non-parameter state
  serum2_fx_survey.md    what the Serum 2 effect racks store
tests/                   fixtures under DebugPresets/ plus unit tests (pytest)

vital_defaults.py is generated from Vital's own synth_parameters.cpp:

curl -o tools/synth_parameters.cpp https://raw.githubusercontent.com/mtytel/vital/main/src/common/synth_parameters.cpp
python tools/gen_vital_defaults.py tools/synth_parameters.cpp serum2vital/vital_defaults.py

See CONTRIBUTING.md. The project is licensed under the GPL-3.0-or-later (LICENSE): the Vital parameter table it ships and regenerates from is GPL-3.0 code from the Vital repository.

Serum's .fxp parameter list comes from 0xdevalias' reverse-engineering notes; the Serum 2 container layout matches serum-preset-packager. Everything else in docs/FORMATS.md was worked out against a large preset library and the Serum plugin's own read-outs (see docs/FINDINGS_AND_PLAN.md for the investigation). Vital's parameter table is taken from mtytel/vital (GPLv3). Headless hosting uses DawDreamer and pedalboard.
