StonkGuy/eac-arm64-emulation-poc

A proof of concept: running VRChat with genuine Easy Anti-Cheat on an arm64 Linux machine through FEX-Emu — and everything it took to get there.

Reminder: here be dragons, please be mindful of the associated risks. I personally haven't observed any yet, but this runs anti-cheat-protected games on a setup their developers don't support (an emulated x86 CPU, often inside a VM). An anti-cheat or a game's terms of service may treat that as a violation, and an account action is possible; use an account you can afford to lose. The scripts replace files inside Steam's FEX tool (restore puts Valve's back) and nothing here is endorsed by Valve, Epic Games, the FEX-Emu project or any game developer. No warranty; see the License.

This is a standalone repository. It records the investigation and the changes to FEX-Emu (2610; developed on 2609.1) that were needed to bring up one x86-64 game with Epic's Easy Anti-Cheat for Linux/Proton on an arm64 host: the changes are kept as patch files you can apply yourself, with the tests that show what each one fixes and the diagnostic tools that found the problems.

It is deliberately one game on one SoC (VRChat on an Apple M2: developed under Fedora Asahi Remix inside a muvm micro-VM, and also verified on macOS, see below). Treat it as a starting point and take it further — another game, another SoC, another host — but please report bugs you find here rather than only fixing them in a fork; see Bugs, fixes and upstreaming.

macOS. The same patched FEX also runs VRChat with genuine EAC on an Apple M2 MacBook Air under macOS 27, inside the steamac libkrun guest (Valve's ARM64 SteamOS, Steam's own FEX compatibility tool swapped for the patched build). Result, timings and limits: docs/macos-port.md. Setup and the downstream fixes live in a separate fork, StonkGuy/steamac (branch fex-eac).

Steam Frame. Got here from a post about the Steam Frame? Start with docs/steam-frame.md: get a shell, build the patched FEX on the Frame with scripts/steamos/, swap it into Steam's FEX tool, set the launch options. Reported working by another user; not tested here.

What made it hard was not CPU speed but fidelity. The anti-cheat launcher injects its client into the game with ptrace, and the emulator has to behave like a real Linux kernel for ptrace, signals and /proc in ways nothing else had asked of it; later, VRChat's own network threads exposed two more places where FEX's signal handling differs from Linux.

The series is split into fixes and diagnostics — patches 0001 (ptrace), 0002 (SMC hot pages) and 0007 (signal mask) are needed to run; 0008 and 0010 are correctness fixes in the same area, the rest is performance, kernel fidelity or tooling. docs/patches.md explains each patch and its reasoning:

Three different kinds of change are involved. Only the first is new code; nothing in Wine or Proton is patched.

1. The EAC launcher needed an x86-64 ptrace view of its tracee, /proc/<pid>/exe of the guest binary and signal-delivery stops for guest int3; the whole conversation is reproduced by a freestanding test (eac-tests/ptrace-inject, docs/how-it-works.md).
2. Joins that took a minute were code-invalidation cost in a process with ~200 threads (patch 0004, found with the stats of patch 0003).
3. Host out-of-memory kills of the whole VM: memory tuning and VM sizing (docs/tuning.md).
4. Photon time-outs (about every second session) were a lost wake-up in Wine's wait protocol: FEX ran guest signal handlers with the wrong signal mask (patch 0007). Finding it took a thread-snapshot facility that does not ptrace the anti-cheat, a stand-alone Wine reproducer, and a look at wineserver's epoll registrations (docs/disconnects.md). A second FEX bug of the same family (registers lost inside signal handlers, patch 0008) turned up while testing 0007.
5. A ~60 s freeze at start-up in some launches (the Photon region lookup timing out, then a Disconnecting rejoin loop) was the game's IL2CPP thread pool starving on a 4-vCPU VM. Not a FEX or Wine bug: reporting 16 CPUs with Proton's WINE_CPU_TOPOLOGY removes it. Found with in-process thread snapshots and a passive reader of wineserver's socket state (docs/disconnects.md).

On a Steam Frame (or another SteamOS arm64 device), follow docs/steam-frame.md instead.

sudo dnf install steam muvm fex-emu && steam          # base install, log in, install VRChat, launch it once
scripts/build-fex.sh                                  # clones and builds StonkGuy/FEX tag eac-2610.2 into work/FEX
scripts/vm/install-overlay.sh
(cd work/FEX/eac-tests/ptrace-inject && ./build.sh clang)
scripts/vm/run-test-in-vm.sh work/FEX/eac-tests/ptrace-inject/ptrace_inject_test   # must print RESULT: PASS
scripts/vm/run-test-in-vm.sh <other eac-tests binary>  # e.g. signal-mask, signal-regs: RESULT: PASS
sudo scripts/host-tune.sh                             # memory tuning (optional, strongly recommended on 16 GB)
scripts/set-launch-options.sh                         # with Steam closed
REALISM=1 VM_MEM_MB=10240 VM_VRAM_MB=3072 scripts/vm/steam-vm.sh   # start Steam in the VM (verified config; REALISM=1 is optional), then launch VRChat

Full A-to-Z guide, the exact verified versions and what breaks a working setup: docs/setup-asahi.md. Tools: docs/tools.md. What works and what is open: docs/status.md.

• Not an anti-cheat bypass. Nothing fakes, replays or short-circuits EAC's result; no Epic or VRChat binaries, keys or traces are included. The patches only make FEX behave like a real Linux kernel for ptrace, signals and /proc/<pid>/exe, and the EAC client that runs is the stock, unmodified one from Valve's Proton EAC Runtime.
• One caveat, stated plainly. The optional scripts/vm/realism.sh does not touch EAC, but it is not pure emulation-fidelity either: it presents plausible SMBIOS/DMI data to the guest so it looks less like a microVM (and, a step beyond VRChat's guide, a PCI device list and hostname). That is environment adaptation following VRChat's own published guide, "Using VRChat in a Virtual Machine", which says EAC's VM block is its CPUID hypervisor-vendor check and that "You can get virtualization working alongside EAC in some cases, and we don't mind if you do this." Read that as a policy statement, not a licence: it is tolerated-but-unsupported, and this repository marks the script optional: VRChat runs without it. It may be useful for other games whose anti-cheat inspects the machine's hardware identity. It does not modify the game or the anti-cheat.
• Not supported by VRChat. VRChat does not support virtual machines or emulation; Epic/VRChat may change anything at any time and enforcement is their call. Use at your own risk, and never run modified clients. Never attach a debugger or perf to the running game: EAC reports it.

Found a bug, or a place where the patched FEX still behaves differently from x86-64 Linux? Please report it here as an issue. If you have already fixed it in your own fork, please consider opening a pull request here too (with a test), so everyone gets the fix and the test suite covers it. FEX code changes go to StonkGuy/FEX as a pull request against the current eac-<release> branch, with a test in its eac-tests/.

This repository does not send patches to FEX-Emu or Proton itself and is not affiliated with them (steamac changes are discussed with its maintainer directly). If you have reviewed a patch and think it is good enough for upstream, you are welcome to submit it there yourself: keep its test with it, follow the upstream project's own process, and mention where it came from. The same applies to the other patched components (libkrun, Mesa/KosmicKrisp, virglrenderer, DXMT), unless that project's own rules say otherwise — DXMT, for example, does not accept AI-assisted contributions.

I will try to keep the patched components up to date with their upstream releases, re-running the regression tests on every update, and to drop any patch once upstream covers its behaviour. For game-specific problems I will try to help where I can, but I cannot guarantee that every game, or every fix, will work.

Each FEX release is handled the same way: rebase the patches onto it as branch eac-<release> of StonkGuy/FEX, run eac-tests in the guest and natively for the oracle, check a live VRChat session, drop every patch whose behaviour upstream now provides, and tag the result; this repository and the steamac fork then pin the new tag.

The Proton EAC runtime is the same launcher/client machinery for every game that ships Linux EAC, so the ptrace work is not VRChat-specific; each game still has its own EAC build, integrity checks and server-side policy. VRChat is verified end to end; Mini Royale's EAC launcher also reaches 301 with 0033 (the game itself was not played past its account prompt). Results differ from game to game: each title ships its own EAC build and checks, so an untested game may or may not work. Besides Asahi and the macOS guest above, other FEX hosts are untested, with the exception of the Steam Frame (findings from another user, @VirtuallyNoxide; setup in docs/steam-frame.md) — see docs/other-platforms.md.

MIT (see LICENSE); the patches modify FEX-Emu, also MIT.
